2014 Honda CRF50F - Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.
Location Part Description
001

BAND, A3, WIRE

Part #: 32161-GEL-A80 Required per assembly: 1
$3.26
$3.03
003

LOCK SET

Part #: 35010-GEL-D60 Required per assembly: 1
$80.03
$66.83
004

KEY, BLANK, (TYPE2)

Part #: 35122-HF1-881
$11.11
$9.49
004

KEY, BLANK, (TYPE1)

Part #: 35121-HF1-881
$9.55
$9.49
005

FRAME *NH132M*

Part #: 50100-GEL-A80ZA Note: MAX SILVER METALLIC
$677.09
006

RUBBER, PIPE, END

Part #: 50351-GEL-A80 Required per assembly: 2
$1.96
$1.81
007

SPLASH GUARD

Part #: 80102-GEL-A80 Required per assembly: 1
$9.39
$8.54
009

BOLT, RR., ENGINE

Part #: 90116-GEL-A00 Required per assembly: 1
$6.80
$6.18
011

NUT, FLANGE, (8MM)

Part #: 94050-08000 Required per assembly: 2 Note: Sold in multiples of 5 only
$2.01
$1.96
012

BULK, HOSE, VINYL

Part #: 95003-25003-10M
$16.49
$14.57
013

BOLT, FLANGE, (8X110)

Part #: 95801-08110-00 Required per assembly: 1
$3.13
