Front Fork replacement parts for 2012 Yamaha Royal Star VENTURE S (XVZ13TFSBB)

OEM Parts Yamaha 2012 Yamaha Royal Star VENTURE S (XVZ13TFSBB) Front Fork

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (LH) Part #: 4XY-23102-10-00 Required per assembly: 1 $498.81 - + Add to cart
2	INNER TUBE COMP 1 Part #: 4XY-23110-00-00 Required per assembly: 1 $232.99 $218.02 - + Add to cart
3	TUBE, OUTER, (LEFT) Part #: 5MB-23126-00-00 Required per assembly: 1 $1,123.92 $1,021.75 - + Add to cart
4	SPRING, FRONT, FORK Part #: 4XY-23141-00-00 Required per assembly: 1 $57.99 $50.05 - + Add to cart
5	BOLT, CAP Part #: 4XY-23111-10-00 Required per assembly: 1 $138.99 $120.04 - + Add to cart
6	O-RING Part #: 4NK-23147-00-00 Required per assembly: 1 $7.49 $6.35 - + Add to cart
7	SEAL, DUST Part #: 4NK-23144-00-00 Required per assembly: 1 $21.98 $17.80 - + Add to cart
8	RING, SNAP Part #: 34L-23153-00-00 Required per assembly: 1 $21.98 $17.68 - + Add to cart
9	OIL SEAL Part #: 4NK-23145-00-00 Required per assembly: 1 $27.98 $18.67 - + Add to cart
10	WASHER, OIL, SEAL Part #: 4NK-23146-00-00 Required per assembly: 1 $10.99 $9.19 - + Add to cart
11	METAL, SLIDE, 1 Part #: 4NK-23125-00-00 Required per assembly: 1 $25.98 $20.05 - + Add to cart
12	RING, PISTON Part #: 4NK-23157-00-00 Required per assembly: 1 $10.99 $8.81 - + Add to cart
13	SPRING, REBOUND Part #: 4NK-23151-00-00 Required per assembly: 1 Not Available
14	PISTON, FRONT, FORK Part #: 4WM-23171-00-00 Required per assembly: 1 Not Available
15	METAL, SLIDE, 2 Part #: 4NK-23135-00-00 Required per assembly: 1 Not Available
16	SPACER, OIL, LOCK Part #: 4WM-23166-00-00 Required per assembly: 1 $19.48 $15.85 - + Add to cart
17	GASKET, DRAIN, PLUG Part #: 3MA-23163-10-00 Required per assembly: 1 $9.49 $8.12 - + Add to cart
18	BOLT, HEXAGON, SOCKET, HEAD Part #: 4NK-23181-00-00 Required per assembly: 1 $7.49 $5.29 - + Add to cart
19	GUIDE, BOOT Part #: 4NK-23193-00-00 Required per assembly: 1 $22.98 $17.80 - + Add to cart
20	CAP, AIR, VALVE Part #: 4V1-23184-L0-00 Required per assembly: 1 $7.99 $6.55 - + Add to cart
21	FRONT FORK ASSEMBLY (RH) Part #: 4XY-23103-10-00 Required per assembly: 1 $579.58 $536.89 - + Add to cart
22	INNER TUBE COMP 1 Part #: 4XY-23110-00-00 Required per assembly: 1 $232.99 $218.02 - + Add to cart
23	TUBE, OUTER, (RIGHT) Part #: 5MB-23136-00-00 Required per assembly: 1 $1,134.09 $1,030.99 - + Add to cart
24	SPRING, FRONT, FORK Part #: 4XY-23141-00-00 Required per assembly: 1 $57.99 $50.05 - + Add to cart
25	BOLT, CAP Part #: 4XY-23111-10-00 Required per assembly: 1 $138.99 $120.04 - + Add to cart
26	O-RING Part #: 4NK-23147-00-00 Required per assembly: 1 $7.49 $6.35 - + Add to cart
27	SEAL, DUST Part #: 4NK-23144-00-00 Required per assembly: 1 $21.98 $17.80 - + Add to cart
28	RING, SNAP Part #: 34L-23153-00-00 Required per assembly: 1 $21.98 $17.68 - + Add to cart
29	OIL SEAL Part #: 4NK-23145-00-00 Required per assembly: 1 $27.98 $18.67 - + Add to cart
30	WASHER, OIL, SEAL Part #: 4NK-23146-00-00 Required per assembly: 1 $10.99 $9.19 - + Add to cart
31	METAL, SLIDE, 1 Part #: 4NK-23125-00-00 Required per assembly: 1 $25.98 $20.05 - + Add to cart
32	RING, PISTON Part #: 4NK-23157-00-00 Required per assembly: 1 $10.99 $8.81 - + Add to cart
33	SPRING, REBOUND Part #: 4NK-23151-00-00 Required per assembly: 1 Not Available
34	PISTON, FRONT, FORK Part #: 4WM-23171-00-00 Required per assembly: 1 Not Available
35	METAL, SLIDE, 2 Part #: 4NK-23135-00-00 Required per assembly: 1 Not Available
36	SPACER, OIL, LOCK Part #: 4WM-23166-00-00 Required per assembly: 1 $19.48 $15.85 - + Add to cart
37	GASKET, DRAIN, PLUG Part #: 3MA-23163-10-00 Required per assembly: 1 $9.49 $8.12 - + Add to cart
38	BOLT, HEXAGON, SOCKET, HEAD Part #: 4NK-23181-00-00 Required per assembly: 1 $7.49 $5.29 - + Add to cart
39	GUIDE, BOOT Part #: 4NK-23193-00-00 Required per assembly: 1 $22.98 $17.80 - + Add to cart
40	CAP, AIR, VALVE Part #: 4V1-23184-L0-00 Required per assembly: 1 $7.99 $6.55 - + Add to cart
41	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08035-00 Required per assembly: 1 $2.70 $2.51 - + Add to cart
42	UNDER BRACKET COMP. Part #: 4XY-23340-01-00 Required per assembly: 1 $333.83 - + Add to cart
43	BOLT, SOCKET Part #: 91317-08030-00 Required per assembly: 4 $9.49 $6.05 - + Add to cart
44	COVER, UNDER, 1 Part #: 4NK-23123-10-00 Required per assembly: 2 $279.99 $261.71 - + Add to cart
45	BOLT, HEXAGON, SOCKET, HEAD Part #: 4XY-23181-00-00 Required per assembly: 6 $4.59 $3.84 - + Add to cart
46	COVER, UPPER, 1 Part #: 4XY-23121-10-00 Required per assembly: 2 $234.99 $219.48 - + Add to cart
47	GASKET Part #: 4NK-23163-00-00 Required per assembly: 2 $33.99 $23.84 - + Add to cart
48	WASHER, FELT Part #: 4NK-23165-00-00 Required per assembly: 2 $18.98 $15.27 - + Add to cart
