Front Fork Bracket replacement parts for 2013 Suzuki DR-Z400SM

OEM Parts Suzuki 2013 Suzuki DR Z400SM Front Fork Bracket

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BRACKET, UNDER Part #: 51410-29F70 Required per assembly: 1 $1,069.52 $962.57 - + Add to cart
2	BEARING Part #: 09265-30035 Required per assembly: 1 $56.89 $51.20 - + Add to cart
3	BOLT Part #: 51166-35F00 Required per assembly: 4 Note: BOLT, AXLE HOLDER; $9.26 $8.33 - + Add to cart
4	GUIDE, FR, BRAKE, HOSE Part #: 58621-29F00 Required per assembly: 1 $15.82 $14.24 - + Add to cart
5	BOLT, GUIDE Part #: 09111-06087 Required per assembly: 1 Note: BOLT; $3.20 $2.88 - + Add to cart
6	BRACKET, UPPER Part #: 51311-29F70 Required per assembly: 1 $507.33 $456.60 - + Add to cart
7	BOLT Part #: 51166-35F00 Required per assembly: 4 Note: BOLT, AXLE HOLDER; $9.26 $8.33 - + Add to cart
8	GUIDE, CABLE Part #: 51280-29F00 Required per assembly: 1 $28.60 $25.74 - + Add to cart
9	HOLDER, HANDLE, UPPER Part #: 56211-29FA0 Required per assembly: 1 $104.01 $93.61 - + Add to cart
10	HOLDER, HANDLE, LOWER Part #: 56221-35G00 Required per assembly: 2 Note: HOLDER, HANDLE, UNDER; $62.79 $56.51 - + Add to cart
11	CUSHION, RUBBER, UPPER Part #: 56241-42AE1 Required per assembly: 2 $36.71 $31.38 - + Add to cart
12	CUSHION, RUBBER, UNDER Part #: 56242-28C61 Required per assembly: 2 $37.95 $32.43 - + Add to cart
13	SPACER Part #: 56243-42A00 Required per assembly: 2 $8.68 $7.81 - + Add to cart
14	BOLT Part #: 56321-35G00 Required per assembly: 2 $7.42 $6.68 - + Add to cart
15	NUT Part #: 08319-31107 Required per assembly: 2 Note: NUT, FR DIFFERENTIAL; $3.28 $2.95 - + Add to cart
16	BOLT Part #: 51166-35F00 Required per assembly: 4 Note: BOLT, AXLE HOLDER; $9.26 $8.33 - + Add to cart
17	WASHER, STEM, HEAD Part #: 51356-29E00 Required per assembly: 1 Note: WASHER; $19.43 $16.60 - + Add to cart
18	NUT Part #: 51353-27G00 Required per assembly: 1 Note: MODEL K9 $36.52 $32.87 - + Add to cart
19	BEARING Part #: 09265-30035 Required per assembly: 1 $56.89 $51.20 - + Add to cart
20	NUT, STEERING Part #: 51631-28E00 Required per assembly: 1 Note: NUT, STEM; $31.20 $28.08 - + Add to cart
21	LOCK, ASSEMBLY, STEER Part #: 51900-29F00 Required per assembly: 1 $222.46 $200.21 - + Add to cart
22	CAP, STEERING, LO Part #: 51912-29F00 Required per assembly: 1 $6.74 $6.07 - + Add to cart
23	PIN, STEERING, LO Part #: 51913-29F00 Required per assembly: 1 $5.42 $4.88 - + Add to cart
24	WASHER, STEERING Part #: 51914-29F00 Required per assembly: 1 $5.21 $4.69 - + Add to cart
25	SPRING, STEERING Part #: 51931-29F00 Required per assembly: 1 $4.70 $4.23 - + Add to cart
26	BRACKET, HEADLAMP, HSG, R Part #: 51530-29F10 Required per assembly: 1 $66.04 $56.46 - + Add to cart
27	BRACKET, HEADLAMP, HSG, L Part #: 51540-29F10 Required per assembly: 1 $66.04 $59.44 - + Add to cart
28	DAMPER, UPPER Part #: 51553-29F10 Required per assembly: 2 $11.41 $10.27 - + Add to cart
29	DAMPER, LOWER Part #: 51553-29F20 Required per assembly: 2 $11.41 $10.27 - + Add to cart
