Fender replacement parts for 2012 Yamaha FZS10BCW

OEM Parts Yamaha 2012 Yamaha FZS10BCW Fender

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FENDER, FRONT Part #: 5PW-21511-02-PB Required per assembly: 1 $154.95 - + Add to cart
2	COLLAR Part #: 90387-06159-00 Required per assembly: 6 $9.49 $6.27 - + Add to cart
3	GROMMET Part #: 90480-12072-00 Required per assembly: 6 $9.49 $6.55 - + Add to cart
4	SCREW, SPEC'L, SHAPE Part #: 90149-06302-00 Required per assembly: 4 $6.49 $4.22 - + Add to cart
5	BOLT Part #: 90109-06031-00 Required per assembly: 2 $2.85 $1.89 - + Add to cart
6	NUT, U, FLANGE Part #: 95604-06200-00 Required per assembly: 2 $2.95 $2.31 - + Add to cart
7	BOX, BATTERY, 1 Part #: 2D1-8212B-02-00 Required per assembly: 1 $72.17 - + Add to cart
8	BOLT Part #: 90109-06253-00 Required per assembly: 2 $6.49 $4.54 - + Add to cart
9	RIVET Part #: 90269-07077-00 Required per assembly: 4 $9.49 $6.80 - + Add to cart
10	SEAL, 2 Part #: 2D1-216A2-00-00 Required per assembly: 1 $2.14 $1.78 - + Add to cart
11	SEAL, 3 Part #: 2D1-216A3-00-00 Required per assembly: 1 $7.49 $5.94 - + Add to cart
12	CLAMP Part #: 90464-07259-00 Required per assembly: 4 $3.29 $1.59 - + Add to cart
13	BAND, TOOL Part #: 4XV-21376-00-00 Required per assembly: 1 $11.99 $10.01 - + Add to cart
14	BAND Part #: 2D1-21646-00-00 Required per assembly: 1 $5.49 $4.75 - + Add to cart
15	SEAT, BATTERY Part #: 2D1-82122-10-00 Required per assembly: 1 $104.98 $95.24 - + Add to cart
16	HANDLE, SEAT, (MAT, BLACK, 2) Part #: 3C3-24773-00-P8 Required per assembly: 1 $757.99 $752.73 - + Add to cart
17	DAMPER, SEAT Part #: 3C3-24723-00-00 Required per assembly: 1 $10.49 $8.88 - + Add to cart
18	DAMPER, SEAT Part #: 3C3-24724-00-00 Required per assembly: 1 $5.99 $4.91 - + Add to cart
19	DAMPER, SEAT Part #: 3C3-24737-00-00 Required per assembly: 1 $12.49 $10.01 - + Add to cart
20	DAMPER, SEAT Part #: 3C3-24747-00-00 Required per assembly: 1 $5.49 $4.69 - + Add to cart
21	DAMPER 1 Part #: 3C3-21541-00-00 Required per assembly: 1 $3.39 $2.69 - + Add to cart
22	COVER, TAIL, 1, (MAT, BLACK, 2) Part #: 3C3-2471K-00-P7 Required per assembly: 1 $139.99 $125.71 - + Add to cart
23	COVER, TAIL, 2, (MAT, BLACK, 2) Part #: 3C3-2472K-00-P7 Required per assembly: 1 $166.99 $144.74 - + Add to cart
24	PROTECTOR Part #: 3C3-2193A-00-00 Required per assembly: 2 $8.49 $6.73 - + Add to cart
25	DAMPER Part #: 5PW-2174X-00-00 Required per assembly: 2 $7.49 $6.35 - + Add to cart
26	COVER, REAR, FENDER, 1 Part #: 3C3-2163A-00-00 Required per assembly: 1 $65.98 $54.52 - + Add to cart
27	BRACKET, FENDER Part #: 3C3-21617-00-00 Required per assembly: 1 $316.99 $316.76 - + Add to cart
28	PAD, SEAT Part #: 22W-24741-00-00 Required per assembly: 2 $9.49 $7.58 - + Add to cart
29	SCREW, WITH, WASHER Part #: 90159-05056-00 Required per assembly: 8 $1.39 $1.18 - + Add to cart
30	NUT, SPRING Part #: 90183-051A0-00 Required per assembly: 8 $4.09 $2.62 - + Add to cart
31	BOLT, FLANGE, (4LN) Part #: 95817-08025-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
32	BOLT, FLANGE, (6TA) Part #: 95817-08030-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
33	NUT, FLANGE, (JN5) Part #: 95707-08500-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
34	COLLAR Part #: 90387-09012-00 Required per assembly: 4 $13.49 $11.36 - + Add to cart
35	CLAMP Part #: 90464-16021-00 Required per assembly: 1 $13.49 $10.66 - + Add to cart
36	PROTECTOR 1 Part #: 3C3-22825-00-00 Required per assembly: 1 $4.40 $3.67 - + Add to cart
37	PROTECTOR 2 Part #: 3C3-22826-00-00 Required per assembly: 1 $3.89 $3.24 - + Add to cart
38	RIVET, SPEC'L, SHAPE Part #: 90269-07076-00 Required per assembly: 2 $8.49 $5.88 - + Add to cart
39	BOLT, FLANGE Part #: 95817-06025-00 Required per assembly: 2 $1.75 $1.44 - + Add to cart
40	BOLT, FLANGE Part #: 95817-06014-00 Required per assembly: 2 $2.79 $2.10 - + Add to cart
41	BOLT, FLANGE Part #: 95817-08012-00 Required per assembly: 2 $5.49 $3.90 - + Add to cart
42	GUARD, MUD Part #: 2D1-21629-10-00 Required per assembly: 1 $52.90 - + Add to cart
43	BRACKET, REAR, STAY Part #: 2D1-21688-02-00 Required per assembly: 1 $199.99 $171.58 - + Add to cart
44	GROMMET Part #: 90480-13004-00 Required per assembly: 2 $8.99 $5.97 - + Add to cart
45	CLAMP Part #: 90464-16021-00 Required per assembly: 1 $13.49 $10.66 - + Add to cart
46	SCREW, TAPPING Part #: 97702-50016-00 Required per assembly: 6 $2.60 $1.95 - + Add to cart
47	REAR REFLECTOR ASSEMBLY Part #: 3Y6-85130-02-00 Required per assembly: 1 $30.98 $22.33 - + Add to cart
48	WASHER, PLATE Part #: 90201-05043-00 Required per assembly: 1 $8.49 $5.16 - + Add to cart
49	NUT, U Part #: 95617-05100-00 Required per assembly: 1 $10.49 $6.55 - + Add to cart
50	BRACKET, REAR, STAY Part #: 5VY-21688-00-00 Required per assembly: 1 $8.99 $7.44 - + Add to cart
51	BRACKET, REAR, STAY, 2 Part #: 5VY-21689-00-00 Required per assembly: 1 $8.99 $7.44 - + Add to cart
52	SCREW, ROUND, HEAD(4KM) Part #: 90150-04041-00 Required per assembly: 4 $0.50 $0.41 - + Add to cart
53	NUT, U, (7LY) Part #: 95617-04100-00 Required per assembly: 4 $10.49 $6.80 - + Add to cart
54	REAR REFLECTOR ASSEMBLY Part #: 3Y6-85130-02-00 Required per assembly: 2 $30.98 $22.33 - + Add to cart
55	NUT, WITH, WASHER Part #: 95702-05500-00 Required per assembly: 2 $0.28 $0.25 - + Add to cart
56	BRACKET, LICENSE Part #: 39P-84751-00-00 Required per assembly: 1 $31.98 $22.01 - + Add to cart
57	WASHER, PLATE Part #: 90201-06088-00 Required per assembly: 2 $9.49 $6.15 - + Add to cart
58	NUT, SELF-LOCKING Part #: 95617-06100-00 Required per assembly: 2 $2.89 $2.28 - + Add to cart
59	BOLT, FLANGE, (4LN) Part #: 95817-08025-00 Required per assembly: 4 $9.49 $6.05 - + Add to cart
60	BRACKET, REAR, FENDER Part #: 3C3-21261-00-00 Required per assembly: 1 $261.99 $235.83 - + Add to cart
61	BOLT, FLANGE Part #: 95817-06020-00 Required per assembly: 4 $3.50 $2.65 - + Add to cart
62	FENDER, REAR Part #: 3C3-21611-00-00 Required per assembly: 1 $78.98 $67.00 - + Add to cart
63	RIVET Part #: 90269-07077-00 Required per assembly: 8 $9.49 $6.80 - + Add to cart
64	TOOL KIT Part #: 39P-28100-01-00 Required per assembly: 1 $93.98 $84.55 - + Add to cart
65	TUNING FORK MARK Part #: 4KN-2836B-00-00 Required per assembly: 1 $21.98 $16.92 - + Add to cart
66	LABEL, CAUTION Part #: 3JJ-28446-A1-00 Required per assembly: 1 $8.49 $6.79 - + Add to cart
67	LABEL, CAUTION Part #: 3TB-24877-A0-00 Required per assembly: 1 $5.49 $4.51 - + Add to cart
