Frame replacement parts for 2013 Yamaha Raptor 700

OEM Parts Yamaha 2013 Yamaha Raptor 700 Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FRAME COMP. Part #: 1PE-F1101-09-00 Required per assembly: 1 Not Available
2	REAR FRAME COMP. Part #: 1S3-21190-08-00 Required per assembly: 1 $841.54 - + Add to cart
3	SCREW Part #: 90149-10034-00 Required per assembly: 4 $9.49 $7.38 - + Add to cart
4	STAY, ENGINE, 2 Part #: 1S3-21315-10-00 Required per assembly: 1 $14.49 $9.39 - + Add to cart
5	BOLT, FLANGE Part #: 90105-08142-00 Required per assembly: 2 $6.49 $4.81 - + Add to cart
6	BOLT, FLANGE, (87Y) Part #: 95817-10055-00 Required per assembly: 1 $6.49 $4.46 - + Add to cart
7	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 1 $4.95 $4.10 - + Add to cart
8	STAY, ENGINE, 3 Part #: 1S3-21316-10-00 Required per assembly: 1 $17.98 $14.97 - + Add to cart
9	STAY, ENGINE, 3 Part #: 1S3-21317-10-00 Required per assembly: 1 $19.98 $16.16 - + Add to cart
10	BOLT, FLANGE Part #: 90105-08142-00 Required per assembly: 4 $6.49 $4.81 - + Add to cart
11	BOLT, FLANGE Part #: 95812-10110-00 Required per assembly: 1 $8.49 $5.76 - + Add to cart
12	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 1 $4.95 $4.10 - + Add to cart
13	BOLT, FLANGE Part #: 95817-10090-00 Required per assembly: 1 $10.49 $6.73 - + Add to cart
14	NUT, SELF-LOCKING Part #: 90185-10011-00 Required per assembly: 1 $4.95 $4.10 - + Add to cart
15	PROTECTOR, ENGINE Part #: 1PE-F1471-00-00 Required per assembly: 1 $52.14 - + Add to cart
16	BOLT Part #: 90109-06201-00 Required per assembly: 2 $6.49 $5.50 - + Add to cart
17	BOLT Part #: 90109-06172-00 Required per assembly: 2 $3.50 $2.66 - + Add to cart
18	TENSIONER Part #: 5TG-22178-01-00 Required per assembly: 1 $24.98 $19.26 - + Add to cart
19	BEARING Part #: 93300-60804-00 Required per assembly: 1 $13.49 $10.98 - + Add to cart
20	WASHER, PLATE Part #: 90201-08043-00 Required per assembly: 2 $8.49 $5.67 - + Add to cart
21	COLLAR Part #: 90387-08064-00 Required per assembly: 1 $9.99 $9.74 - + Add to cart
22	BOLT, FLANGE Part #: 95814-08045-00 Required per assembly: 1 $4.75 $3.87 - + Add to cart
23	BEARING Part #: 93306-20352-00 Required per assembly: 1 $36.99 $26.10 - + Add to cart
24	OIL, SEAL, SD-TYPE Part #: 93102-25081-00 Required per assembly: 1 $6.49 $4.02 - + Add to cart
25	OIL, SEAL, SD-TYPE Part #: 93102-25099-00 Required per assembly: 1 $14.49 $10.39 - + Add to cart
26	HOLDER, BEARING Part #: 2GU-23872-00-00 Required per assembly: 1 $28.98 $22.04 - + Add to cart
27	PLUG Part #: 90338-26004-00 Required per assembly: 2 $8.49 $6.24 - + Add to cart
28	PLUG Part #: 90338-24260-00 Required per assembly: 2 $6.49 $3.99 - + Add to cart
29	PLUG, SPEC'L, SHAPE Part #: 90338-20183-00 Required per assembly: 2 $12.49 $9.63 - + Add to cart
30	PLUG Part #: 90338-23004-00 Required per assembly: 2 $5.59 $3.46 - + Add to cart
31	CLAMP Part #: 5B4-F1338-00-00 Required per assembly: 2 $3.60 $2.98 - + Add to cart
32	CLAMP Part #: 90464-20213-00 Required per assembly: 3 $5.49 $3.49 - + Add to cart
33	BAND, SWITCH, CORD Part #: 25G-83936-01-00 Required per assembly: 1 $5.49 $4.05 - + Add to cart
34	DAMPER, STOPPER Part #: 1S3-2140A-00-00 Required per assembly: 1 $8.49 $6.27 - + Add to cart
35	TOOL KIT Part #: 1PE-F8100-01-00 Required per assembly: 1 $17.98 $13.70 - + Add to cart
36	GAUGE, AIR Part #: 1NV-2811A-01-00 Required per assembly: 1 $62.99 $49.61 - + Add to cart
37	BAND, BATTERY Part #: 116-82131-00-00 Required per assembly: 1 $34.99 $25.98 - + Add to cart
