Frame replacement parts for 2012 Yamaha Raptor (YFM25RBW 1BTF0 2012)

OEM Parts Yamaha 2012 Yamaha Raptor (YFM25RBW 1BTF0 2012) Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: 4D3-21110-10-P0 Required per assembly: 1 Note: S8(SILVER 8) FOR DPBSE(DEEP PURPLISH BLUE SOLID E) Not Available
2	STAY, ENGINE, 2 Part #: 4D3-21315-00-00 Required per assembly: 1 $24.98 $18.14 - + Add to cart
4	BOLT, FLANGE Part #: 90105-10221-00 Required per assembly: 1 $6.49 $5.13 - + Add to cart
5	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 1 $2.70 $2.25 - + Add to cart
6	STAY, ENGINE, 3 Part #: 4D3-21316-00-00 Required per assembly: 2 $17.98 $12.85 - + Add to cart
8	BOLT, FLANGE Part #: 90105-10220-00 Required per assembly: 1 $11.49 $8.66 - + Add to cart
9	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 1 $2.70 $2.25 - + Add to cart
10	BOLT, FLANGE Part #: 90105-10219-00 Required per assembly: 1 $8.49 $5.64 - + Add to cart
11	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 1 $2.70 $2.25 - + Add to cart
12	BOLT, FLANGE Part #: 90105-10214-00 Required per assembly: 1 $11.49 $8.63 - + Add to cart
13	NUT, SELF-LOCKING Part #: 95602-10200-00 Required per assembly: 1 $2.70 $2.25 - + Add to cart
14	PLUG, SPEC'L, SHAPE Part #: 90338-16148-00 Required per assembly: 4 $12.49 $9.80 - + Add to cart
15	BUSH, SOLID Part #: 90381-15040-00 Required per assembly: 2 $32.99 $23.13 - + Add to cart
16	O-RING (22U) Part #: 93210-15566-00 Required per assembly: 2 Note: Sold in multiples of 5 only $8.49 $5.67 - + Add to cart
17	NIPPLE, GREASE(6A1) Part #: 93700-06M03-00 Required per assembly: 1 $8.49 $8.30 - + Add to cart
18	TENSIONER Part #: 4D3-22178-00-00 Required per assembly: 1 $12.99 $10.22 - + Add to cart
19	WASHER, PLATE Part #: 90201-08054-00 Required per assembly: 1 $9.49 $6.17 - + Add to cart
20	BOLT, FLANGE Part #: 95817-08012-00 Required per assembly: 1 $5.49 $3.90 - + Add to cart
21	PROTECTOR, ENGINE Part #: 4D3-21471-00-00 Required per assembly: 1 $38.99 $33.02 - + Add to cart
22	BOLT Part #: 90109-06172-00 Required per assembly: 4 $3.50 $2.66 - + Add to cart
23	STAY 2 Part #: 4D3-2137G-00-00 Required per assembly: 1 Not Available
24	BOLT Part #: 90109-06172-00 Required per assembly: 2 $3.50 $2.66 - + Add to cart
25	PAD, SEAT Part #: 3C3-24741-00-00 Required per assembly: 2 $10.99 $8.18 - + Add to cart
26	TOOL KIT Part #: 4D3-28100-01-00 Required per assembly: 1 $38.99 $33.85 - + Add to cart
27	GAUGE, AIR Part #: 1NV-2811A-01-00 Required per assembly: 1 $62.99 $49.61 - + Add to cart
