Frame replacement parts for 2012 Yamaha Road Star S (XV17ASBCB)

OEM Parts Yamaha 2012 Yamaha Road Star S (XV17ASBCB) Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: 5VN-21110-20-00 Required per assembly: 1 $2,757.46 - + Add to cart
2	REAR FRAME COMP. Part #: 5VN-21190-00-00 Required per assembly: 1 $379.99 $347.82 - + Add to cart
3	BOLT, FLANGE Part #: 90105-12016-00 Required per assembly: 1 $13.49 $11.07 - + Add to cart
4	NUT, SELF-LOCKING Part #: 90185-12002-00 Required per assembly: 1 $13.49 $9.87 - + Add to cart
5	BOLT, FLANGE Part #: 95817-10035-00 Required per assembly: 2 $9.49 $6.43 - + Add to cart
6	BRACKET Part #: 5VN-2115C-00-00 Required per assembly: 1 $11.49 $9.63 - + Add to cart
7	BOLT, FLANGE Part #: 90105-12087-00 Required per assembly: 2 $22.98 $18.05 - + Add to cart
8	BOLT, HEXAGON Part #: 97027-05010-00 Required per assembly: 2 $8.49 $5.50 - + Add to cart
9	WASHER, PLATE Part #: 92907-05600-00 Required per assembly: 2 $1.00 $0.77 - + Add to cart
10	CAP Part #: 4WM-21399-00-00 Required per assembly: 1 $4.40 $3.67 - + Add to cart
11	BRACKET, SEAT Part #: 5VN-2134M-00-00 Required per assembly: 1 $11.99 $9.84 - + Add to cart
12	BOLT, HEXAGON Part #: 97027-05010-00 Required per assembly: 2 $8.49 $5.50 - + Add to cart
13	WASHER, PLATE Part #: 92907-05600-00 Required per assembly: 2 $1.00 $0.77 - + Add to cart
14	BOLT, FLANGE Part #: 90105-12689-00 Required per assembly: 1 Not Available
15	BOLT, FLANGE Part #: 90105-126A6-00 Required per assembly: 1 $23.98 $18.22 - + Add to cart
16	NUT, SELF-LOCKING Part #: 95607-12200-00 Required per assembly: 4 $6.49 $5.32 - + Add to cart
17	STAY, ENGINE, 5 Part #: 4WM-21314-00-00 Required per assembly: 2 $18.48 $15.23 - + Add to cart
18	BOLT, FLANGE, (3GD) Part #: 95817-10025-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
19	BOLT, FLANGE, (3HP) Part #: 95817-10016-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
20	STAY, ENGINE, 2 Part #: 4WM-21315-00-00 Required per assembly: 1 $17.48 $14.36 - + Add to cart
21	STAY, ENGINE, 3 Part #: 4WM-21316-00-00 Required per assembly: 1 $17.98 $14.74 - + Add to cart
22	BOLT, FLANGE Part #: 90105-10737-00 Required per assembly: 2 $12.99 $9.63 - + Add to cart
23	NUT, SELF-LOCKING, (JN5) Part #: 95607-10200-00 Required per assembly: 2 $4.15 $3.27 - + Add to cart
24	CAP Part #: 5YU-2143A-00-00 Required per assembly: 2 Not Available
25	STAY, ENGINE, 3 Part #: 5VN-21317-10-00 Required per assembly: 1 $223.99 $209.93 - + Add to cart
26	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-10047-00 Required per assembly: 2 $4.54 $3.78 - + Add to cart
27	BOLT, FLANGE Part #: 95817-10035-00 Required per assembly: 2 $9.49 $6.43 - + Add to cart
28	STAY 1 Part #: 5VN-2137F-00-00 Required per assembly: 1 $18.98 $15.76 - + Add to cart
29	BOLT, HEX, SOCKET, BUTTON Part #: 90111-10003-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
30	WASHER, PLATE Part #: 90201-11013-00 Required per assembly: 4 $3.54 $2.84 - + Add to cart
31	PLUG, SPEC'L, SHAPE Part #: 90338-09012-00 Required per assembly: 2 $10.49 $7.12 - + Add to cart
32	STAY, MUFFLER, 1 Part #: 5MB-21445-00-00 Required per assembly: 1 $143.99 $134.66 - + Add to cart
33	BOLT Part #: 91317-10025-00 Required per assembly: 2 Note: (USA) $9.49 $6.05 - + Add to cart
34	PROTECTOR Part #: 3D8-2117G-00-00 Required per assembly: 1 Not Available
35	STOPPER, MAIN, STAND Part #: 3VR-27114-00-00 Required per assembly: 1 $8.49 $6.41 - + Add to cart
36	SEAL Part #: 5VN-21268-00-00 Required per assembly: 1 Not Available
37	PLATE, CONNECTOR Part #: 5VN-8257V-00-00 Required per assembly: 1 $39.99 $34.88 - + Add to cart
38	BOLT, BUTTON, HEAD Part #: 92017-06020-00 Required per assembly: 2 $4.04 $2.51 - + Add to cart
39	CLAMP Part #: 90464-07001-00 Required per assembly: 2 Note: (USA) $2.39 $2.00 - + Add to cart
