Fuel replacement parts for 2013 Yamaha T9.9LPB / T9.9LPHB / T9.9XPB / T9.9XPHB

OEM Parts Yamaha 2013 Yamaha T9.9LPB / T9.9LPHB / T9.9XPB / T9.9XPHB Fuel

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FUEL PIPE JOINT COMP. 1 Part #: 6G1-24304-11-00 Required per assembly: 1 ~~$35.99~~ $34.75 - + Add to cart
2	SEAL Part #: 61N-24329-01-00 Required per assembly: 1 $9.72 - + Add to cart
3	BOLT Part #: 90101-06M27-00 Required per assembly: 1 $4.73 - + Add to cart
4	WASHER, PLATE Part #: 92990-06600-00 Required per assembly: 1 Note: Sold in multiples of 5 only $4.21 - + Add to cart
5	HOSE Part #: 90445-10052-00 Required per assembly: 1 Note: (L295) $18.31 - + Add to cart
6	CLAMP Part #: 80L-26397-00-00 Required per assembly: 1 ~~$7.99~~ $5.49 - + Add to cart
7	CLIP Part #: 90467-09M09-00 Required per assembly: 2 $1.77 - + Add to cart
8	STRAINER 1 Part #: 68T-24251-01-00 Required per assembly: 1 $25.84 - + Add to cart
9	HOSE (L170) Part #: 90445-10051-00 Required per assembly: 1 $8.69 - + Add to cart
10	CLIP Part #: 90467-09M09-00 Required per assembly: 2 $1.77 - + Add to cart
11	HOSE Part #: 90445-16010-00 Required per assembly: 1 Note: (L140) $8.38 - + Add to cart
12	FUEL PUMP ASSY Part #: 68T-24410-02-00 Required per assembly: 1 ~~$64.98~~ $61.98 - + Add to cart
13	BODY 2 Part #: 66M-24413-01-00 Required per assembly: 1 $19.01 - + Add to cart
14	VALVE, CHECK Part #: 62Y-24421-01-00 Required per assembly: 2 $18.31 - + Add to cart
15	SCREW, PAN, HEAD Part #: 6E7-14325-00-00 Required per assembly: 2 $6.93 - + Add to cart
16	DIAPHRAGM Part #: 66M-24411-02-00 Required per assembly: 1 ~~$93.98~~ $89.19 - + Add to cart
17	SPRING, DIAPHRAGM Part #: 66M-24423-00-00 Required per assembly: 1 $11.07 - + Add to cart
18	PLUNGER Part #: 66M-13131-00-00 Required per assembly: 1 ~~$38.99~~ $37.77 - + Add to cart
19	PIN Part #: 66M-24374-00-00 Required per assembly: 1 $8.38 - + Add to cart
20	SPRING Part #: 66M-24454-00-00 Required per assembly: 1 $9.53 - + Add to cart
21	DIAPHRAGM Part #: 66M-24471-02-00 Required per assembly: 1 $20.36 - + Add to cart
22	SCREW Part #: 66M-24444-00-00 Required per assembly: 4 $7.13 - + Add to cart
23	NUT Part #: 95303-04600-00 Required per assembly: 4 $6.63 - + Add to cart
24	BOLT, HEXAGON, W/W Part #: 97E95-06630-00 Required per assembly: 2 $1.66 - + Add to cart
25	O-RING Part #: 93210-20M65-00 Required per assembly: 1 Note: Sold in multiples of 5 only $7.54 - + Add to cart
26	PIPE, FUEL, 1 Part #: 6AU-24311-10-00 Required per assembly: 1 ~~$28.98~~ $27.94 - + Add to cart
27	CLIP Part #: 90467-09M09-00 Required per assembly: 2 $1.77 - + Add to cart
29	CLAMP Part #: 90464-10M53-00 Required per assembly: 1 $7.34 - + Add to cart
