Lower Casing Drive 3 replacement parts for 2013 Yamaha LF150XA

OEM Parts Yamaha 2013 Yamaha LF150XA Lower Casing Drive 3

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	LOWER UNIT ASSEMBLY Part #: 64P-45300-16-8D Required per assembly: 1 Not Available
2	CASING, LOWER Part #: 6J9-45301-07-8D Required per assembly: 1 $1,350.93 $1,278.12 - + Add to cart
3	BEARING, CYL.#11 Part #: 93311-928U5-00 Required per assembly: 1 Note: ((150)) [BEARING,CYL.#11] $144.99 $131.09 - + Add to cart
4	BEARING, CYL., #90 Part #: 93390-000U2-00 Required per assembly: 1 $187.99 $176.00 - + Add to cart
5	BEARING, FLAT, #41 Part #: 93341-465U4-00 Required per assembly: 1 $66.98 $60.42 - + Add to cart
6	SHIM (T:0.12MM) Part #: 6G5-45567-10-00 Required per assembly: 1 Note: (T:0.12MM) UR $6.59 $6.18 - + Add to cart
6	SHIM (T:0.10MM) Part #: 6G5-45567-01-00 Required per assembly: 1 Note: (T:0.10MM) UR $6.25 $5.88 - + Add to cart
6	SHIM (T:0.15MM) Part #: 6G5-45567-20-00 Required per assembly: 1 Note: (T:0.15MM) UR $6.59 $6.18 - + Add to cart
6	SHIM (T:0.50MM) Part #: 6G5-45567-60-00 Required per assembly: 1 Note: (T:0.50MM) UR $6.59 $6.18 - + Add to cart
6	SHIM (T:0.40MM) Part #: 6G5-45567-50-00 Required per assembly: 1 Note: (T:0.40MM) UR $6.59 $6.18 - + Add to cart
6	SHIM (T:0.18MM) Part #: 6G5-45567-30-00 Required per assembly: 1 Note: (T:0.18MM) UR $6.59 $6.18 - + Add to cart
6	SHIM (T:0.30MM) Part #: 6G5-45567-40-00 Required per assembly: 1 Note: (T:0.30MM) UR $6.59 $6.18 - + Add to cart
7	PLUG, STRAIGHT, SCREW Part #: 90340-08002-00 Required per assembly: 1 $12.75 $12.02 - + Add to cart
8	PLUG, DRAIN Part #: 688-45341-10-00 Required per assembly: 1 $12.69 $11.94 - + Add to cart
9	GASKET Part #: 90430-08003-00 Required per assembly: 2 $1.75 $1.59 - + Add to cart
10	SLEEVE, DRIVE, SHFT Part #: 6G5-45536-01-00 Required per assembly: 1 Note: ((LZ)) [SLEEVE,DRIVE SHFT] $18.75 $17.54 - + Add to cart
11	GUIDE, RUB.SEAL Part #: 663-45376-00-00 Required per assembly: 1 $14.90 $13.99 - + Add to cart
12	SEAL, RUBBER Part #: 688-45375-00-00 Required per assembly: 1 Note: ((68V1)) [SEAL,RUBBER] $13.75 $12.93 - + Add to cart
13	NIPPLE, HOSE Part #: 63P-45378-00-00 Required per assembly: 1 $6.75 $6.35 - + Add to cart
14	O-RING Part #: 93210-07540-00 Required per assembly: 1 $7.49 $5.67 - + Add to cart
15	PLATE Part #: 6E5-45321-00-00 Required per assembly: 1 Note: ((68V1)) $63.79 $59.88 - + Add to cart
16	O-RING Part #: 93210-58677-00 Required per assembly: 1 $7.49 $5.32 - + Add to cart
17	OIL, SEAL, DD-TYPE Part #: 93106-09014-00 Required per assembly: 1 Note: ((68V1)) [OIL SEAL,DD-TYPE] $8.40 $8.00 - + Add to cart
18	BOLT, WITH, WASHER Part #: 90119-06286-00 Required per assembly: 3 $6.25 $5.88 - + Add to cart
19	SHIFT CAM ASSEMBLY Part #: 64P-44150-11-00 Required per assembly: 1 Note: X(25.3"),LH $416.71 $378.83 - + Add to cart
20	CIRCLIP (2R6) Part #: 99001-08600-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
21	SPACER 1 Part #: 61A-45538-00-00 Required per assembly: 1 Note: ((68W1)) $7.59 $7.18 - + Add to cart
22	WASHER, PLATE Part #: 90201-22M01-00 Required per assembly: 2 Note: ((LX)) [WASHER,PLATE] Sold in multiples of 5 only $4.15 $3.84 - + Add to cart
23	WASHER, WAVE Part #: 90206-22M19-00 Required per assembly: 1 Note: ((SX)) [WASHER,WAVE] $6.15 $5.82 - + Add to cart
24	COLLAR, DRIVE, SHAFT Part #: 61A-45527-00-00 Required per assembly: 1 Note: ((67N1)) [COLLAR,DRIVE SHAFT] $12.75 $12.02 - + Add to cart
25	HOUSING, WATER, PUMP Part #: 61A-44311-01-00 Required per assembly: 1 $33.70 $31.59 - + Add to cart
26	INSERT, CARTRIDGE Part #: 61A-44322-02-00 Required per assembly: 1 $50.50 $47.40 - + Add to cart
27	O-RING Part #: 93210-86M38-00 Required per assembly: 1 Note: ((67N1)) $13.85 $12.99 - + Add to cart
28	O-RING Part #: 93210-37M67-00 Required per assembly: 1 $3.75 $3.18 - + Add to cart
29	DAMPER, WATER, SEAL, 1 Part #: 6E5-44365-01-00 Required per assembly: 1 $2.00 $1.89 - + Add to cart
30	COVER, WTR.PUMP, HSG Part #: 6E5-44312-00-00 Required per assembly: 1 Note: ((67N1)) [COVER,WTR.PUMP HSG] $3.50 $3.33 - + Add to cart
31	IMPELLER Part #: 6E5-44352-01-00 Required per assembly: 1 $33.64 $31.53 - + Add to cart
32	KEY, WOODRUFF Part #: 90280-04M05-00 Required per assembly: 1 Note: ((Z)) [KEY,WOODRUFF] $14.35 $13.61 - + Add to cart
34	GASKET, WATER, PUMP Part #: 6E5-44315-A0-00 Required per assembly: 1 $6.15 $5.73 - + Add to cart
35	PIN, DOWEL Part #: 93606-12019-00 Required per assembly: 2 Note: (USA) $4.24 $3.21 - + Add to cart
36	BOLT, WITH, WASHER Part #: 90119-08191-00 Required per assembly: 4 $4.79 $3.96 - + Add to cart
37	HOUSING, BEARING Part #: 6E5-45331-00-9S Required per assembly: 1 $133.55 $125.18 - + Add to cart
38	OIL, SEAL, S-TYPE Part #: 93101-28M16-00 Required per assembly: 2 Note: ((130)) [OIL SEAL,S-TYPE] $11.40 $10.81 - + Add to cart
39	BEARING, CYL.#15 Part #: 93315-430V5-00 Required per assembly: 1 $26.98 $22.15 - + Add to cart
40	SHIM 3 Part #: 6E5-45587-01-00 Required per assembly: 1 Note: (T:0.10MM) UR $4.20 $3.93 - + Add to cart
40	SHIM (T:0.12MM) Part #: 6E5-45587-10-00 Required per assembly: 1 Note: (T:0.12MM) UR $6.25 $5.88 - + Add to cart
40	SHIM (T:0.15MM) Part #: 6E5-45587-20-00 Required per assembly: 1 Note: (T:0.15MM) UR $6.25 $5.88 - + Add to cart
40	SHIM (T:0.18MM) Part #: 6E5-45587-30-00 Required per assembly: 1 Note: (T:0.18MM) UR $6.25 $5.88 - + Add to cart
40	SHIM (T:0.30MM) Part #: 6E5-45587-40-00 Required per assembly: 1 Note: (T:0.30MM) UR $6.25 $5.88 - + Add to cart
40	SHIM (T:0.40MM) Part #: 6E5-45587-50-00 Required per assembly: 1 Note: (T:0.40MM) UR $6.25 $5.88 - + Add to cart
40	SHIM (T:0.50MM) Part #: 6E5-45587-60-00 Required per assembly: 1 Note: (T:0.50MM) UR $6.25 $5.88 - + Add to cart
41	BEARING, THRUST Part #: 93341-930V2-00 Required per assembly: 1 $174.99 $163.39 - + Add to cart
42	O-RING Part #: 93210-54534-00 Required per assembly: 1 $5.95 $5.67 - + Add to cart
43	COVER, OIL, SEAL Part #: 6E5-45344-00-00 Required per assembly: 1 Note: ((68V1)) [COVER,OIL SEAL] $19.35 $18.22 - + Add to cart
44	BOLT Part #: 97095-08025-00 Required per assembly: 4 $9.49 $6.44 - + Add to cart
45	WASHER, PLAIN, (663) Part #: 92990-08600-00 Required per assembly: 4 $2.64 $2.28 - + Add to cart
46	DRIVE SHAFT COMP. X(25.3") Part #: 63P-45501-11-00 Required per assembly: 1 $431.92 $399.65 - + Add to cart
47	PINION Part #: 63P-45551-00-00 Required per assembly: 1 Note: (14T) $350.60 $318.73 - + Add to cart
48	NUT, HEXAGON Part #: 90170-16M01-00 Required per assembly: 1 Note: ((T50)) [NUT,HEXAGON] $7.49 $5.35 - + Add to cart
49	GEAR Part #: 64P-45560-01-00 Required per assembly: 1 Note: (28T) $905.53 $823.21 - + Add to cart
50	BEARING, CYL.#15 Part #: 93315-425V3-00 Required per assembly: 2 $31.98 $26.57 - + Add to cart
51	SHAFT, PROPELLER Part #: 6K1-45611-11-00 Required per assembly: 1 $246.65 $236.23 - + Add to cart
52	SLIDE, SHIFT Part #: 6E5-45634-02-00 Required per assembly: 1 $115.30 $108.17 - + Add to cart
53	SPRING, COMPRESSION Part #: 90501-16M37-00 Required per assembly: 1 Note: ((68V1)) [SPRING,COMPRESSION] $6.75 $6.35 - + Add to cart
54	BALL (12R) Part #: 93507-32031-00 Required per assembly: 2 Note: Sold in multiples of 5 only $5.49 $3.84 - + Add to cart
55	BALL 11/32 Part #: 93511-32027-00 Required per assembly: 2 Note: Sold in multiples of 5 only $9.49 $6.05 - + Add to cart
56	BALL 3/16 Part #: 93503-16003-00 Required per assembly: 2 $2.72 $2.06 - + Add to cart
57	PIN, STRAIGHT Part #: 90250-08M07-00 Required per assembly: 1 Note: ((SX)) [PIN,STRAIGHT] $9.09 $8.54 - + Add to cart
58	CLUTCH, DOG Part #: 63P-45631-01-00 Required per assembly: 1 Not Available
59	RING, CROSS, PIN Part #: 6E5-45633-01-00 Required per assembly: 1 Note: ((150)) [RING,CROSS PIN] $16.60 $15.57 - + Add to cart
60	HOUSING, BEARING Part #: 6K1-45332-01-CA Required per assembly: 1 $174.65 $163.75 - + Add to cart
61	BEARING, TAPRD, #32 Part #: 93332-00048-00 Required per assembly: 1 $133.99 $120.64 - + Add to cart
62	GEAR Part #: 64P-45570-01-00 Required per assembly: 1 Note: (28T) $747.19 $679.27 - + Add to cart
63	WASHER, THRUST Part #: 6K1-45576-00-00 Required per assembly: 1 $84.50 $79.21 - + Add to cart
64	BEARING, FLAT, #41 Part #: 93341-440U5-00 Required per assembly: 1 $47.99 $41.38 - + Add to cart
65	SHIM Part #: 6K1-45578-01-00 Required per assembly: 1 Note: (T:0.10MM) UR $5.20 $4.97 - + Add to cart
65	SHIM (T:0.12MM) Part #: 6K1-45578-10-00 Required per assembly: 1 Note: (T:0.12MM) UR $6.15 $5.82 - + Add to cart
65	SHIM (T:0.15MM) Part #: 6K1-45578-20-00 Required per assembly: 1 Note: (T:0.15MM) UR $6.15 $5.82 - + Add to cart
65	SHIM (T:0.18MM) Part #: 6K1-45578-30-00 Required per assembly: 1 Note: (T:0.18MM) UR $6.15 $5.82 - + Add to cart
65	SHIM (T:0.30MM) Part #: 6K1-45578-40-00 Required per assembly: 1 Note: (T:0.30MM) UR $6.15 $5.82 - + Add to cart
65	SHIM (T:0.40MM) Part #: 6K1-45578-50-00 Required per assembly: 1 Note: (T:0.40MM) UR $6.15 $5.82 - + Add to cart
65	SHIM (T:0.50MM) Part #: 6K1-45578-60-00 Required per assembly: 1 Note: (T:0.50MM) UR $6.15 $5.82 - + Add to cart
66	BEARING Part #: 93315-43061-00 Required per assembly: 1 $41.99 $36.02 - + Add to cart
67	OIL, SEAL, S-TYPE Part #: 93101-30M17-00 Required per assembly: 2 Note: ((150)) [OIL SEAL,S-TYPE] $14.15 $13.37 - + Add to cart
68	O-RING Part #: 93210-97M55-00 Required per assembly: 1 Note: ((LZ)) $14.90 $13.99 - + Add to cart
69	SHIM Part #: 6G5-45577-02-00 Required per assembly: 1 Note: (T:0.10MM) UR $5.79 $5.59 - + Add to cart
69	SHIM (T:0.12MM) Part #: 6G5-45577-10-00 Required per assembly: 1 Note: (T:0.12MM) UR $6.15 $5.82 - + Add to cart
69	SHIM (T:0.15MM) Part #: 6G5-45577-20-00 Required per assembly: 1 Note: (T:0.15MM) UR $6.59 $6.18 - + Add to cart
69	SHIM (T:0.18MM) Part #: 6G5-45577-30-00 Required per assembly: 1 Note: (T:0.18MM) UR $6.59 $6.18 - + Add to cart
69	SHIM (T:0.30MM) Part #: 6G5-45577-40-00 Required per assembly: 1 Note: (T:0.30MM) UR $6.59 $6.18 - + Add to cart
69	SHIM (T:0.40MM) Part #: 6G5-45577-50-00 Required per assembly: 1 Note: (T:0.40MM) UR $6.59 $6.18 - + Add to cart
69	SHIM (T:0.50MM) Part #: 6G5-45577-60-00 Required per assembly: 1 Note: (T:0.50MM) UR $6.59 $6.18 - + Add to cart
70	KEY, STRAIGHT Part #: 90282-04M00-00 Required per assembly: 1 Note: ((150)) [KEY,STRAIGHT] $8.59 $8.16 - + Add to cart
71	WASHER, CLAW Part #: 6G5-45383-01-00 Required per assembly: 1 $19.89 $18.75 - + Add to cart
72	NUT Part #: 6G5-45384-02-00 Required per assembly: 1 $56.39 $52.92 - + Add to cart
