Front Fork replacement parts for 2011 Yamaha FJR1300A (FJR13AACS)

OEM Parts Yamaha 2011 Yamaha FJR1300A (FJR13AACS) Front Fork

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H) Part #: 3P6-23102-10-00 Required per assembly: 1 ~~$1,178.99~~ $1,111.56 - + Add to cart
2	INNER TUBE COMP.1 Part #: 3P6-23110-11-00 Required per assembly: 1 Not Available
3	METAL, SLIDE, 2 Part #: 4SV-23135-10-00 Required per assembly: 1 ~~$22.98~~ $20.26 - + Add to cart
4	OUTER TUBE COMP (LH) Part #: 3P6-23106-01-00 Required per assembly: 1 ~~$365.99~~ $358.42 - + Add to cart
5	METAL, SLIDE, 1 Part #: 4SV-23125-10-00 Required per assembly: 1 ~~$22.98~~ $20.12 - + Add to cart
6	METAL, SLIDE, 2 Part #: 3P6-23135-00-00 Required per assembly: 1 ~~$22.98~~ $20.61 - + Add to cart
7	SEAL, DUST Part #: 4SV-23144-00-00 Required per assembly: 1 ~~$17.98~~ $17.70 - + Add to cart
8	OIL SEAL Part #: 4SV-23145-01-00 Required per assembly: 1 ~~$19.98~~ $19.55 - + Add to cart
9	GUIDE, COVER, UPPER Part #: 4SV-23115-00-00 Required per assembly: 1 $9.46 - + Add to cart
10	RING, SNAP Part #: 4SV-23156-00-00 Required per assembly: 1 $8.69 - + Add to cart
11	CYLINDER, COMP, FRONT, FORK Part #: 3P6-23170-00-00 Required per assembly: 1 ~~$498.99~~ $437.35 - + Add to cart
12	SPINDLE, TAPER Part #: 5LV-23173-00-00 Required per assembly: 1 ~~$65.98~~ $52.65 - + Add to cart
13	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-10N52-00 Required per assembly: 1 ~~$8.49~~ $7.87 - + Add to cart
14	GASKET Part #: 90430-10171-00 Required per assembly: 1 ~~$3.18~~ $2.65 - + Add to cart
15	PLUNGER Part #: 5JW-2318Y-00-00 Required per assembly: 1 $5.51 - + Add to cart
16	SPRING, FRONT, FORK Part #: 3P6-23141-00-00 Required per assembly: 1 ~~$78.98~~ $64.41 - + Add to cart
17	WASHER, PLATE Part #: 90201-10321-00 Required per assembly: 1 ~~$9.49~~ $7.38 - + Add to cart
18	SPACER Part #: 5JW-23118-00-00 Required per assembly: 1 ~~$9.99~~ $7.51 - + Add to cart
19	BOLT, CAP Part #: 5JW-23111-01-00 Required per assembly: 1 ~~$286.99~~ $257.55 - + Add to cart
20	O-RING Part #: 93210-40N50-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
21	KNOB (TEN) Part #: 5JW-2319W-00-00 Required per assembly: 1 $12.04 - + Add to cart
22	SCREW, OVAL, HEAD Part #: 98680-03008-00 Required per assembly: 1 ~~$0.28~~ $0.25 - + Add to cart
23	NUT (3BM) Part #: 95314-10600-00 Required per assembly: 1 ~~$2.54~~ $2.46 - + Add to cart
24	COVER Part #: 4SV-2331G-00-00 Required per assembly: 1 ~~$19.98~~ $18.17 - + Add to cart
25	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08045-00 Required per assembly: 2 ~~$9.49~~ $9.10 - + Add to cart
26	FRONT FORK ASSEMBLY (R.H) Part #: 3P6-23103-10-00 Required per assembly: 1 Not Available
27	INNER TUBE COMP.1 Part #: 3P6-23110-11-00 Required per assembly: 1 Not Available
28	METAL, SLIDE, 2 Part #: 4SV-23135-10-00 Required per assembly: 1 ~~$22.98~~ $20.26 - + Add to cart
30	METAL, SLIDE, 1 Part #: 4SV-23125-10-00 Required per assembly: 1 ~~$22.98~~ $20.12 - + Add to cart
31	METAL, SLIDE, 2 Part #: 3P6-23135-00-00 Required per assembly: 1 ~~$22.98~~ $20.61 - + Add to cart
32	SEAL, DUST Part #: 4SV-23144-00-00 Required per assembly: 1 ~~$17.98~~ $17.70 - + Add to cart
33	OIL SEAL Part #: 4SV-23145-01-00 Required per assembly: 1 ~~$19.98~~ $19.55 - + Add to cart
34	GUIDE, COVER, UPPER Part #: 4SV-23115-00-00 Required per assembly: 1 $9.46 - + Add to cart
35	RING, SNAP Part #: 4SV-23156-00-00 Required per assembly: 1 $8.69 - + Add to cart
36	CYLINDER, COMP, FRONT, FORK Part #: 3P6-23170-00-00 Required per assembly: 1 ~~$498.99~~ $437.35 - + Add to cart
37	SPINDLE, TAPER Part #: 5LV-23173-00-00 Required per assembly: 1 ~~$65.98~~ $52.65 - + Add to cart
38	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-10N52-00 Required per assembly: 1 ~~$8.49~~ $7.87 - + Add to cart
39	GASKET Part #: 90430-10171-00 Required per assembly: 1 ~~$3.18~~ $2.65 - + Add to cart
40	PLUNGER Part #: 5JW-2318Y-00-00 Required per assembly: 1 $5.51 - + Add to cart
41	SPRING, FRONT, FORK Part #: 3P6-23141-00-00 Required per assembly: 1 ~~$78.98~~ $64.41 - + Add to cart
42	WASHER, PLATE Part #: 90201-10321-00 Required per assembly: 1 ~~$9.49~~ $7.38 - + Add to cart
43	SPACER Part #: 5JW-23118-00-00 Required per assembly: 1 ~~$9.99~~ $7.51 - + Add to cart
44	BOLT, CAP Part #: 5JW-23111-01-00 Required per assembly: 1 ~~$286.99~~ $257.55 - + Add to cart
45	O-RING Part #: 93210-40N50-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
46	KNOB (TEN) Part #: 5JW-2319W-00-00 Required per assembly: 1 $12.04 - + Add to cart
47	SCREW, OVAL, HEAD Part #: 98680-03008-00 Required per assembly: 1 ~~$0.28~~ $0.25 - + Add to cart
48	NUT (3BM) Part #: 95314-10600-00 Required per assembly: 1 ~~$2.54~~ $2.46 - + Add to cart
49	COVER Part #: 4SV-2331G-00-00 Required per assembly: 1 ~~$19.98~~ $18.17 - + Add to cart
50	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08045-00 Required per assembly: 2 ~~$9.49~~ $9.10 - + Add to cart
51	UNDER BRACKET COMP. Part #: 1MC-23340-10-00 Required per assembly: 1 ~~$446.99~~ $433.99 - + Add to cart
52	BOLT, SOCKET Part #: 91317-08025-00 Required per assembly: 4 ~~$9.49~~ $8.40 - + Add to cart
