Fuel Tank replacement parts for 2012 Yamaha YZFR1 (YZFR1BB)

OEM Parts Yamaha 2012 Yamaha YZFR1 (YZFR1BB) Fuel Tank

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FUEL TANK COMP Part #: 14B-WK241-01-P0 Required per assembly: 1 $933.32 $863.47 - + Add to cart
3	MOLD, FUEL, TANK Part #: 1HX-24188-01-00 Required per assembly: 1 $21.98 $17.51 - + Add to cart
4	DAMPER, LOCATING, 3 Part #: 5VY-24183-00-00 Required per assembly: 2 $8.49 $6.41 - + Add to cart
5	BRACKET, FUEL, TANK, 1 Part #: 14B-24191-10-00 Required per assembly: 1 $51.99 $42.79 - + Add to cart
6	DAMPER, LOCATING, 1 Part #: 5VY-24181-00-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
7	GROMMET Part #: 90480-10542-00 Required per assembly: 1 $12.49 $9.65 - + Add to cart
8	HOLDER, CABLE Part #: 14B-21161-00-00 Required per assembly: 1 $15.49 $12.94 - + Add to cart
9	COLLAR Part #: 90387-06143-00 Required per assembly: 2 $8.49 $5.35 - + Add to cart
10	BRACKET, FUEL, TANK, 2 Part #: 14B-24192-10-00 Required per assembly: 1 Not Available
11	DAMPER, LOCATING, 1 Part #: 5VY-24181-00-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
12	GROMMET Part #: 90480-10542-00 Required per assembly: 1 $12.49 $9.65 - + Add to cart
13	HOLDER, CLUTCH, CABLE Part #: 14B-21162-00-00 Required per assembly: 1 $15.49 $12.67 - + Add to cart
14	BOLT, WITH, WASHER Part #: 90119-06262-00 Required per assembly: 2 $9.49 $6.17 - + Add to cart
15	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06378-00 Required per assembly: 1 $6.49 $4.40 - + Add to cart
16	BRACKET, TANK, FITTING Part #: 14B-2413Y-10-00 Required per assembly: 1 $58.99 $50.98 - + Add to cart
17	DAMPER, LOCATING, 3 Part #: 5SL-24183-00-00 Required per assembly: 2 $8.49 $6.31 - + Add to cart
18	COLLAR Part #: 90387-06055-00 Required per assembly: 1 $5.49 $4.49 - + Add to cart
19	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06163-00 Required per assembly: 4 $10.49 $7.53 - + Add to cart
20	CAP ASSEMBLY Part #: 39P-24602-00-00 Required per assembly: 1 $278.99 $250.57 - + Add to cart
21	BOLT, HEXAGON, SOCKET, HEAD, (1FM) Part #: 90110-05112-00 Required per assembly: 3 $10.49 $7.35 - + Add to cart
22	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-05010-00 Required per assembly: 1 $6.49 $4.84 - + Add to cart
23	FUEL PUMP COMP. Part #: 14B-13907-22-00 Required per assembly: 1 Not Available
24	BRACKET, FUEL, PUMP Part #: 13S-24491-00-00 Required per assembly: 1 $44.99 $34.99 - + Add to cart
25	CLAMP 1 Part #: 14B-24135-00-00 Required per assembly: 1 $31.98 $24.33 - + Add to cart
26	BOLT, HEXAGON, SOCKET, HEAD Part #: 91312-05008-00 Required per assembly: 1 $8.49 $5.10 - + Add to cart
27	O-RING Part #: 19B-24486-01-00 Required per assembly: 1 $47.99 $36.68 - + Add to cart
28	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-05028-00 Required per assembly: 6 $9.49 $6.17 - + Add to cart
29	PIPE 2 Part #: 14B-24312-00-00 Required per assembly: 2 Note: FOR CALIFORNIA $60.99 $43.33 - + Add to cart
30	CLAMP Part #: 90464-09M31-00 Required per assembly: 1 $8.49 $5.40 - + Add to cart
31	PIPE 3 Part #: 14B-24313-00-00 Required per assembly: 1 $14.49 $10.25 - + Add to cart
32	PIPE 4 Part #: 14B-24314-00-00 Required per assembly: 1 Not Available
33	CLIP Part #: 90467-090A2-00 Required per assembly: 6 $4.75 $2.45 - + Add to cart
34	COVER, TOP, (BLACK, METALLIC, X) Part #: 14B-2171A-00-P5 Required per assembly: 1 $233.99 $229.82 - + Add to cart
35	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-06233-00 Required per assembly: 1 $9.49 $6.12 - + Add to cart
36	GROMMET Part #: 90480-12023-00 Required per assembly: 1 $9.49 $6.12 - + Add to cart
37	COLLAR Part #: 90387-06203-00 Required per assembly: 1 $9.49 $6.85 - + Add to cart
38	NUT, SPRING Part #: 90183-05074-00 Required per assembly: 2 $11.49 $7.30 - + Add to cart
39	DAMPER, PLATE, 1 Part #: 14B-2414H-00-00 Required per assembly: 1 $10.99 $8.71 - + Add to cart
40	DAMPER, LOCATING, 2 Part #: 4C8-24182-00-00 Required per assembly: 2 $8.49 $6.35 - + Add to cart
41	DAMPER, LOCATING, 1 Part #: 3XV-21778-00-00 Required per assembly: 3 $8.49 $6.27 - + Add to cart
42	DAMPER, LOCATING, 1 Part #: 14B-24181-00-00 Required per assembly: 2 $8.49 $6.35 - + Add to cart
43	BOLT, WITH, WASHER Part #: 90119-05015-00 Required per assembly: 2 $9.49 $6.05 - + Add to cart
44	NUT, SPEC'L, SHAPE Part #: 90179-05523-00 Required per assembly: 2 Note: Sold in multiples of 5 only $7.49 $5.59 - + Add to cart
45	SCREW, BIND Part #: 98902-05014-00 Required per assembly: 2 $1.85 $1.19 - + Add to cart
46	DAMPER, PLATE, 4 Part #: 14B-2414N-20-00 Required per assembly: 1 $64.98 $53.99 - + Add to cart
47	DAMPER, PLATE, 5 Part #: 14B-2414P-20-00 Required per assembly: 1 $39.99 $31.45 - + Add to cart
48	DAMPER, SIDE, COVER Part #: 5PW-2411J-01-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
49	DAMPER, SIDE, COVER Part #: 5PW-2411J-01-00 Required per assembly: 1 $8.49 $6.31 - + Add to cart
50	DAMPER Part #: 5VU-21747-00-00 Required per assembly: 1 $8.49 $6.35 - + Add to cart
51	DAMPER, PLATE, 3 Part #: 14B-2414K-10-00 Required per assembly: 2 $5.49 $2.66 - + Add to cart
52	SEAL Part #: 14B-2414G-00-00 Required per assembly: 2 $10.99 $8.39 - + Add to cart
53	DAMPER, PLATE Part #: 90520-08002-00 Required per assembly: 1 $10.49 $7.88 - + Add to cart
54	EMBLEM Part #: 5SL-2413B-00-00 Required per assembly: 2 $56.99 $45.77 - + Add to cart
55	LABEL, CAUTION Part #: 4C8-2118K-00-00 Required per assembly: 1 $8.49 $6.47 - + Add to cart
70	TANK SIDE COVER ASSEMBLY 1 Part #: 14B-24106-10-00 Required per assembly: 1 $140.99 $120.67 - + Add to cart
71	DAMPER, PLATE, 1 Part #: 2C0-2414H-00-00 Required per assembly: 1 $6.99 $5.32 - + Add to cart
72	DAMPER, PLATE, 2 Part #: 14B-2414J-00-00 Required per assembly: 1 $6.99 $5.40 - + Add to cart
73	DAMPER, PLATE, 2 Part #: 2C0-2414J-00-00 Required per assembly: 1 $6.99 $5.40 - + Add to cart
74	PLUG, SPEC'L, SHAPE Part #: 90338-07180-00 Required per assembly: 1 $8.49 $5.58 - + Add to cart
76	DAMPER, PLATE Part #: 90520-10005-00 Required per assembly: 1 $4.24 $2.62 - + Add to cart
77	SCREW, BIND Part #: 98902-05008-00 Required per assembly: 1 $1.85 $1.21 - + Add to cart
78	TANK SIDE COVER ASSEMBLY 2 Part #: 14B-24108-10-00 Required per assembly: 1 $156.99 $136.43 - + Add to cart
79	DAMPER, PLATE, 1 Part #: 2C0-2414H-00-00 Required per assembly: 1 $6.99 $5.32 - + Add to cart
80	DAMPER, PLATE, 2 Part #: 14B-2414J-00-00 Required per assembly: 1 $6.99 $5.40 - + Add to cart
81	DAMPER, PLATE, 2 Part #: 2C0-2414J-00-00 Required per assembly: 1 $6.99 $5.40 - + Add to cart
82	PLUG, SPEC'L, SHAPE Part #: 90338-07180-00 Required per assembly: 1 $8.49 $5.58 - + Add to cart
84	DAMPER, PLATE Part #: 90520-10005-00 Required per assembly: 1 $4.24 $2.62 - + Add to cart
85	SCREW, BIND Part #: 98902-05008-00 Required per assembly: 1 $1.85 $1.21 - + Add to cart
