Stand Footrest replacement parts for 2013 Yamaha Grizzly 350 4WD

OEM Parts Yamaha 2013 Yamaha Grizzly 350 4WD Stand Footrest

STAND FOOTREST Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	BAR, FOOTREST, 1 Part #: 5ND-F7471-01-00 Required per assembly: 4 $15.49 $11.79 - + Add to cart
2	BOLT, FLANGE Part #: 95817-08012-00 Required per assembly: 4 $5.49 $3.90 - + Add to cart
3	PEDAL, BRAKE Part #: 5TE-F7211-00-00 Required per assembly: 1 $19.48 $15.83 - + Add to cart
4	NUT (JN5) Part #: 95317-06700-00 Required per assembly: 1 $9.49 $6.56 - + Add to cart
5	BOLT, HEXAGON Part #: 97017-06020-00 Required per assembly: 1 $4.05 $2.49 - + Add to cart
6	CIRCLIP, E-TYPE Part #: 93430-10015-00 Required per assembly: 1 $9.49 $7.35 - + Add to cart
7	WASHER, PLATE Part #: 90201-14023-00 Required per assembly: 1 $6.49 $5.16 - + Add to cart
8	NUT, ADJUSTING Part #: 20E-26343-00-00 Required per assembly: 1 $30.98 $21.89 - + Add to cart
9	SPRING, COMPRESSION Part #: 90501-10782-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
10	PIN, SPEC'L, SHAPE Part #: 90249-12008-00 Required per assembly: 1 Note: Sold in multiples of 5 only $9.49 $6.05 - + Add to cart
11	PIN, CLEVIS Part #: 90240-08005-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
12	WASHER, PLATE Part #: 90201-08066-00 Required per assembly: 1 $9.49 $6.23 - + Add to cart
13	PIN, COTTER Part #: 91490-20025-00 Required per assembly: 1 $1.99 $1.29 - + Add to cart
14	COVER 1 (FOOTREST CVR LH SIDE) Part #: 5ND-F7453-01-00 Required per assembly: 1 $82.08 - + Add to cart
15	COVER 2 (FOOTREST CVR RH SIDE) Part #: 5ND-F7463-01-00 Required per assembly: 1 $82.18 - + Add to cart
16	PLATE 1 Part #: 5ND-F7445-00-00 Required per assembly: 2 $11.99 $8.10 - + Add to cart
17	ARM 1 Part #: 5UH-F741A-10-00 Required per assembly: 2 Note: (YMUS) $5.99 $5.07 - + Add to cart
18	RIVET, BLIND Part #: 90267-489U9-00 Required per assembly: 2 $4.29 $3.27 - + Add to cart
19	BOLT Part #: 90109-06262-00 Required per assembly: 8 $10.49 $6.29 - + Add to cart
20	SCREW Part #: 90149-05034-00 Required per assembly: 12 $8.49 $6.27 - + Add to cart
21	NUT, S/L, FLANGE Part #: 95607-05200-00 Required per assembly: 12 $10.49 $6.73 - + Add to cart
22	CABLE, BRAKE Part #: 1NS-26361-00-00 Required per assembly: 1 $78.98 $66.30 - + Add to cart
23	CABLE, CONTROL, 2 Part #: 5GH-2637F-11-00 Required per assembly: 1 $63.99 $51.03 - + Add to cart
24	SPRING, TENSION Part #: 90506-12403-00 Required per assembly: 1 $9.49 $6.55 - + Add to cart
25	PLATE 1 Part #: 5UH-F7445-02-00 Required per assembly: 1 $8.49 $5.07 - + Add to cart
26	RIVET (EU0) Part #: 90267-48938-00 Required per assembly: 1 Note: Sold in multiples of 5 only $5.49 $4.97 - + Add to cart
