Body, Fuel Tank Asm. replacement parts for 2011 Polaris Sportsman 500 FOREST (A11MH50FF)

OEM Parts Polaris 2011 Polaris Sportsman 500 FOREST (A11MH50FF) Body, Fuel Tank Asm.

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ASM-FUEL TANK 500HO 7 LAYER Part #: 2521132 Required per assembly: 1 Currently Not Available
2	BRACKET, MOUNTING, REAR, RH Part #: 5247185 Required per assembly: 1 Note: Bracket, Fuel Cover Mount, RH Currently Not Available
2	BRACKET, MOUNTING, REAR, LH Part #: 5247184 Required per assembly: 1 Note: Bracket, Fuel Cover Mount, LH Currently Not Available
3	SEAL, FOAM Part #: 5812265 Required per assembly: 1 Currently Not Available
4	SCREW Part #: 7517219 Required per assembly: 2 Currently Not Available
5	FOIL Part #: 5813282 Required per assembly: 1 Currently Not Available
6	FOIL Part #: 5813218 Required per assembly: 1 Currently Not Available
7	STRAP, BLACK, WEATHER-RESIST. Part #: 7080492 Required per assembly: 2 Currently Not Available
8	GASKET Part #: 5812123 Required per assembly: 1 Currently Not Available
9	CAP, GAS, VENTED Part #: 2520957 Required per assembly: 1 Note: Cap, Gas, Vented [Incl. 2] Currently Not Available
10	CAP-PLUG VENT .1200 ID Part #: 5413875 Required per assembly: 1 Currently Not Available
