Speedometer replacement parts for 2009 Suzuki V-Strom (DL1000)

OEM Parts Suzuki 2009 Suzuki V Strom (DL1000) Speedometer

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1-1	SPEEDOMETER (MILE/KILO) Part #: 34120-06G61 Required per assembly: 1 Not Available
2	RING Part #: 34193-06G50 Required per assembly: 1 Not Available
3	SCREW Part #: 34183-31F10 Required per assembly: 8 Note: SCREW (2.3X8); Not Available
4	CASE, UPPER Part #: 34150-27G00 Required per assembly: 1 Not Available
5	KNOB Part #: 34124-24F00 Required per assembly: 2 Note: SWITCH, LEVER; $9.54 $8.59 - + Add to cart
6	CASE, LOWER Part #: 34111-27G00 Required per assembly: 1 $85.12 $76.61 - + Add to cart
7	TAPPING SCREW Part #: 09132-03008 Required per assembly: 14 Note: SCREW (3X16); $1.81 $1.63 - + Add to cart
8	CUSHION, SPEEDOMETER Part #: 34955-10G01 Required per assembly: 2 $3.28 $2.95 - + Add to cart
9	SCREW, FENDER Part #: 03541-0520B Required per assembly: 4 Note: SCREW; $2.77 $2.49 - + Add to cart
10	ROTOR, SPEED Part #: 34981-38G01 Required per assembly: 1 $22.13 $18.91 - + Add to cart
11	SENSOR, SPEEDOMETER Part #: 34990-35F00 Required per assembly: 1 Note: SENSOR, SPEED; $168.77 $144.30 - + Add to cart
12	SCREW, FUSE, BOX Part #: 07120-0510B Required per assembly: 1 $3.22 $2.90 - + Add to cart
13	BOLT, REAR, MUFFLER Part #: 07130-0825B Required per assembly: 1 Note: BOLT, SPEED ROTOR; $4.10 $3.69 - + Add to cart
