Electrical 2 replacement parts for 2012 Yamaha YZF-R6 (YZFR6BB)

OEM Parts Yamaha 2012 Yamaha YZF R6 (YZFR6BB) Electrical 2

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	STARTER RELAY ASSEMBLY Part #: 2C0-81940-00-00 Required per assembly: 1 $168.99 $143.82 - + Add to cart
2	FUSE (15A-BLUE) Part #: 36Y-82151-00-00 Required per assembly: 2 $6.49 $3.99 - + Add to cart
3	COVER, LEAD, WIRE Part #: 5SL-82119-10-00 Required per assembly: 1 $5.49 $3.99 - + Add to cart
4	BOLT, FLANGE Part #: 95022-06008-00 Required per assembly: 2 $9.49 $6.15 - + Add to cart
5	YTZ10S YUASA BATTER (YUASA YTZ10S) Part #: YTZ-10S00-00-00 Required per assembly: 1 $242.92 - + Add to cart
6	WIRE HARNESS ASSY Part #: 13S-82590-11-00 Required per assembly: 1 $1,022.29 $944.35 - + Add to cart
7	FUSE (15A) Part #: 67F-82151-50-00 Required per assembly: 5 Note: (15A) (15A) $4.15 $3.93 - + Add to cart
8	FUSE (75A-BL) Part #: 5JJ-82151-00-00 Required per assembly: 3 $7.49 $6.29 - + Add to cart
9	FUSE (10A) Part #: 67F-82151-40-00 Required per assembly: 2 Note: (10A) $7.49 $6.94 - + Add to cart
10	FUSE (50A) Part #: 5JW-82151-10-00 Required per assembly: 1 $17.98 $14.50 - + Add to cart
11	SENSOR, LEAN, ANGLE Part #: 5PS-82576-02-00 Required per assembly: 1 $96.98 $83.11 - + Add to cart
12	BOLT, HEXAGON, SOCKET, HEAD Part #: 91317-04025-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
13	WASHER, PLATE Part #: 90201-043H7-00 Required per assembly: 2 $3.75 $2.51 - + Add to cart
14	RECTIFIER & REGULATOR ASSEMBLY Part #: 4XY-81960-00-00 Required per assembly: 1 $194.99 $166.89 - + Add to cart
15	BOLT, BUTTON, HEAD Part #: 92012-06025-00 Required per assembly: 2 $3.39 $2.83 - + Add to cart
16	CLAMP Part #: 90465-15011-00 Required per assembly: 2 $2.29 $1.92 - + Add to cart
17	BAND Part #: 1UA-82591-00-00 Required per assembly: 2 $5.49 $4.05 - + Add to cart
18	BAND Part #: 1UA-82591-00-00 Required per assembly: 4 $5.49 $4.05 - + Add to cart
19	CLAMP (2TV) Part #: 90464-10112-00 Required per assembly: 2 Note: Sold in multiples of 5 only $9.49 $6.06 - + Add to cart
20	HORN Part #: 4TH-83371-00-00 Required per assembly: 1 $53.99 $45.92 - + Add to cart
21	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 1 $1.95 $1.47 - + Add to cart
22	BRACKET, HORN Part #: 13S-23377-00-00 Required per assembly: 1 $35.99 $25.51 - + Add to cart
23	BOLT, FLANGE Part #: 95817-06020-00 Required per assembly: 2 $3.50 $2.65 - + Add to cart
24	SWITCH, SIDE, STAND Part #: 13S-82566-70-00 Required per assembly: 1 $124.98 $104.81 - + Add to cart
25	BOLT, BUTTON, HEAD Part #: 92012-05025-00 Required per assembly: 2 $3.85 $3.18 - + Add to cart
26	NUT, S/L, FLANGE Part #: 95607-05200-00 Required per assembly: 2 $10.49 $6.73 - + Add to cart
27	BRACKET, SENSOR, 1 Part #: 2C0-27961-00-00 Required per assembly: 1 $36.99 $29.12 - + Add to cart
28	STOP SWITCH ASSY Part #: 13S-82530-02-00 Required per assembly: 1 $44.99 $37.47 - + Add to cart
29	MAIN SWITCH STEERING LOCK Part #: 2C0-82501-10-00 Required per assembly: 1 Not Available
31	BLANK KEY Part #: 4BH-82511-09-00 Required per assembly: 1 Note: AP $33.99 $24.01 - + Add to cart
32	WIRE, MINUS, LEAD Part #: 2C0-82116-00-00 Required per assembly: 1 $21.98 $17.21 - + Add to cart
33	BOLT Part #: 91380-06012-00 Required per assembly: 1 $1.99 $1.81 - + Add to cart
34	BOLT Part #: 90109-08196-00 Required per assembly: 2 $9.49 $6.06 - + Add to cart
