Front Fork replacement parts for 2012 Yamaha YZF-R6 (YZFR6BW)

OEM Parts Yamaha 2012 Yamaha YZF R6 (YZFR6BW) Front Fork

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (LH) Part #: 13S-23102-12-00 Required per assembly: 1 Note: FOR BWC1(BLUISH WHITE COCKTAIL 1) ~~$1,028.99~~ $1,004.33 - + Add to cart
2	INNER TUBE COMP.1 Part #: 13S-23110-03-00 Required per assembly: 1 ~~$513.99~~ $506.11 - + Add to cart
3	OUTER TUBE COMP (LH) Part #: 13S-23106-10-00 Required per assembly: 1 Note: FOR BWC1(BLUISH WHITE COCKTAIL 1) ~~$295.99~~ $290.06 - + Add to cart
4	GUIDE, COVER, UPPER Part #: 3VD-23115-00-00 Required per assembly: 1 $14.25 - + Add to cart
5	OIL SEAL Part #: 5VU-23145-00-00 Required per assembly: 1 ~~$32.99~~ $25.92 - + Add to cart
6	CLIP, OIL, SEAL Part #: 3VD-23156-00-00 Required per assembly: 1 $8.76 - + Add to cart
7	SEAL, DUST Part #: 3VD-23144-00-00 Required per assembly: 1 ~~$30.98~~ $24.10 - + Add to cart
8	CYLINDER, COMP, FRONT, FORK Part #: 13S-23170-00-00 Required per assembly: 1 ~~$357.99~~ $350.36 - + Add to cart
9	BOLT, CAP Part #: 13S-23111-00-00 Required per assembly: 1 ~~$303.99~~ $273.58 - + Add to cart
10	O-RING Part #: 93210-41N50-00 Required per assembly: 1 ~~$9.49~~ $8.44 - + Add to cart
11	NUT, SPECIAL Part #: 13S-23393-00-00 Required per assembly: 1 $14.51 - + Add to cart
13	SEAT, SPRING, LOWER Part #: 2C0-23143-00-00 Required per assembly: 1 $8.69 - + Add to cart
14	SPRING, FRONT, FORK Part #: 13S-23141-00-00 Required per assembly: 1 ~~$39.99~~ $34.85 - + Add to cart
16	SPACER Part #: 13S-23118-00-00 Required per assembly: 1 Not Available
17	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 2 ~~$8.49~~ $5.15 - + Add to cart
18	FRONT FORK ASSEMBLY (RH) Part #: 13S-23103-12-00 Required per assembly: 1 Note: FOR BWC1(BLUISH WHITE COCKTAIL 1) ~~$837.99~~ $822.51 - + Add to cart
19	INNER TUBE COMP.2 Part #: 13S-23120-03-00 Required per assembly: 1 ~~$638.99~~ $617.15 - + Add to cart
20	OUTER TUBE COMP (LH) Part #: 13S-23106-10-00 Required per assembly: 1 Note: FOR BWC1(BLUISH WHITE COCKTAIL 1) ~~$295.99~~ $290.06 - + Add to cart
21	GUIDE, COVER, UPPER Part #: 3VD-23115-00-00 Required per assembly: 1 $14.25 - + Add to cart
22	OIL SEAL Part #: 5VU-23145-00-00 Required per assembly: 1 ~~$32.99~~ $25.92 - + Add to cart
23	CLIP, OIL, SEAL Part #: 3VD-23156-00-00 Required per assembly: 1 $8.76 - + Add to cart
24	SEAL, DUST Part #: 3VD-23144-00-00 Required per assembly: 1 ~~$30.98~~ $24.10 - + Add to cart
25	CYLINDER, COMP, FRONT, FORK Part #: 13S-23170-00-00 Required per assembly: 1 ~~$357.99~~ $350.36 - + Add to cart
26	BOLT, CAP Part #: 13S-23111-00-00 Required per assembly: 1 ~~$303.99~~ $273.58 - + Add to cart
27	O-RING Part #: 93210-41N50-00 Required per assembly: 1 ~~$9.49~~ $8.44 - + Add to cart
28	NUT, SPECIAL Part #: 13S-23393-00-00 Required per assembly: 1 $14.51 - + Add to cart
30	SEAT, SPRING, LOWER Part #: 2C0-23143-00-00 Required per assembly: 1 $8.69 - + Add to cart
31	SPRING, FRONT, FORK Part #: 13S-23141-00-00 Required per assembly: 1 ~~$39.99~~ $34.85 - + Add to cart
33	SPACER Part #: 13S-23118-00-00 Required per assembly: 1 Not Available
34	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08040-00 Required per assembly: 2 ~~$8.49~~ $5.15 - + Add to cart
35	UNDER BRACKET COMP. Part #: 2CX-23340-00-00 Required per assembly: 1 ~~$582.99~~ $572.25 - + Add to cart
36	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08030-00 Required per assembly: 4 $3.25 - + Add to cart
37	BEARING Part #: 93399-99957-00 Required per assembly: 1 ~~$76.98~~ $63.61 - + Add to cart
38	SEAL, STEERING Part #: 3FV-23462-00-00 Required per assembly: 1 ~~$26.98~~ $23.44 - + Add to cart
