Frame replacement parts for 2013 Yamaha RS Vector LTX RS90PLTDL / RS90PLTDB

OEM Parts Yamaha 2013 Yamaha RS Vector LTX RS90PLTDL / RS90PLTDB Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FRAME COMP. Part #: 8HV-21940-00-00 Required per assembly: 1 $2,248.25 - + Add to cart
2	BULKHEAD Part #: 8FA-W2197-13-00 Required per assembly: 1 $478.88 - + Add to cart
3	BUSH, SOLID Part #: 90381-15001-00 Required per assembly: 2 ~~$6.49~~ $5.67 - + Add to cart
4	BUSH, SOLID Part #: 90381-16004-00 Required per assembly: 2 ~~$18.48~~ $15.92 - + Add to cart
5	BULKHEAD 2 Part #: 8FA-W2198-20-00 Required per assembly: 1 $997.07 - + Add to cart
6	BUSH, SOLID Part #: 90381-15001-00 Required per assembly: 2 ~~$6.49~~ $5.67 - + Add to cart
7	BUSH, SOLID Part #: 90381-16004-00 Required per assembly: 2 ~~$18.48~~ $15.92 - + Add to cart
8	BOLT, FLANGE Part #: 95817-08060-00 Required per assembly: 3 ~~$4.79~~ $4.57 - + Add to cart
9	BOLT, WASHER, BASED Part #: 90105-084A1-00 Required per assembly: 1 $12.13 - + Add to cart
10	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 4 ~~$9.49~~ $9.46 - + Add to cart
11	BRACKET 2 Part #: 8HG-2836E-00-00 Required per assembly: 1 $13.80 - + Add to cart
12	BRACKET, STEERING, 1 Part #: 8FG-21947-00-00 Required per assembly: 1 ~~$182.99~~ $170.95 - + Add to cart
13	NUT, SELF-LOCKING, (JN5) Part #: 95607-10200-00 Required per assembly: 4 $4.65 - + Add to cart
14	PROTECTOR Part #: 8FR-2193A-01-00 Required per assembly: 1 ~~$100.98~~ $91.52 - + Add to cart
15	HEAT EXCHANGER ASSEMBLY Part #: 8JA-12440-00-00 Required per assembly: 1 $487.23 - + Add to cart
16	HOSE 7 Part #: 8FA-12551-00-00 Required per assembly: 1 $10.25 - + Add to cart
17	CLIP, SCISSOR Part #: 90467-28046-00 Required per assembly: 1 ~~$18.48~~ $15.44 - + Add to cart
18	HOSE CLAMP ASSEMBLY Part #: 90450-35001-00 Required per assembly: 1 $7.16 - + Add to cart
19	NUT, SELF-LOCKING Part #: 90185-08169-00 Required per assembly: 1 ~~$9.49~~ $9.46 - + Add to cart
20	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 43 Note: (4.7X16.4 YELLOW) $4.92 - + Add to cart
21	PLATE, COVER Part #: 8ES-2131D-00-00 Required per assembly: 1 $5.89 - + Add to cart
22	RIVET, BLIND, (4.8X16.4, YELLOW) Part #: 90267-48016-00 Required per assembly: 12 ~~$11.49~~ $10.35 - + Add to cart
23	CLAMP Part #: 90462-08083-00 Required per assembly: 1 $14.51 - + Add to cart
24	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 16 ~~$2.60~~ $2.44 - + Add to cart
25	REAR FRAME COMP. Part #: 8HW-21950-00-00 Required per assembly: 1 Not Available
26	REINEFORCEMENT, FRAME, REAR, 1 Part #: 8FA-W2199-10-00 Required per assembly: 1 $2,140.06 - + Add to cart
27	REINFORCEMENT, FOOTR Part #: 8FG-21926-00-00 Required per assembly: 1 ~~$141.99~~ $140.16 - + Add to cart
28	REINFORCEMENT, FOOTR Part #: 8FG-21936-00-00 Required per assembly: 1 ~~$141.99~~ $128.16 - + Add to cart
29	BRACKET, MAIN, TRACK, 1 Part #: 8FU-21943-00-00 Required per assembly: 1 Not Available
30	BRACKET, MAIN, TRACK, 2 Part #: 8FU-21953-00-00 Required per assembly: 1 Not Available
31	BRACKET, RR.TRACK, SUSPENTION, 1 Part #: 8FT-21944-00-00 Required per assembly: 1 ~~$86.98~~ $78.52 - + Add to cart
32	BRACKET, RR.TRACK, SU Part #: 8FT-21954-00-00 Required per assembly: 1 ~~$86.98~~ $78.52 - + Add to cart
33	BOLT, FLANGE Part #: 95814-10020-00 Required per assembly: 4 $5.24 - + Add to cart
34	PATCH 8 Part #: 8FU-21988-01-00 Required per assembly: 2 $10.55 - + Add to cart
35	BRACKET, FUEL, TANK, 1 Part #: 8CR-2194N-00-00 Required per assembly: 2 $4.40 - + Add to cart
36	BRACKET 1 Part #: 8FA-2194X-00-00 Required per assembly: 1 $4.92 - + Add to cart
37	BRACKET 2 Part #: 8FA-2195X-00-00 Required per assembly: 1 $4.92 - + Add to cart
38	PROTECTOR, MUFFLER Part #: 8ES-2194H-00-00 Required per assembly: 1 ~~$68.98~~ $57.18 - + Add to cart
39	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 1 Note: (4.7X16.4 YELLOW) $4.92 - + Add to cart
40	PATCH 3 Part #: 8FT-21963-01-00 Required per assembly: 1 ~~$61.99~~ $55.38 - + Add to cart
41	PATCH 4 Part #: 8FT-21964-00-00 Required per assembly: 1 ~~$67.98~~ $61.57 - + Add to cart
42	HEAT EXCHANGER ASSEMBLY Part #: 8FT-1241A-00-00 Required per assembly: 1 ~~$879.99~~ $772.59 - + Add to cart
43	WASHER, SEAL Part #: 90210-06006-00 Required per assembly: 1 Note: AP ~~$9.49~~ $5.78 - + Add to cart
44	BOLT, FLANGE Part #: 95817-06012-00 Required per assembly: 1 $2.13 - + Add to cart
45	RIVET, BLIND, (4.8X12.6, SILVER) Part #: 90267-48095-00 Required per assembly: 2 Note: (4.8X12.6 SILVER) $2.84 - + Add to cart
46	BRACKET, MAIN, TRACK, 3 Part #: 8FU-21919-00-00 Required per assembly: 2 $6.39 - + Add to cart
47	BOLT, BUTTON, HEAD Part #: 92014-10020-00 Required per assembly: 2 $4.96 - + Add to cart
48	MEMBER, SIDE, 1 Part #: 8FG-2111J-00-00 Required per assembly: 1 ~~$88.98~~ $80.18 - + Add to cart
49	MEMBER, SIDE, 2 Part #: 8FG-2111K-00-00 Required per assembly: 1 ~~$88.98~~ $80.18 - + Add to cart
50	PANEL, SUB, FRAME, 5 Part #: 8FT-21916-01-00 Required per assembly: 1 $173.45 - + Add to cart
51	PATCH 8 Part #: 8FG-21988-00-00 Required per assembly: 1 $5.75 - + Add to cart
52	PATCH 9 Part #: 8FG-21989-00-00 Required per assembly: 1 $5.75 - + Add to cart
53	RIVET, BLIND Part #: 90267-47197-00 Required per assembly: 8 Note: FOR EF30ISEBH ~~$2.39~~ $1.58 - + Add to cart
54	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 24 ~~$11.49~~ $10.76 - + Add to cart
55	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 8 ~~$2.60~~ $2.44 - + Add to cart
56	BRACKET, REFLECTOR, 1 Part #: 8FT-2113J-00-00 Required per assembly: 2 $14.70 - + Add to cart
57	FRAME CONNECTION KIT Part #: 8JA-W2195-00-00 Required per assembly: 1 ~~$219.99~~ $205.30 - + Add to cart
58	BRACKET, CHAIN, HOUSING Part #: 8CR-21939-01-00 Required per assembly: 2 $7.30 - + Add to cart
59	BRACKET, 5 Part #: 8JA-2196M-00-00 Required per assembly: 1 ~~$35.99~~ $31.24 - + Add to cart
60	BRACKET, 6 Part #: 8JA-2197M-00-00 Required per assembly: 1 ~~$35.99~~ $31.24 - + Add to cart
61	COVER 2 Part #: 8FP-2198G-01-00 Required per assembly: 1 ~~$25.98~~ $22.65 - + Add to cart
62	CLAMP, WIRE, HARNESS Part #: 8FA-21999-00-00 Required per assembly: 1 ~~$10.99~~ $9.65 - + Add to cart
63	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 66 Note: (4.7X16.4 YELLOW) $4.92 - + Add to cart
64	RIVET, BLIND, (4.8X18.6, BLACK) Part #: 90267-48018-00 Required per assembly: 4 Note: (4.8X18.6 BLACK) ~~$10.49~~ $9.78 - + Add to cart
65	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 10 ~~$2.60~~ $2.44 - + Add to cart
66	RIVET, BLIND, (4.7X16.4, BLACK) Part #: 90267-47186-00 Required per assembly: 4 $3.27 - + Add to cart
67	FOOTREST COMP. 1 Part #: 8JA-21960-00-00 Required per assembly: 1 Not Available
68	FOOTREST COMP. 2 Part #: 8HG-21970-00-00 Required per assembly: 1 ~~$260.99~~ $257.95 - + Add to cart
69	HOUSING, REINF, SUB-ASSEMBLY, (L.H) Part #: 8EK-21920-01-00 Required per assembly: 1 Note: (L.H) ~~$21.98~~ $20.36 - + Add to cart
70	GROMMET Part #: 90480-13567-00 Required per assembly: 2 ~~$5.49~~ $5.39 - + Add to cart
71	FRAME UNDER 1 Part #: 8GM-2196A-01-00 Required per assembly: 1 $214.47 - + Add to cart
72	FRAME, UNDER, 2 Part #: 8FP-2196E-02-00 Required per assembly: 1 $97.97 - + Add to cart
73	BRACKET, GUARD, FITTING Part #: 8FP-21972-00-00 Required per assembly: 1 ~~$41.99~~ $31.34 - + Add to cart
74	BRACKET 3 Part #: 8FA-2196F-00-00 Required per assembly: 6 $7.57 - + Add to cart
75	RIVET, BLIND, (4.8X18.6, BLACK) Part #: 90267-48018-00 Required per assembly: 12 Note: (4.8X18.6 BLACK) ~~$10.49~~ $9.78 - + Add to cart
76	RIVET, BLIND, (47X195, SILVER) Part #: 90267-47200-00 Required per assembly: 3 $3.23 - + Add to cart
77	PROTECTOR, FRAME Part #: 8FT-21978-00-00 Required per assembly: 2 $129.72 - + Add to cart
78	BRACKET 7 Part #: 8FT-2197N-00-00 Required per assembly: 2 $10.33 - + Add to cart
79	BRACKET 7 Part #: 8FU-2197N-00-00 Required per assembly: 4 ~~$23.98~~ $20.65 - + Add to cart
80	BRACKET 3 Part #: 8FT-2196F-00-00 Required per assembly: 1 $17.85 - + Add to cart
81	BRACKET 4 Part #: 8FT-2196G-00-00 Required per assembly: 1 $13.82 - + Add to cart
82	BOLT, FLANGE, (8AB) Part #: 95817-08020-00 Required per assembly: 2 ~~$10.49~~ $6.86 - + Add to cart
83	RIVET, BLIND, (4.7X16.4, BLACK) Part #: 90267-47186-00 Required per assembly: 12 $3.27 - + Add to cart
84	RIVET, BLIND, (4.8X15.2, SILVER) Part #: 90267-48083-00 Required per assembly: 8 Note: (4.8X15.2 SILVER) $3.92 - + Add to cart
85	RIVET, BLIND, (4.8X12.6, SILVER) Part #: 90267-48095-00 Required per assembly: 4 Note: (4.8X12.6 SILVER) $2.84 - + Add to cart
86	RIVET, BLIND, (4.7X16.4, YELLOW) Part #: 90267-47195-00 Required per assembly: 10 Note: (4.7X16.4 YELLOW) $4.92 - + Add to cart
87	RIVET, BLIND, (4.8X12.1, YELLOW) Part #: 90267-48023-00 Required per assembly: 12 ~~$11.49~~ $10.76 - + Add to cart
88	RIVET, BLIND, (48X14, YELLOW) Part #: 90267-48177-00 Required per assembly: 4 ~~$2.60~~ $2.44 - + Add to cart
89	PROTECTOR, FRAME, FR Part #: 8FR-2197E-00-00 Required per assembly: 1 ~~$49.99~~ $41.69 - + Add to cart
90	BOLT, BUTTON, HEAD Part #: 92012-06012-00 Required per assembly: 2 ~~$4.70~~ $3.52 - + Add to cart
91	SPACER Part #: 8FA-21998-00-00 Required per assembly: 4 $5.00 - + Add to cart
92	SHIELD, HEAT Part #: 8FG-23892-00-00 Required per assembly: 1 ~~$50.99~~ $43.03 - + Add to cart
93	RIVET, BLIND, (48X123) Part #: 90267-48059-00 Required per assembly: 14 Note: (4.8X12.3) (4.8X12.3) ~~$3.54~~ $3.48 - + Add to cart
94	STOPPER Part #: 8HG-24768-00-00 Required per assembly: 1 $8.86 - + Add to cart
95	DAMPER 1 Part #: 8HG-2214F-00-00 Required per assembly: 2 $13.46 - + Add to cart
96	TAPE 4 Part #: 8FA-7717H-00-00 Required per assembly: 1 $2.13 - + Add to cart
97	GROMMET Part #: 90480-12053-00 Required per assembly: 1 Note: Sold in multiples of 5 only ~~$8.49~~ $7.83 - + Add to cart
