Frame replacement parts for 2012 Yamaha TTR125LE (TTR125LEB)

OEM Parts Yamaha 2012 Yamaha TTR125LE (TTR125LEB) Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: 1B2-F1110-80-00 Required per assembly: 1 Note: 19C3 LEX $1,307.94 - + Add to cart
2	BOLT, FLANGE Part #: 90105-08007-00 Required per assembly: 2 $6.49 $4.28 - + Add to cart
3	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 2 $9.49 $6.97 - + Add to cart
4	STAY, ENGINE, 3 Part #: 1B2-F1316-10-00 Required per assembly: 1 Not Available
5	BOLT, WASHER, BASED Part #: 90105-084A1-00 Required per assembly: 2 $11.49 $9.21 - + Add to cart
6	BOLT, FLANGE Part #: 90105-08011-00 Required per assembly: 2 $6.49 $4.28 - + Add to cart
7	NUT, U Part #: 95617-08100-00 Required per assembly: 4 $10.49 $6.67 - + Add to cart
8	WASHER, PLATE, (3XP) Part #: 90201-086P8-00 Required per assembly: 4 $5.49 $4.28 - + Add to cart
9	STAY, ENGINE, 2 Part #: 1B2-F1315-00-00 Required per assembly: 1 $28.98 $22.77 - + Add to cart
10	BOLT, FLANGE Part #: 90105-082A0-00 Required per assembly: 2 $5.49 $3.08 - + Add to cart
11	BOLT, FLANGE Part #: 90105-08002-00 Required per assembly: 1 $2.64 $2.01 - + Add to cart
12	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 1 $9.49 $6.97 - + Add to cart
13	BUSH Part #: 5RM-F2184-00-00 Required per assembly: 1 $2.35 $1.39 - + Add to cart
14	TENSIONER Part #: 5RM-F2178-00-00 Required per assembly: 1 $10.49 $7.68 - + Add to cart
15	WASHER, PLATE, (8AT) Part #: 90201-081R9-00 Required per assembly: 1 $10.49 $6.21 - + Add to cart
16	BOLT, FLANGE Part #: 95027-08012-00 Required per assembly: 1 $10.49 $6.77 - + Add to cart
17	TENSIONER SET Part #: 99999-04397-00 Required per assembly: 1 $20.98 $16.83 - + Add to cart
18	COLLAR Part #: 90387-067K6-00 Required per assembly: 1 Note: Sold in multiples of 5 only $11.49 $7.30 - + Add to cart
19	BOLT, WITH, WASHER(81H) Part #: 90119-06118-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
20	COVER Part #: 1B2-F117F-00-00 Required per assembly: 1 $38.99 $33.02 - + Add to cart
21	SCREW, BIND, (1JK) Part #: 98980-06010-00 Required per assembly: 2 $9.49 $5.76 - + Add to cart
22	PROTECTOR, ENGINE Part #: 1B2-F1471-00-00 Required per assembly: 1 $24.50 - + Add to cart
23	DAMPER, RUBBER, 1 Part #: 5HP-21485-00-00 Required per assembly: 1 $37.99 $30.39 - + Add to cart
24	SEAL Part #: 1B2-F1268-00-00 Required per assembly: 3 $3.50 $1.78 - + Add to cart
25	BOLT, FLANGE Part #: 95817-06016-00 Required per assembly: 3 $1.95 $1.47 - + Add to cart
26	COLLAR Part #: 90387-06681-00 Required per assembly: 3 $10.49 $6.49 - + Add to cart
27	COVER 4 Part #: 1B2-F117R-00-00 Required per assembly: 1 $1.39 $1.15 - + Add to cart
28	DAMPER, 2 Part #: 1B2-F4849-00-00 Required per assembly: 1 $0.25 $0.20 - + Add to cart
