Front Fork replacement parts for 2012 Yamaha YZF-R6 (YZFR6BCL)

OEM Parts Yamaha 2012 Yamaha YZF R6 (YZFR6BCL) Front Fork

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (LH) Part #: 13S-23102-12-00 Required per assembly: 1 Note: FOR BWC1(BLUISH WHITE COCKTAIL 1) $1,146.58 $1,051.34 - + Add to cart
1	FRONT FORK ASSEMBLY (L.H) Part #: 13S-23102-02-00 Required per assembly: 1 $1,007.99 $998.03 - + Add to cart
2	INNER TUBE COMP.1 Part #: 13S-23110-03-00 Required per assembly: 1 $515.27 - + Add to cart
3	OUTER TUBE COMP (LH) Part #: 13S-23106-10-00 Required per assembly: 1 Note: FOR BWC1(BLUISH WHITE COCKTAIL 1) $295.99 $290.06 - + Add to cart
3	OUTER TUBE COMP (LH) Part #: 13S-23106-00-00 Required per assembly: 1 $359.99 $353.75 - + Add to cart
4	GUIDE, COVER, UPPER Part #: 3VD-23115-00-00 Required per assembly: 1 $12.99 $11.10 - + Add to cart
5	OIL SEAL Part #: 5VU-23145-00-00 Required per assembly: 1 $32.99 $25.05 - + Add to cart
6	CLIP, OIL, SEAL Part #: 3VD-23156-00-00 Required per assembly: 1 $8.49 $6.41 - + Add to cart
7	SEAL, DUST Part #: 3VD-23144-00-00 Required per assembly: 1 $30.98 $22.20 - + Add to cart
8	CYLINDER, COMP, FRONT, FORK Part #: 13S-23170-00-00 Required per assembly: 1 $357.99 $350.87 - + Add to cart
9	BOLT, CAP Part #: 13S-23111-00-00 Required per assembly: 1 $303.99 $273.58 - + Add to cart
10	O-RING Part #: 93210-41N50-00 Required per assembly: 1 $9.49 $6.15 - + Add to cart
11	NUT, SPECIAL Part #: 13S-23393-00-00 Required per assembly: 1 $13.49 $11.34 - + Add to cart
13	SEAT, SPRING, LOWER Part #: 2C0-23143-00-00 Required per assembly: 1 $8.49 $6.35 - + Add to cart
14	SPRING, FRONT, FORK Part #: 13S-23141-00-00 Required per assembly: 1 $39.99 $34.85 - + Add to cart
16	SPACER Part #: 13S-23118-00-00 Required per assembly: 1 $8.49 $6.92 - + Add to cart
17	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
18	FRONT FORK ASSEMBLY (RH) Part #: 13S-23103-12-00 Required per assembly: 1 Note: FOR BWC1(BLUISH WHITE COCKTAIL 1) $932.96 $857.14 - + Add to cart
18	FRONT FORK ASSEMBLY (R.H) Part #: 13S-23103-02-00 Required per assembly: 1 $1,007.99 $998.03 - + Add to cart
19	INNER TUBE COMP.2 Part #: 13S-23120-03-00 Required per assembly: 1 $638.99 $636.85 - + Add to cart
20	OUTER TUBE COMP (LH) Part #: 13S-23106-10-00 Required per assembly: 1 Note: FOR BWC1(BLUISH WHITE COCKTAIL 1) $295.99 $290.06 - + Add to cart
20	OUTER TUBE COMP (LH) Part #: 13S-23106-00-00 Required per assembly: 1 $359.99 $353.75 - + Add to cart
21	GUIDE, COVER, UPPER Part #: 3VD-23115-00-00 Required per assembly: 1 $12.99 $11.10 - + Add to cart
22	OIL SEAL Part #: 5VU-23145-00-00 Required per assembly: 1 $32.99 $25.05 - + Add to cart
23	CLIP, OIL, SEAL Part #: 3VD-23156-00-00 Required per assembly: 1 $8.49 $6.41 - + Add to cart
24	SEAL, DUST Part #: 3VD-23144-00-00 Required per assembly: 1 $30.98 $22.20 - + Add to cart
25	CYLINDER, COMP, FRONT, FORK Part #: 13S-23170-00-00 Required per assembly: 1 $357.99 $350.87 - + Add to cart
26	BOLT, CAP Part #: 13S-23111-00-00 Required per assembly: 1 $303.99 $273.58 - + Add to cart
27	O-RING Part #: 93210-41N50-00 Required per assembly: 1 $9.49 $6.15 - + Add to cart
28	NUT, SPECIAL Part #: 13S-23393-00-00 Required per assembly: 1 $13.49 $11.34 - + Add to cart
30	SEAT, SPRING, LOWER Part #: 2C0-23143-00-00 Required per assembly: 1 $8.49 $6.35 - + Add to cart
31	SPRING, FRONT, FORK Part #: 13S-23141-00-00 Required per assembly: 1 $39.99 $34.85 - + Add to cart
33	SPACER Part #: 13S-23118-00-00 Required per assembly: 1 $8.49 $6.92 - + Add to cart
34	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
35	UNDER BRACKET COMP. Part #: 2CX-23340-00-00 Required per assembly: 1 $587.17 - + Add to cart
36	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08030-00 Required per assembly: 4 $2.54 $2.25 - + Add to cart
37	BEARING Part #: 93399-99957-00 Required per assembly: 1 $76.98 $63.61 - + Add to cart
38	SEAL, STEERING Part #: 3FV-23462-00-00 Required per assembly: 1 $26.98 $21.26 - + Add to cart
