Generator replacement parts for 2013 Honda TRX90X

OEM Parts Honda 2013 Honda TRX90X Generator

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

01	FLYWHEEL Part #: 31110-HP2-671 Required per assembly: 1 $195.99 $158.64 - + Add to cart
02	STATOR Part #: 31120-HP2-671 Required per assembly: 1 $201.41 $163.04 - + Add to cart
03	CLAMP Part #: 31141-141-860 Required per assembly: 1 $2.81 $2.61 - + Add to cart
04	CLAMP Part #: 32961-GT0-700 Required per assembly: 1 $3.31 - + Add to cart
05	WASHER (10MM) Part #: 90410-HC4-000 Required per assembly: 1 $5.18 $4.71 - + Add to cart
06	BOLT, HEX., (5X6) Part #: 93301-05006-0H Required per assembly: 1 $1.71 $1.57 - + Add to cart
07	BOLT, HEX., (5X10) Part #: 93301-05010-0H Required per assembly: 2 $1.71 $1.57 - + Add to cart
08	NUT, FLANGE, (10MM) Part #: 94050-10000 Required per assembly: 1 $2.60 $2.41 - + Add to cart
09	BOLT, FLANGE, (6X16) Part #: 96001-06016-00 Required per assembly: 1 $2.09 $1.93 - + Add to cart
10	BOLT, FLANGE, (6X22) Part #: 96001-06022-00 Required per assembly: 2 $2.27 $2.10 - + Add to cart
