Frame replacement parts for 2012 Yamaha Zuma 50 (YW50FBB)

OEM Parts Yamaha 2012 Yamaha Zuma 50 (YW50FBB) Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

2	BOLT, ENGINE, MOUNTING, 1 Part #: 5ST-F1481-00-00 Required per assembly: 1 $8.49 $6.24 - + Add to cart
3	NUT, SELF-LOCKING Part #: 90185-10801-00 Required per assembly: 1 $1.96 $1.42 - + Add to cart
4	BOLT, FLANGE Part #: 95817-10045-00 Required per assembly: 2 $6.99 $4.45 - + Add to cart
5	NUT, SELF-LOCKING, (JN5) Part #: 95607-10200-00 Required per assembly: 2 $4.15 $3.27 - + Add to cart
6	ENGINE BRACKET COMP Part #: 3B3-F1410-00-00 Required per assembly: 1 $45.99 $35.85 - + Add to cart
7	SPACER Part #: 5ST-F1459-00-00 Required per assembly: 1 $3.54 $2.81 - + Add to cart
8	COVER, DUST Part #: 5ST-F7235-00-00 Required per assembly: 2 $0.70 $0.59 - + Add to cart
9	DAMPER Part #: 5ST-F139X-00-00 Required per assembly: 1 $2.35 $1.01 - + Add to cart
13	BOLT, BUTTON, HEAD Part #: 92017-06012-00 Required per assembly: 2 $2.64 $2.01 - + Add to cart
14	BOLT, FLANGE Part #: 95817-08014-00 Required per assembly: 2 $2.50 $1.91 - + Add to cart
16	GROMMET Part #: 90480-01559-00 Required per assembly: 2 $6.49 $4.72 - + Add to cart
