Front Fork replacement parts for 2012 Yamaha FZ6R (FZ6RBCB)

OEM Parts Yamaha 2012 Yamaha FZ6R (FZ6RBCB) Front Fork

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (LH) Part #: 20S-23102-00-00 Required per assembly: 1 $923.99 $824.66 - + Add to cart
2	INNER TUBE COMP 1 Part #: 20S-23110-00-00 Required per assembly: 1 $280.99 $247.02 - + Add to cart
3	METAL, SLIDE, 2 Part #: 3VD-23135-10-00 Required per assembly: 1 $34.99 $26.81 - + Add to cart
5	TUBE, OUTER, (LEFT) Part #: 20S-23126-00-00 Required per assembly: 1 $307.99 $302.16 - + Add to cart
6	SPRING, REBOUND Part #: 3VD-23151-00-00 Required per assembly: 1 Not Available
7	SPINDLE, TAPER Part #: 5VU-23173-00-00 Required per assembly: 1 $29.98 $24.30 - + Add to cart
8	METAL, SLIDE, 1 Part #: 3VD-23125-10-00 Required per assembly: 1 $43.99 $33.42 - + Add to cart
9	OIL SEAL Part #: 5VU-23145-00-00 Required per assembly: 1 $32.99 $25.05 - + Add to cart
10	GUIDE, COVER, UPPER Part #: 3VD-23115-00-00 Required per assembly: 1 $12.99 $11.10 - + Add to cart
11	CLIP, OIL, SEAL Part #: 3VD-23156-00-00 Required per assembly: 1 $8.49 $6.41 - + Add to cart
12	SEAL, DUST Part #: 3VD-23144-00-00 Required per assembly: 1 $30.98 $22.20 - + Add to cart
14	FORK BOLT Part #: 5VU-2311H-00-00 Required per assembly: 1 $69.98 $53.15 - + Add to cart
15	O-RING Part #: 93210-35N02-00 Required per assembly: 1 $4.45 $3.70 - + Add to cart
16	GASKET Part #: 90430-10171-00 Required per assembly: 1 $3.18 $2.65 - + Add to cart
17	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-10N52-00 Required per assembly: 1 $8.49 $5.70 - + Add to cart
18	SPACER Part #: 5VU-23118-00-00 Required per assembly: 1 $13.49 $10.90 - + Add to cart
19	SEAT, SPRING, UPPER Part #: 5VU-23142-00-00 Required per assembly: 1 $3.39 $2.69 - + Add to cart
20	COVER Part #: 4TX-2331G-00-00 Required per assembly: 1 $18.98 $15.36 - + Add to cart
21	FRONT FORK ASSEMBLY (RH) Part #: 20S-23103-00-00 Required per assembly: 1 $923.99 $824.66 - + Add to cart
22	INNER TUBE COMP 1 Part #: 20S-23110-00-00 Required per assembly: 1 $280.99 $247.02 - + Add to cart
23	METAL, SLIDE, 2 Part #: 3VD-23135-10-00 Required per assembly: 1 $34.99 $26.81 - + Add to cart
25	TUBE, OUTER, (RIGHT) Part #: 20S-23136-00-00 Required per assembly: 1 $310.99 $303.65 - + Add to cart
26	SPRING, REBOUND Part #: 3VD-23151-00-00 Required per assembly: 1 Not Available
27	SPINDLE, TAPER Part #: 5VU-23173-00-00 Required per assembly: 1 $29.98 $24.30 - + Add to cart
28	METAL, SLIDE, 1 Part #: 3VD-23125-10-00 Required per assembly: 1 $43.99 $33.42 - + Add to cart
29	OIL SEAL Part #: 5VU-23145-00-00 Required per assembly: 1 $32.99 $25.05 - + Add to cart
30	GUIDE, COVER, UPPER Part #: 3VD-23115-00-00 Required per assembly: 1 $12.99 $11.10 - + Add to cart
31	CLIP, OIL, SEAL Part #: 3VD-23156-00-00 Required per assembly: 1 $8.49 $6.41 - + Add to cart
32	SEAL, DUST Part #: 3VD-23144-00-00 Required per assembly: 1 $30.98 $22.20 - + Add to cart
34	FORK BOLT Part #: 5VU-2311H-00-00 Required per assembly: 1 $69.98 $53.15 - + Add to cart
35	O-RING Part #: 93210-35N02-00 Required per assembly: 1 $4.45 $3.70 - + Add to cart
36	GASKET Part #: 90430-10171-00 Required per assembly: 1 $3.18 $2.65 - + Add to cart
37	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-10N52-00 Required per assembly: 1 $8.49 $5.70 - + Add to cart
38	SPACER Part #: 5VU-23118-00-00 Required per assembly: 1 $13.49 $10.90 - + Add to cart
39	SEAT, SPRING, UPPER Part #: 5VU-23142-00-00 Required per assembly: 1 $3.39 $2.69 - + Add to cart
40	COVER Part #: 4TX-2331G-00-00 Required per assembly: 1 $18.98 $15.36 - + Add to cart
41	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 1 $8.49 $5.15 - + Add to cart
42	UNDER BRACKET COMP. Part #: B40-23340-00-00 Required per assembly: 1 $268.99 $268.07 - + Add to cart
43	BOLT, SOCKET Part #: 91314-10025-00 Required per assembly: 2 $9.49 $6.67 - + Add to cart
44	BEARING, SPECIAL Part #: 93399-99932-00 Required per assembly: 1 $69.98 $55.57 - + Add to cart
45	SEAL, STEERING Part #: 3FV-23462-00-00 Required per assembly: 1 $26.98 $21.26 - + Add to cart
46	COVER, UNDER, 1 Part #: 4KM-23123-01-00 Required per assembly: 1 $15.49 $13.06 - + Add to cart
