Fuel Tank replacement parts for 2013 Yamaha 242 Limited S California SXT1800KLM

OEM Parts Yamaha 2013 Yamaha 242 Limited S California SXT1800KLM Fuel Tank

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FUEL PUMP COMP. Part #: 6AP-13907-05-00 Required per assembly: 2 $1,192.49 $1,181.30 - + Add to cart
2	TANK, FUEL Part #: F2J-U7711-01-00 Required per assembly: 1 $861.04 - + Add to cart
3	PACKING, SEAL Part #: F1B-67747-00-00 Required per assembly: 2 $24.93 $22.66 - + Add to cart
4	RING Part #: F1B-U7773-00-00 Required per assembly: 2 $31.60 $23.42 - + Add to cart
5	SCREW Part #: 90149-14SC7-00 Required per assembly: 16 $6.11 $1.66 - + Add to cart
6	PAD, FUEL, TANK Part #: F2A-U6632-00-00 Required per assembly: 22 $7.12 $2.72 - + Add to cart
7	MAT, WATER, LOCK Part #: GJ3-U755J-00-00 Required per assembly: 2 $115.25 $90.70 - + Add to cart
8	FIX, FUEL, TANK Part #: F1T-U777B-00-00 Required per assembly: 2 $98.93 $84.58 - + Add to cart
9	BOLT Part #: 90101-08802-00 Required per assembly: 4 $1.16 $0.98 - + Add to cart
10	WASHER, PLATE Part #: 9299R-08600-00 Required per assembly: 4 Note: Sold in multiples of 10 only $7.12 $2.27 - + Add to cart
11	CANNISTER, FUEL Part #: F2J-U775L-00-00 Required per assembly: 1 $354.94 $297.75 - + Add to cart
12	BRACKET, FILTER Part #: F2D-U781E-00-00 Required per assembly: 2 $44.86 $31.72 - + Add to cart
13	BOLT Part #: 90101-04S10-00 Required per assembly: 2 $6.11 $2.48 - + Add to cart
14	WASHER Part #: 90209-14SA5-00 Required per assembly: 2 $0.46 $0.38 - + Add to cart
15	NUT, SELF-LOCKING Part #: 90185-14S00-00 Required per assembly: 2 $5.08 $0.68 - + Add to cart
16	SCREW Part #: 90149-10S20-00 Required per assembly: 8 $8.15 $3.61 - + Add to cart
17	WASHER Part #: 90209-10SB1-00 Required per assembly: 8 $6.11 $1.29 - + Add to cart
18	NUT, SELF-LOCKING Part #: 90185-10S00-00 Required per assembly: 8 $5.08 $1.06 - + Add to cart
19	FUEL FILLER ASSEMBLY Part #: F2J-U783E-20-00 Required per assembly: 1 $167.27 $123.95 - + Add to cart
20	SCREW, 8-32, X, 1 Part #: 90157-08S16-00 Required per assembly: 4 $4.07 $0.60 - + Add to cart
21	WASHER, #8, FLAT Part #: 90201-08S00-00 Required per assembly: 4 $4.07 $0.60 - + Add to cart
22	NUT, SELF-LOCKING Part #: 90185-08S00-00 Required per assembly: 4 $7.12 $1.59 - + Add to cart
23	PACKING FUEL FILLER Part #: F2J-U7834-00-00 Required per assembly: 1 $15.28 $11.32 - + Add to cart
24	HOSE Part #: F2D-U7844-10-00 Required per assembly: 1 Not Available
25	HOSE CLAMP ASSEMBLY Part #: 90450-57802-00 Required per assembly: 4 $4.99 $3.18 - + Add to cart
26	CHECK VALVE Part #: F2J-U7767-00-00 Required per assembly: 1 $52.00 $40.79 - + Add to cart
27	HOSE Part #: F2J-U7844-00-00 Required per assembly: 1 $27.53 $21.15 - + Add to cart
28	HOSE CLAMP ASSEMBLY Part #: 90450-57802-00 Required per assembly: 4 $4.99 $3.18 - + Add to cart
29	CLAMP Part #: 90464-99806-00 Required per assembly: 1 $7.12 $2.86 - + Add to cart
30	SCREW, #10, X, 3/4 Part #: 90167-10S12-00 Required per assembly: 1 $6.11 $1.29 - + Add to cart
31	PROTECTOR TUBE Part #: F2J-U1489-00-00 Required per assembly: 1 $56.09 $48.35 - + Add to cart
32	AIR VENT Part #: F2J-U7850-00-00 Required per assembly: 1 $73.43 $57.44 - + Add to cart
33	HOSE, AIR, VENT, 3 Part #: F2D-U7856-30-00 Required per assembly: 1 Not Available
34	HOSE CLAMP ASSEMBLY Part #: 90450-27801-00 Required per assembly: 2 $4.07 $3.46 - + Add to cart
35	HOSE, AIR, VENT, 3 Part #: F2D-U7856-20-00 Required per assembly: 1 $49.96 $48.35 - + Add to cart
36	PROTECTOR, HOSE Part #: F2J-U773J-20-00 Required per assembly: 1 $7.12 $5.22 - + Add to cart
37	HOSE CLAMP ASSEMBLY Part #: 90450-27801-00 Required per assembly: 2 $4.07 $3.46 - + Add to cart
38	AIR VENT Part #: F2J-U7744-10-00 Required per assembly: 1 Not Available
39	PACKING, AIR, VENT Part #: F2J-U7852-10-00 Required per assembly: 1 $32.63 $23.42 - + Add to cart
40	SCREW, SPECIAL, SHAPE Part #: 90149-10SA4-00 Required per assembly: 6 $8.15 $2.86 - + Add to cart
41	HOSE, AIR, VENT, 3 Part #: F2J-U785H-00-00 Required per assembly: 1 $5.59 $3.99 - + Add to cart
42	BAND, HOSE, 18 Part #: 90601-118UF-00 Required per assembly: 2 Note: Sold in multiples of 5 only $7.12 $2.34 - + Add to cart
43	AIR VENT Part #: F2J-U7744-01-00 Required per assembly: 2 $125.45 $93.73 - + Add to cart
44	PACKING, AIR, VENT Part #: F2J-U7852-00-00 Required per assembly: 2 $32.63 $23.42 - + Add to cart
45	SCREW, SPECIAL, SHAPE Part #: 90149-10SA4-00 Required per assembly: 12 $8.15 $2.86 - + Add to cart
46	HOSE, AIR, VENT Part #: F2J-U785G-00-00 Required per assembly: 1 $10.18 $7.56 - + Add to cart
47	BAND, HOSE, 18 Part #: 90601-118UF-00 Required per assembly: 2 Note: Sold in multiples of 5 only $7.12 $2.34 - + Add to cart
48	PROTECTOR, HOSE Part #: F2J-U773J-00-00 Required per assembly: 1 $4.74 $3.70 - + Add to cart
49	ELBOW, AIR, VENT Part #: F2J-U7855-10-00 Required per assembly: 1 $40.78 $28.70 - + Add to cart
50	HOSE AIR VENT Part #: F2J-U785J-00-00 Required per assembly: 1 $11.72 $9.06 - + Add to cart
51	BAND, HOSE, 18 Part #: 90601-118UF-00 Required per assembly: 2 Note: Sold in multiples of 5 only $7.12 $2.34 - + Add to cart
52	PROTECTOR, HOSE Part #: F2J-U773J-10-00 Required per assembly: 1 $5.04 $3.93 - + Add to cart
53	SENDER, FUEL Part #: F2A-U824B-00-00 Required per assembly: 1 $186.65 $145.12 - + Add to cart
54	PACKING Part #: F1C-U775E-00-00 Required per assembly: 1 $18.35 $14.35 - + Add to cart
55	SCREW, SPECIAL, SHAPE Part #: 90149-10SA4-00 Required per assembly: 5 $8.15 $2.86 - + Add to cart
56	GROMMET Part #: F1C-U136D-10-00 Required per assembly: 2 $6.11 $2.48 - + Add to cart
57	HOLDER, PIPE, 1 Part #: F1C-U781B-00-00 Required per assembly: 2 $1.94 $1.51 - + Add to cart
58	SCREW, SPECIAL, SHAPE Part #: 90149-10S06-00 Required per assembly: 2 $0.30 $0.21 - + Add to cart
59	PACKING 7 Part #: F2D-U266F-10-00 Required per assembly: 1 $11.21 $6.35 - + Add to cart
