Upper Casing replacement parts for 2013 Yamaha F30LA / F30LEHA

OEM Parts Yamaha 2013 Yamaha F30LA / F30LEHA Upper Casing

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	GUIDE, EXHAUST, (6BG-00) Part #: 99999-04324-00 Required per assembly: 1 $656.95 $610.22 - + Add to cart
2	ANODE Part #: 62Y-11325-00-00 Required per assembly: 1 Note: ((VZ)) $12.46 $11.32 - + Add to cart
3	GROMMET, ANODE Part #: 66M-11328-01-00 Required per assembly: 1 $1.39 $1.36 - + Add to cart
4	ANODE COVER Part #: 66M-11327-00-94 Required per assembly: 1 Note: ((VZ)) [ANODE COVER] $10.99 $10.57 - + Add to cart
5	PLATE Part #: 66M-12535-00-00 Required per assembly: 1 Note: ((VZ)) $6.49 $6.18 - + Add to cart
6	BOLT (6A4) Part #: 97095-05012-00 Required per assembly: 1 $1.75 $1.44 - + Add to cart
7	WASHER, PLAIN, (646) Part #: 92990-05600-00 Required per assembly: 1 $0.75 $0.42 - + Add to cart
8	BOLT (661) Part #: 97013-06020-00 Required per assembly: 1 $1.55 $1.30 - + Add to cart
9	WASHER, PLATE Part #: 92990-06600-00 Required per assembly: 1 Note: Sold in multiples of 5 only $2.95 - + Add to cart
10	OIL SEAL Part #: 93110-16004-00 Required per assembly: 1 $15.99 $15.86 - + Add to cart
11	GASKET, EXHAUST, MANIFOLD, 1 Part #: 64J-41133-10-00 Required per assembly: 1 $9.49 $9.06 - + Add to cart
12	MANIFOLD, EXT., 1 Part #: 6BG-41131-A0-CA Required per assembly: 1 $114.98 $110.35 - + Add to cart
13	BOLT Part #: 97080-06050-00 Required per assembly: 3 $5.99 $5.59 - + Add to cart
14	WASHER, PLATE Part #: 92990-06600-00 Required per assembly: 3 Note: Sold in multiples of 5 only $2.95 - + Add to cart
15	GASKET 1 Part #: 64J-46132-10-00 Required per assembly: 1 $66.98 $63.49 - + Add to cart
16	GASKET, EXHAUST, MANIFOLD Part #: 6BG-41134-00-00 Required per assembly: 2 $13.99 $13.59 - + Add to cart
17	PLATE Part #: 6BG-45181-00-CA Required per assembly: 1 $113.98 $110.35 - + Add to cart
18	MUFFLER 1 Part #: 69W-14711-00-CA Required per assembly: 1 Note: L(21.0") $204.49 $185.90 - + Add to cart
19	BOLT, HEXAGON, W/W, DEEP, RECESS Part #: 97E75-06525-00 Required per assembly: 6 $1.33 $1.21 - + Add to cart
20	GASKET, MUFFLER Part #: 67C-45123-00-00 Required per assembly: 1 $15.99 $15.86 - + Add to cart
21	SEAL Part #: 62Y-45127-01-00 Required per assembly: 1 $2.95 - + Add to cart
22	GUIDE 1 Part #: 64J-77123-00-00 Required per assembly: 1 $6.49 $6.11 - + Add to cart
23	CASING, UPPER Part #: 6BG-45111-10-8D Required per assembly: 1 Note: L(21.0") $1,057.78 $988.62 - + Add to cart
24	BOLT, WITH, WASHER Part #: 90119-08182-00 Required per assembly: 4 $5.49 $4.97 - + Add to cart
25	BOLT, WITH, WASHER Part #: 90119-08132-00 Required per assembly: 8 $7.04 $6.65 - + Add to cart
26	COVER, UPPER, CASIN Part #: 67C-45151-00-00 Required per assembly: 1 $11.99 $11.32 - + Add to cart
27	SCREW, WITH, WASHER Part #: 97980-05216-00 Required per assembly: 2 $14.22 - + Add to cart
28	CAP Part #: 6C5-45155-01-00 Required per assembly: 1 Not Available
29	BUSHING, DRIVE, SHAFT, 3 Part #: 679-45318-00-00 Required per assembly: 1 Note: L(21.0") $23.98 $22.66 - + Add to cart
30	COLLAR Part #: 90387-23002-00 Required per assembly: 1 Note: L(21.0") $9.96 $9.06 - + Add to cart
31	CIRCLIP, R-TYPE Part #: 93420-36M01-00 Required per assembly: 1 Note: (X(150)) [CIRCLIP,R-TYPE] $11.49 $11.32 - + Add to cart
32	PLUG, STRAGHT, SCREW Part #: 90340-14M06-00 Required per assembly: 1 $14.49 $14.35 - + Add to cart
33	GASKET Part #: 90430-14M09-00 Required per assembly: 1 $2.64 $2.57 - + Add to cart
