OEM Parts Suzuki 2013 Suzuki Burgman (AN400A, ZA) Magneto

2013 Suzuki Burgman (AN400A, ZA) - Magneto

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
1

NUT

Part #: 31792-18A00 Required per assembly: 1 Note: NUT, MAGNETO;
$12.82
$11.54
-
+
Add to cart
3

ROTOR, ASSEMBLY, MAGNETO

Part #: 32102-15G30 Required per assembly: 1
Not Available
4

CLAMP, MAGNETO, NO.2

Part #: 32371-32E00 Required per assembly: 1
$6.81
$6.13
-
+
Add to cart
5

BOLT, PULSER/CLAMP

Part #: 07130-0512A Required per assembly: 2 Note: SCREW, PULSER COIL;
$2.64
$2.38
-
+
Add to cart
6

BOLT

Part #: 07130-0630A Required per assembly: 3
$3.91
$3.52
-
+
Add to cart
7

KEY

Part #: 09420-04008 Required per assembly: 1
$4.16
$3.74
-
+
Add to cart
8

CLAMP (L:235)

Part #: 09407-25401 Required per assembly: 1
$5.68
$5.11
-
+
Add to cart
