Frame replacement parts for 2013 Yamaha FX Nytro XTX 1.75 FX10XT75DL / FX10XT75DB

OEM Parts Yamaha 2013 Yamaha FX Nytro XTX 1.75 FX10XT75DL / FX10XT75DB Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FRAME COMP. Part #: 8GL-21940-03-00 Required per assembly: 1 $1,694.83 - + Add to cart
2	BRACKET, ENGINE Part #: 8GL-2194E-00-00 Required per assembly: 1 Not Available
3	NUT, SELF-LOCKING, (3Y2) Part #: 90185-08089-00 Required per assembly: 3 ~~$10.49~~ $9.72 - + Add to cart
4	BOLT, FLANGE, (JN5) Part #: 95817-08016-00 Required per assembly: 12 $5.71 - + Add to cart
5	WASHER, PLATE, (4W3) Part #: 90201-086A3-00 Required per assembly: 1 ~~$9.49~~ $8.46 - + Add to cart
6	REAR FRAME COMP. Part #: 8JJ-21950-00-00 Required per assembly: 1 $4,418.46 - + Add to cart
7	REAR FRAME COMP. Part #: 8JJ-21950-09-00 Required per assembly: 1 $3,101.59 - + Add to cart
8	REINFORCEMENT, FOOTR Part #: 8HK-21926-00-00 Required per assembly: 1 ~~$236.99~~ $221.89 - + Add to cart
9	REINFORCEMENT, FOOTR Part #: 8HK-21936-00-00 Required per assembly: 1 Not Available
10	BRACKET, MAIN, TRACK, 1 Part #: 8HL-21943-00-00 Required per assembly: 1 ~~$77.98~~ $70.63 - + Add to cart
11	BRACKET, MAIN, TRACK, 2 Part #: 8HL-21953-00-00 Required per assembly: 1 Not Available
12	BRACKET, MAIN, TRACK, 3 Part #: 8FU-21919-00-00 Required per assembly: 2 $6.39 - + Add to cart
13	BRACKET, RR.TRACK, SUSPENTION, 1 Part #: 8HL-21944-00-00 Required per assembly: 1 $107.66 - + Add to cart
14	BRACKET, RR.TRACK, SUSPENTION, 2 Part #: 8HL-21954-00-00 Required per assembly: 1 Not Available
15	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 4 ~~$8.49~~ $5.15 - + Add to cart
16	WASHER, PLATE Part #: 90201-10035-00 Required per assembly: 2 $5.32 - + Add to cart
17	PROTECTOR, MUFFLER Part #: 8GL-2194H-00-00 Required per assembly: 1 ~~$76.98~~ $63.91 - + Add to cart
18	BRACKET 7 Part #: 8GL-2197N-00-00 Required per assembly: 1 ~~$111.98~~ $101.27 - + Add to cart
19	REINEFORCEMENT, FRAME, REAR, 1 Part #: 8HL-21923-00-00 Required per assembly: 1 ~~$72.98~~ $65.88 - + Add to cart
20	BRACKET, FUEL, TANK, 1 Part #: 8CR-2194N-00-00 Required per assembly: 2 $4.40 - + Add to cart
21	PANEL, SUB, FRAME, 6 Part #: 8HL-21917-01-00 Required per assembly: 1 Not Available
22	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 1 Note: (4.7X16.4 YELLOW) $4.92 - + Add to cart
23	BRACKET 8 Part #: 8GL-22512-00-00 Required per assembly: 4 $9.01 - + Add to cart
24	NUT Part #: 8GL-21295-00-00 Required per assembly: 1 $11.67 - + Add to cart
25	RIVET, BLIND, (4.8X12, YELLOW) Part #: 90267-48010-00 Required per assembly: 6 $2.84 - + Add to cart
26	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 55 ~~$11.49~~ $10.76 - + Add to cart
27	PATCH 1 Part #: 8HK-21961-00-00 Required per assembly: 2 Not Available
28	PATCH 3 Part #: 8HK-21963-00-00 Required per assembly: 1 Not Available
29	PATCH 4 Part #: 8HK-21964-00-00 Required per assembly: 1 Not Available
30	PATCH 5 Part #: 8HK-21965-00-00 Required per assembly: 1 ~~$50.99~~ $42.31 - + Add to cart
31	PATCH 6 Part #: 8HK-21966-00-00 Required per assembly: 1 ~~$43.99~~ $34.23 - + Add to cart
32	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 14 ~~$11.49~~ $10.35 - + Add to cart
33	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 18 ~~$2.60~~ $2.44 - + Add to cart
34	REINF., HOUSING, 1 Part #: 8GL-21925-00-00 Required per assembly: 1 Not Available
35	HOUSING, REINF, SUB-A Part #: 8GL-21930-00-00 Required per assembly: 1 Not Available
36	BEARING (5X5) Part #: 93306-20627-00 Required per assembly: 1 ~~$82.98~~ $66.75 - + Add to cart
37	CIRCLIP 54G Part #: 99009-62500-00 Required per assembly: 1 ~~$9.49~~ $8.38 - + Add to cart
38	OIL SEAL Part #: 93102-30012-00 Required per assembly: 1 ~~$35.99~~ $28.59 - + Add to cart
39	HEAT EXCHANGER ASSEMBLY Part #: 8HA-12440-00-00 Required per assembly: 1 ~~$571.99~~ $571.77 - + Add to cart
40	PANEL, SUB, FRAME, 4 Part #: 8GL-21915-00-00 Required per assembly: 1 Not Available
41	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 41 Note: (4.7X16.4 YELLOW) $4.92 - + Add to cart
42	BOLT, BUTTON, HEAD Part #: 92012-08016-00 Required per assembly: 2 ~~$10.49~~ $9.33 - + Add to cart
43	BOLT, HEXAGON Part #: 97017-08016-00 Required per assembly: 8 ~~$9.49~~ $8.37 - + Add to cart
44	RIVET, BLIND, (4.8X12, YELLOW) Part #: 90267-48010-00 Required per assembly: 5 $2.84 - + Add to cart
45	CLAMP Part #: 90462-08061-00 Required per assembly: 1 Not Available
46	CLAMP Part #: 90462-08064-00 Required per assembly: 1 Not Available
47	WASHER, PLATE Part #: 90201-08512-00 Required per assembly: 8 ~~$9.49~~ $8.31 - + Add to cart
48	FOOTREST COMP. 1 Part #: 8GL-21960-00-00 Required per assembly: 1 ~~$210.99~~ $210.60 - + Add to cart
49	FOOTREST COMP. 2 Part #: 8GL-21970-02-00 Required per assembly: 1 ~~$195.99~~ $189.18 - + Add to cart
50	STAY, BUZZER Part #: 8JH-83386-00-00 Required per assembly: 1 $7.83 - + Add to cart
51	GROMMET Part #: 90480-14004-00 Required per assembly: 2 $9.94 - + Add to cart
52	COLLAR 437216330000 Part #: 90387-07391-00 Required per assembly: 2 ~~$10.49~~ $10.24 - + Add to cart
53	WASHER, PLATE, 8221447500 Part #: 90201-06057-00 Required per assembly: 2 ~~$6.49~~ $5.24 - + Add to cart
54	BOLT, FLANGE Part #: 95817-06025-00 Required per assembly: 2 $2.09 - + Add to cart
55	CLAMP Part #: 90462-06022-00 Required per assembly: 1 $5.67 - + Add to cart
56	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 1 ~~$11.49~~ $10.76 - + Add to cart
57	BOLT, FLANGE Part #: 95817-10030-00 Required per assembly: 2 ~~$9.49~~ $8.31 - + Add to cart
58	HEAT EXCHANGER ASSEMBLY Part #: 8HA-1241A-00-00 Required per assembly: 1 Note: AP ~~$437.99~~ $425.52 - + Add to cart
59	WASHER, SEAL Part #: 90210-06006-00 Required per assembly: 1 Note: AP ~~$9.49~~ $5.78 - + Add to cart
60	BOLT (3JP) Part #: 97017-06010-00 Required per assembly: 1 ~~$4.04~~ $3.69 - + Add to cart
61	HOUSING, REINF, SUB-ASSEMBLY(L.H) Part #: 8GL-21920-00-00 Required per assembly: 1 Note: (L.H) ~~$29.98~~ $24.74 - + Add to cart
62	BOLT, FLANGE Part #: 95812-08020-00 Required per assembly: 2 ~~$2.79~~ $2.41 - + Add to cart
63	PANEL, SUB, FRAME, 5 Part #: 8GL-21916-00-00 Required per assembly: 1 $340.99 - + Add to cart
64	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 10 Note: (4.7X16.4 YELLOW) $4.92 - + Add to cart
65	STAY, MUFFER Part #: 8GL-2194L-00-00 Required per assembly: 1 ~~$41.99~~ $28.86 - + Add to cart
66	BRACKET, SEAT, FITTING Part #: 8GL-21946-00-00 Required per assembly: 2 Not Available
67	NUT, CROWN Part #: 90176-06016-00 Required per assembly: 8 $4.96 - + Add to cart
68	SEAL, GUARD Part #: 8GL-22151-00-00 Required per assembly: 2 Not Available
69	SEAL, GUARD Part #: 8GL-22152-00-00 Required per assembly: 2 $5.63 - + Add to cart
70	PATCH 7 Part #: 8GL-21967-00-00 Required per assembly: 2 ~~$22.98~~ $21.53 - + Add to cart
71	PATCH 8 Part #: 8GL-21988-00-00 Required per assembly: 1 Not Available
72	BAR, FOOTREST, 1 Part #: 8GL-27471-00-00 Required per assembly: 1 ~~$54.99~~ $46.25 - + Add to cart
73	BAR, FOOTREST, 2 Part #: 8GL-27472-00-00 Required per assembly: 1 ~~$54.99~~ $46.25 - + Add to cart
74	BOLT, BUTTON, HEAD Part #: 92012-06014-00 Required per assembly: 4 ~~$9.49~~ $8.33 - + Add to cart
75	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 4 $2.13 - + Add to cart
76	BRACKET, REAR, FENDER, 1 Part #: 8GL-21151-00-00 Required per assembly: 1 Not Available
77	BRACKET, REAR, FENDER, 2 Part #: 8GL-21152-00-00 Required per assembly: 1 Not Available
78	CAP Part #: 180-22117-00-00 Required per assembly: 2 $8.76 - + Add to cart
79	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 46 Note: (4.7X16.4 YELLOW) $4.92 - + Add to cart
80	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 4 ~~$11.49~~ $10.35 - + Add to cart
81	DAMPER Part #: 8GL-21852-00-00 Required per assembly: 1 $3.16 - + Add to cart
82	PROTECTOR, FRAME Part #: 8GL-2197B-00-00 Required per assembly: 1 ~~$72.98~~ $59.77 - + Add to cart
83	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 12 ~~$11.49~~ $10.76 - + Add to cart
84	DAMPER, PLATE Part #: 90520-05012-00 Required per assembly: 1 $1.13 - + Add to cart
