Front Fork replacement parts for 2012 Yamaha FZ8NBG

OEM Parts Yamaha 2012 Yamaha FZ8NBG Front Fork

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H) Part #: 39P-23102-00-00 Required per assembly: 1 ~~$940.99~~ $920.86 - + Add to cart
2	TUBE, OUTER, (RIGHT) Part #: 2D1-23136-10-00 Required per assembly: 1 ~~$601.99~~ $590.79 - + Add to cart
3	WASHER, OIL, SEAL Part #: 4V4-23146-L0-00 Required per assembly: 1 $8.69 - + Add to cart
4	OIL SEAL Part #: 4PU-23145-01-00 Required per assembly: 1 ~~$28.98~~ $22.96 - + Add to cart
5	RING, SNAP Part #: 4V4-23153-L0-00 Required per assembly: 1 $11.30 - + Add to cart
6	SEAL, DUST Part #: 4PU-23144-00-00 Required per assembly: 1 ~~$26.98~~ $22.35 - + Add to cart
7	INNER TUBE COMP 1 Part #: 39P-23110-00-00 Required per assembly: 1 ~~$383.99~~ $375.64 - + Add to cart
8	CYLINDER, COMP., FRONT, FORK Part #: 39P-23170-00-00 Required per assembly: 1 $464.88 - + Add to cart
9	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 ~~$17.98~~ $17.34 - + Add to cart
10	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $10.11 - + Add to cart
11	SPRING, FRONT, FORK Part #: 39P-23141-00-00 Required per assembly: 1 ~~$85.98~~ $77.20 - + Add to cart
12	SPACER Part #: 5VY-23118-01-00 Required per assembly: 1 ~~$33.99~~ $28.91 - + Add to cart
13	NUT Part #: 3LC-23357-00-00 Required per assembly: 1 $8.63 - + Add to cart
14	BOLT, CAP Part #: 39P-23111-00-00 Required per assembly: 1 ~~$249.99~~ $225.18 - + Add to cart
15	O-RING Part #: 39P-23147-00-00 Required per assembly: 1 ~~$9.49~~ $9.22 - + Add to cart
16	FRONT FORK ASSEMBLY (R.H Part #: 39P-23103-01-00 Required per assembly: 1 Not Available
17	TUBE, OUTER, (RIGHT) Part #: 2D1-23136-10-00 Required per assembly: 1 ~~$601.99~~ $590.79 - + Add to cart
18	WASHER, OIL, SEAL Part #: 4V4-23146-L0-00 Required per assembly: 1 $8.69 - + Add to cart
19	OIL SEAL Part #: 4PU-23145-01-00 Required per assembly: 1 ~~$28.98~~ $22.96 - + Add to cart
20	RING, SNAP Part #: 4V4-23153-L0-00 Required per assembly: 1 $11.30 - + Add to cart
21	SEAL, DUST Part #: 4PU-23144-00-00 Required per assembly: 1 ~~$26.98~~ $22.35 - + Add to cart
22	INNER TUBE COMP.2 Part #: 39P-23120-01-00 Required per assembly: 1 ~~$383.99~~ $375.64 - + Add to cart
23	CYLINDER, COMP., FRONT, FORK Part #: 39P-23170-10-00 Required per assembly: 1 ~~$464.99~~ $450.61 - + Add to cart
24	GASKET Part #: 509-23158-L0-00 Required per assembly: 1 ~~$17.98~~ $17.34 - + Add to cart
25	BOLT, HEXAGON, SOCKET, HEAD Part #: 3D8-23181-00-00 Required per assembly: 1 $10.11 - + Add to cart
26	SPRING, FRONT, FORK Part #: 39P-23141-00-00 Required per assembly: 1 ~~$85.98~~ $77.20 - + Add to cart
27	SPACER Part #: 5VY-23118-01-00 Required per assembly: 1 ~~$33.99~~ $28.91 - + Add to cart
28	NUT Part #: 3LC-23357-00-00 Required per assembly: 1 $8.63 - + Add to cart
29	BOLT, CAP Part #: 39P-23111-00-00 Required per assembly: 1 ~~$249.99~~ $225.18 - + Add to cart
30	O-RING Part #: 39P-23147-00-00 Required per assembly: 1 ~~$9.49~~ $9.22 - + Add to cart
31	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 1 ~~$8.49~~ $5.15 - + Add to cart
32	UNDER BRACKET COMP. Part #: 39P-23340-00-00 Required per assembly: 1 ~~$582.99~~ $555.35 - + Add to cart
33	BOLT, SOCKET Part #: 91317-08030-00 Required per assembly: 4 ~~$9.49~~ $8.31 - + Add to cart
34	COVER, UNDER, 1 Part #: 4KM-23123-01-00 Required per assembly: 1 $16.31 - + Add to cart
