2013 Honda TRX450ER - Generator

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
01

FLYWHEEL

Part #: 31110-HP1-601 Required per assembly: 1
$467.44
$389.75
02

STATOR

Part #: 31120-HP1-601 Required per assembly: 1
$392.36
$327.13
03

CLAMP, WIRE

Part #: 32112-HP1-670 Required per assembly: 1
$5.46
$4.92
04

BOLT, KNOCK, (5MM)

Part #: 90083-GB6-911 Required per assembly: 4
$3.17
$2.94
05

BOLT, SOCKET, (6X30)

Part #: 90117-GB2-000 Required per assembly: 3
$5.44
$4.89
06

WASHER, PLAIN, (12MM)

Part #: 90437-611-000 Required per assembly: 1
$5.61
$5.10
07

NUT, FLANGE, (12MM)

Part #: 94050-12000 Required per assembly: 1
$2.07
$1.91
