Upper Casing replacement parts for 2013 Yamaha F50LB / F50LHB

OEM Parts Yamaha 2013 Yamaha F50LB / F50LHB Upper Casing

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	GUIDE, EXHAUST Part #: 6C5-41137-03-00 Required per assembly: 1 $387.51 $365.28 - + Add to cart
2	OIL SEAL Part #: 93103-18011-00 Required per assembly: 1 $38.99 $37.77 - + Add to cart
3	PIN, DOWEL Part #: 93608-12M05-00 Required per assembly: 2 Note: ((150)) [PIN,DOWEL] Sold in multiples of 5 only $10.99 $10.57 - + Add to cart
4	GASKET, EXHAUST, MANIFOLD, 1 Part #: 6C5-41133-00-00 Required per assembly: 1 $4.59 $4.46 - + Add to cart
5	MANIFOLD, EXT., 1 Part #: 6C5-41131-00-CA Required per assembly: 1 $367.55 $334.14 - + Add to cart
6	GASKET 1 Part #: 6C5-46132-00-00 Required per assembly: 1 $34.99 $33.23 - + Add to cart
7	BOLT, WITH, WASHER Part #: 90119-06261-00 Required per assembly: 3 $6.49 $6.18 - + Add to cart
8	GASKET, EXHAUST, MANIFOLD Part #: 6C5-41134-00-00 Required per assembly: 1 $20.98 $20.40 - + Add to cart
9	PLATE Part #: 6C5-45181-00-CA Required per assembly: 1 $93.98 $90.70 - + Add to cart
10	PIN, DOWEL Part #: 93604-10M03-00 Required per assembly: 2 Note: Sold in multiples of 5 only $5.49 $5.22 - + Add to cart
11	GASKET, EXHAUST, MANIFOLD Part #: 6C5-41135-00-00 Required per assembly: 1 $14.49 $13.59 - + Add to cart
12	MUFFLER 1 Part #: 6C5-14711-00-CA Required per assembly: 1 $289.38 $263.07 - + Add to cart
13	BOLT, HEXAGON, W/W, DEEP, RECESS Part #: 97E75-06525-00 Required per assembly: 6 $1.33 $1.21 - + Add to cart
14	GASKET, MUFFLER Part #: 6C5-45123-00-00 Required per assembly: 1 $16.98 $16.62 - + Add to cart
15	BOLT, WITH, WASHER Part #: 90119-08182-00 Required per assembly: 4 $5.49 $4.97 - + Add to cart
16	BOLT, WITH, WASHER Part #: 90119-08132-00 Required per assembly: 8 $7.04 $6.65 - + Add to cart
17	CAP Part #: 6C5-45155-01-00 Required per assembly: 1 Not Available
18	BUSHING, DRIVE, SHAFT Part #: 69W-45318-00-00 Required per assembly: 1 $65.98 $63.49 - + Add to cart
19	CIRCLIP, R-TYPE Part #: 93420-36M01-00 Required per assembly: 1 Note: (X(150)) [CIRCLIP,R-TYPE] $11.49 $11.32 - + Add to cart
20	BOLT Part #: 97075-10045-00 Required per assembly: 6 $27.98 $26.43 - + Add to cart
21	WASHER, PLATE Part #: 92990-10600-00 Required per assembly: 6 Note: Sold in multiples of 5 only $3.10 $3.02 - + Add to cart
22	PIN, DOWEL Part #: 93606-12019-00 Required per assembly: 2 Note: (USA) $4.24 $3.21 - + Add to cart
23	CASING, UPPER Part #: 6C5-45111-00-8D Required per assembly: 1 $948.01 $880.82 - + Add to cart
