Crankcase replacement parts for 2011 Yamaha FZ6R (FZ6RAO)

OEM Parts Yamaha 2011 Yamaha FZ6R (FZ6RAO) Crankcase

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CRANKCASE ASSEMBLY Part #: 20S-15100-09-00 Required per assembly: 1 $1,900.46 - + Add to cart
2	NOZZLE 3 Part #: 5EB-15155-00-00 Required per assembly: 4 $16.03 - + Add to cart
3	O-RING Part #: 93210-04092-00 Required per assembly: 4 $4.05 - + Add to cart
4	PIN, DOWEL, (3VD) Part #: 99530-10114-00 Required per assembly: 3 $3.23 - + Add to cart
5	PLUG Part #: 5SL-15189-00-00 Required per assembly: 1 $4.32 - + Add to cart
6	SCREW Part #: 90149-06081-00 Required per assembly: 1 ~~$9.49~~ $8.31 - + Add to cart
7	BOLT, WITH, WASHER Part #: 90119-08083-00 Required per assembly: 8 $9.46 - + Add to cart
8	BOLT, WITH, WASHER Part #: 90119-08084-00 Required per assembly: 2 ~~$17.48~~ $15.25 - + Add to cart
9	BOLT, FLANGE Part #: 95812-06055-00 Required per assembly: 6 $2.09 - + Add to cart
10	BOLT, WASHER, BASED Part #: 95814-08065-00 Required per assembly: 2 ~~$5.49~~ $4.92 - + Add to cart
11	BOLT Part #: 90109-06168-00 Required per assembly: 2 Not Available
12	BOLT, FLANGE Part #: 95812-06065-00 Required per assembly: 2 $7.16 - + Add to cart
13	BOLT, FLANGE Part #: 95817-06045-00 Required per assembly: 3 ~~$9.49~~ $8.33 - + Add to cart
14	BOLT, FLANGE Part #: 95812-06100-00 Required per assembly: 1 $3.29 - + Add to cart
15	BOLT, FLANGE Part #: 90105-06147-00 Required per assembly: 1 $2.67 - + Add to cart
16	PLATE, BREATHER Part #: 20S-11165-00-00 Required per assembly: 1 $4.52 - + Add to cart
17	SCREW Part #: 90149-06081-00 Required per assembly: 3 ~~$9.49~~ $8.31 - + Add to cart
19	GASKET, CRANKCASE, COVER, 3 Part #: 20S-15462-00-00 Required per assembly: 1 $4.73 - + Add to cart
20	BOLT, SOCKET Part #: 91317-06025-00 Required per assembly: 6 $2.91 - + Add to cart
21	PLUG Part #: 36Y-15189-01-00 Required per assembly: 2 ~~$15.49~~ $15.02 - + Add to cart
22	O-RING Part #: 93210-16325-00 Required per assembly: 2 ~~$8.49~~ $7.94 - + Add to cart
23	PLUG, OIL, LEVEL Part #: 5EB-15362-10-00 Required per assembly: 1 ~~$43.99~~ $34.10 - + Add to cart
24	O-RING (1J7) Part #: 93210-09350-00 Required per assembly: 1 $7.87 - + Add to cart
25	STAY 1 Part #: 20S-15544-00-00 Required per assembly: 1 $12.16 - + Add to cart
26	BOLT, FLANGE Part #: 95022-06012-00 Required per assembly: 2 $4.21 - + Add to cart
27	CLAMP Part #: 90464-34002-00 Required per assembly: 1 $2.29 - + Add to cart
