Fuel Tank replacement parts for 2013 Yamaha Grizzly 350 4WD Hunter

OEM Parts Yamaha 2013 Yamaha Grizzly 350 4WD Hunter Fuel Tank

FUEL TANK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FUEL TANK COMP. Part #: 5UH-F4110-10-00 Required per assembly: 1 $169.18 - + Add to cart
2	CAP ASSEMBLY Part #: 5KM-24610-00-00 Required per assembly: 1 ~~$66.98~~ $55.49 - + Add to cart
3	FUEL COCK ASSEMBLY 1 Part #: 5KM-24500-10-00 Required per assembly: 1 ~~$64.98~~ $56.55 - + Add to cart
4	VALVE PACKING Part #: 3AC-24523-00-00 Required per assembly: 1 ~~$14.49~~ $11.39 - + Add to cart
5	SEAL, COCK Part #: 3AJ-24534-10-00 Required per assembly: 1 ~~$8.49~~ $6.73 - + Add to cart
6	SCREW, PAN, HEAD Part #: 98507-03014-00 Required per assembly: 2 ~~$9.49~~ $6.55 - + Add to cart
7	GASKET Part #: 4X8-24512-10-00 Required per assembly: 1 ~~$15.49~~ $10.77 - + Add to cart
8	LEVER, COCK Part #: 1NS-F4524-00-00 Required per assembly: 1 ~~$9.49~~ $7.35 - + Add to cart
9	SCREW, FLAT, HEAD Part #: 98702-04018-00 Required per assembly: 1 ~~$0.95~~ $0.73 - + Add to cart
10	WASHER, PLATE(3MB) Part #: 90202-05187-00 Required per assembly: 2 ~~$1.70~~ $1.30 - + Add to cart
11	SCREW Part #: 90149-06108-00 Required per assembly: 2 ~~$1.10~~ $0.94 - + Add to cart
12	GROMMET Part #: 90480-18290-00 Required per assembly: 2 ~~$9.49~~ $6.88 - + Add to cart
13	COLLAR Part #: 90387-066J1-00 Required per assembly: 2 ~~$9.49~~ $6.73 - + Add to cart
14	BOLT, FLANGE Part #: 95817-06030-00 Required per assembly: 2 ~~$4.65~~ $3.84 - + Add to cart
15	GROMMET Part #: 90480-01400-00 Required per assembly: 2 ~~$14.49~~ $9.89 - + Add to cart
16	COLLAR Part #: 90387-07021-00 Required per assembly: 2 ~~$8.49~~ $6.15 - + Add to cart
17	BOLT, FLANGE Part #: 95817-06030-00 Required per assembly: 2 ~~$4.65~~ $3.84 - + Add to cart
18	PIPE, FUEL, 1 Part #: 5UH-24311-00-00 Required per assembly: 1 ~~$43.99~~ $34.23 - + Add to cart
19	CLIP Part #: 90467-100A1-00 Required per assembly: 2 ~~$8.49~~ $6.27 - + Add to cart
20	HOSE (L400) Part #: 90445-088C5-00 Required per assembly: 1 ~~$6.49~~ $3.99 - + Add to cart
21	DAMPER, PLATE, 1 Part #: 5UH-F414H-01-00 Required per assembly: 1 $41.83 - + Add to cart
