Front Suspension Wheel replacement parts for 2011 Yamaha Grizzly 350 IRS 4WD (YFM35FGIAG)

OEM Parts Yamaha 2011 Yamaha Grizzly 350 IRS 4WD (YFM35FGIAG) Front Suspension Wheel

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRT. UPPER ARM (L) (LEFT) Part #: 5ND-F3540-13-00 Required per assembly: 1 ~~$190.99~~ $169.30 - + Add to cart
2	BALL JOINT 1 Part #: 37S-23549-01-00 Required per assembly: 1 ~~$83.98~~ $74.19 - + Add to cart
3	CIRCLIP, S-TYPE Part #: 93410-32075-00 Required per assembly: 1 Note: Sold in multiples of 10 only ~~$10.49~~ $6.85 - + Add to cart
4	FRT. UPPER ARM (R) (RIGHT) Part #: 5ND-F3550-13-00 Required per assembly: 1 ~~$150.99~~ $125.34 - + Add to cart
5	BALL JOINT 1 Part #: 37S-23549-01-00 Required per assembly: 1 ~~$83.98~~ $74.19 - + Add to cart
6	CIRCLIP, S-TYPE Part #: 93410-32075-00 Required per assembly: 1 Note: Sold in multiples of 10 only ~~$10.49~~ $6.85 - + Add to cart
7	NUT, CASTLE Part #: 90171-12001-00 Required per assembly: 4 ~~$3.54~~ $2.80 - + Add to cart
8	PIN, COTTER Part #: 91490-25020-00 Required per assembly: 4 Note: Sold in multiples of 5 only ~~$3.45~~ $2.87 - + Add to cart
9	ARM, FRONT, LOWER, LH Part #: 1D9-F357A-00-00 Required per assembly: 1 Not Available
10	ARM, FRONT, LOWER, RH Part #: 1D9-F358A-00-00 Required per assembly: 1 Not Available
11	BUSH Part #: 2HR-23526-00-00 Required per assembly: 8 ~~$22.98~~ $18.67 - + Add to cart
12	BOLT, FLANGE Part #: 90105-10267-00 Required per assembly: 8 ~~$10.49~~ $7.61 - + Add to cart
13	WASHER Part #: 5KM-22149-10-00 Required per assembly: 4 ~~$8.49~~ $6.27 - + Add to cart
14	NUT, SELF-LOCKING Part #: 90185-10012-00 Required per assembly: 8 ~~$3.60~~ $2.93 - + Add to cart
15	SHOCK ABSORBER ASSEMBLY Part #: 1AB-F3350-00-00 Required per assembly: 2 Not Available
16	NUT, SELF-LOCKING Part #: 90185-10012-00 Required per assembly: 4 ~~$3.60~~ $2.93 - + Add to cart
17	BOLT, FLANGE Part #: 90105-10841-00 Required per assembly: 4 ~~$2.45~~ $1.84 - + Add to cart
18	COVER, UNDER, 1 Part #: 17S-F3123-00-00 Required per assembly: 1 ~~$70.98~~ $57.46 - + Add to cart
19	COVER, LOWER, 2 Part #: 17S-F3133-00-00 Required per assembly: 1 ~~$70.98~~ $57.68 - + Add to cart
20	NUT, SPRING, (4ES) Part #: 90183-06069-00 Required per assembly: 2 ~~$7.49~~ $5.99 - + Add to cart
21	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 2 ~~$1.95~~ $1.47 - + Add to cart
