Crankshaft replacement parts for 2012 Suzuki DR650SE

OEM Parts Suzuki 2012 Suzuki DR650SE Crankshaft

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	CRANKSHAFT SET Part #: 12000-32820 Required per assembly: 1 $1,172.05 $1,054.85 - + Add to cart
2	ROD, CONNECTING Part #: 12161-32E00 Required per assembly: 1 $170.20 $145.51 - + Add to cart
3	PIN, CRANK Part #: 12211-32E00 Required per assembly: 1 $92.92 $83.63 - + Add to cart
4	BEARING (37X47X25) Part #: 09263-37004-0C0 Required per assembly: 1 $55.90 $50.31 - + Add to cart
5	WASHER Part #: 09160-37006 Required per assembly: 2 $11.13 $10.02 - + Add to cart
6	CRANKSHAFT, SET, RH Part #: 12221-32810 Required per assembly: 1 Not Available
9	BEARING, MID, (40X80X18) Part #: 09262-40008 Required per assembly: 1 Note: RH $84.34 $72.11 - + Add to cart
10	BEARING, LH Part #: 09262-45011 Required per assembly: 1 Note: LH $92.42 $79.02 - + Add to cart
11	OIL, SEAL, RH, (16X30X6) Part #: 09282-16002 Required per assembly: 1 Note: RH $12.28 $11.05 - + Add to cart
12	PLATE, RH Part #: 12548-37400 Required per assembly: 1 $8.45 $7.61 - + Add to cart
13	SCREW Part #: 02112-0508B Required per assembly: 2 $2.24 $2.02 - + Add to cart
14	NUT Part #: 12664-04F00 Required per assembly: 1 $52.26 $47.03 - + Add to cart
15	GEAR, PRIMARY, DRIVE, (NT:28) Part #: 21111-32E00 Required per assembly: 1 Note: NT:28 $82.77 $74.49 - + Add to cart
16	NUT Part #: 09140-20013 Required per assembly: 1 $5.45 $4.91 - + Add to cart
17	LOCK WASHER Part #: 09164-20003 Required per assembly: 1 Note: WASHER; $4.04 $3.64 - + Add to cart
18	KEY Part #: 09420-05007 Required per assembly: 1 $4.83 $4.35 - + Add to cart
19	PISTON Part #: 12111-32E00-0F0 Required per assembly: 1 $122.39 $110.15 - + Add to cart
20	RING, SET, PISTON Part #: 12140-32E10 Required per assembly: 1 $67.22 $57.46 - + Add to cart
21	PIN, PISTON Part #: 12151-14A01 Required per assembly: 1 $29.73 $25.41 - + Add to cart
22	CIRCLIP Part #: 09381-23003 Required per assembly: 2 $1.73 $1.56 - + Add to cart
