Muffler replacement parts for 2012 Suzuki V-Strom (DL650A)

OEM Parts Suzuki 2012 Suzuki V Strom (DL650A) Muffler

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	PIPE, EXH, RR Part #: 14150-27G10 Required per assembly: 1 Not Available
2	PIEP, ECH, FR Part #: 14160-17G10 Required per assembly: 1 $248.79 $223.91 - + Add to cart
3	GASKET, EXHAUST, PIPE Part #: 14181-22D01 Required per assembly: 2 Note: GASKET; $12.49 $11.24 - + Add to cart
4	CONNECTOR, EXH Part #: 14771-32E10 Required per assembly: 2 $28.30 $25.47 - + Add to cart
5	BOLT Part #: 09103-08365 Required per assembly: 2 $4.83 $4.35 - + Add to cart
6	BOLT, EXHAUST, PIPE Part #: 09106-08165 Required per assembly: 4 Note: BOLT; $5.12 $4.61 - + Add to cart
7	COVER, MUFF, FR Part #: 14771-11J00 Required per assembly: 1 $52.26 $47.03 - + Add to cart
8	COVER, MUFFLER Part #: 14781-11J00-YUS Required per assembly: 1 $125.99 $113.39 - + Add to cart
9	SCREW Part #: 09139-06126 Required per assembly: 5 Note: SCREW, SIDE COWL; $5.06 $4.55 - + Add to cart
10	CUSHION Part #: 09320-08070 Required per assembly: 5 $12.50 $11.25 - + Add to cart
11	BOLT Part #: 09118-08152-A05 Required per assembly: 1 Note: BOLT (8X45); $6.38 $5.74 - + Add to cart
12	SPACER Part #: 09180-08152 Required per assembly: 1 Note: SPACER, MUFFLER SUPPORT; $7.10 $6.39 - + Add to cart
13	CUSHION Part #: 09320-12048 Required per assembly: 1 $6.23 $5.61 - + Add to cart
14	MUFFLER Part #: 14305-11J00 Required per assembly: 1 Not Available
15	BOLT, MUFFLER, SUPPORT Part #: 09103-08358 Required per assembly: 2 Note: BOLT (8X45); $4.29 $3.86 - + Add to cart
16	NUT, MUFFLER, SPRT Part #: 14414-27G00 Required per assembly: 1 Not Available
17	SPACER Part #: 09180-08156 Required per assembly: 1 $8.28 $7.45 - + Add to cart
18	CUSHION Part #: 09320-12049 Required per assembly: 2 $13.00 $11.70 - + Add to cart
19	NUT, MUFFLER, SUPPORT Part #: 14414-06G00 Required per assembly: 1 Not Available
20	WASHER Part #: 09160-08146 Required per assembly: 1 $3.02 $2.72 - + Add to cart
21	CUSHION, RH, MIDDLE Part #: 09321-10018 Required per assembly: 5 Note: CUSHION, FRONT; $5.85 $5.27 - + Add to cart
22	SENSOR, OXYGEN Part #: 18213-17G01 Required per assembly: 1 $415.84 $355.54 - + Add to cart
23	BAND, BAR, PAD, (L, 145) Part #: 09407-14407 Required per assembly: 1 Note: BAND; $3.70 $3.33 - + Add to cart
