Fender replacement parts for 2014 Yamaha FJR1300E

OEM Parts Yamaha 2014 Yamaha FJR1300E Fender

FENDER Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FENDER, FRONT Part #: 1MD-21511-00-P2 Required per assembly: 1 $201.20 - + Add to cart
2	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06043-00 Required per assembly: 4 ~~$5.49~~ $3.27 - + Add to cart
3	COLLAR Part #: 90387-06159-00 Required per assembly: 4 ~~$9.49~~ $6.27 - + Add to cart
4	GROMMET Part #: 90480-12072-00 Required per assembly: 4 ~~$9.49~~ $6.55 - + Add to cart
5	EMBLEM, YAMAHA Part #: 3WF-2153E-71-00 Required per assembly: 1 ~~$5.49~~ $4.40 - + Add to cart
6	FENDER, REAR Part #: 1MD-21611-00-00 Required per assembly: 1 $380.01 - + Add to cart
7	BOX Part #: 1MD-2160E-00-00 Required per assembly: 1 ~~$138.99~~ $138.68 - + Add to cart
8	BOLT, WITH, WASHER Part #: 90119-06159-00 Required per assembly: 4 ~~$9.49~~ $6.17 - + Add to cart
9	NUT, SPRING Part #: 90183-060A7-00 Required per assembly: 4 ~~$9.49~~ $6.37 - + Add to cart
10	COLLAR Part #: 90387-06231-00 Required per assembly: 2 ~~$5.49~~ $4.31 - + Add to cart
11	WASHER, PLATE Part #: 90201-07081-00 Required per assembly: 2 Note: (USA) ~~$11.49~~ $6.97 - + Add to cart
12	BOLT, FLANGE Part #: 95817-06040-00 Required per assembly: 2 ~~$6.49~~ $4.46 - + Add to cart
13	RIVET Part #: 90269-06081-00 Required per assembly: 4 ~~$8.49~~ $5.59 - + Add to cart
14	PLUG, SPEC'L, SHAPE Part #: 90338-08226-00 Required per assembly: 3 Note: Sold in multiples of 5 only ~~$2.35~~ $1.60 - + Add to cart
15	SCREW, TAPPING Part #: 97702-60016-00 Required per assembly: 3 ~~$2.35~~ $1.21 - + Add to cart
16	HOOK Part #: 5PS-2162A-00-00 Required per assembly: 1 ~~$3.89~~ $3.24 - + Add to cart
17	HOOK Part #: 4HM-2162A-00-00 Required per assembly: 2 ~~$4.34~~ $3.58 - + Add to cart
18	CLAMP Part #: 90464-13185-00 Required per assembly: 2 ~~$6.49~~ $3.64 - + Add to cart
19	RIVET, BLIND, (8K1) Part #: 90267-40076-00 Required per assembly: 6 ~~$9.49~~ $6.05 - + Add to cart
20	WASHER, PLAIN Part #: 92990-04200-00 Required per assembly: 2 ~~$1.86~~ $1.11 - + Add to cart
21	BAND Part #: 36X-2811G-00-00 Required per assembly: 1 ~~$6.49~~ $4.78 - + Add to cart
22	BAND, BATTERY Part #: 4J2-82131-01-00 Required per assembly: 1 ~~$32.99~~ $23.72 - + Add to cart
23	BAND Part #: 5JW-21647-01-00 Required per assembly: 2 ~~$11.99~~ $9.89 - + Add to cart
24	BAND Part #: 3P6-21647-00-00 Required per assembly: 1 ~~$9.49~~ $7.54 - + Add to cart
25	FLAP Part #: 5JW-21621-10-00 Required per assembly: 1 ~~$25.98~~ $19.25 - + Add to cart
26	COVER, REAR, FENDER Part #: 3P6-21651-00-P8 Required per assembly: 1 $97.70 - + Add to cart
27	COVER, TAIL, 1 Part #: 3P6-2471K-00-P8 Required per assembly: 1 ~~$174.99~~ $170.37 - + Add to cart
28	COVER, TAIL, 2 Part #: 3P6-2472K-00-P8 Required per assembly: 1 ~~$266.99~~ $237.61 - + Add to cart
29	NUT, SPRING Part #: 90183-051A0-00 Required per assembly: 4 ~~$4.09~~ $2.62 - + Add to cart
30	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-05044-00 Required per assembly: 8 ~~$8.49~~ $6.17 - + Add to cart
31	WASHER, PLATE Part #: 90202-05180-00 Required per assembly: 6 ~~$10.49~~ $6.32 - + Add to cart
32	NUT, SPRING Part #: 90183-050A0-00 Required per assembly: 4 ~~$6.49~~ $4.37 - + Add to cart
33	RIVET Part #: 90269-06081-00 Required per assembly: 4 ~~$8.49~~ $5.59 - + Add to cart
34	COVER, REAR, FENDER, 2 Part #: 3P6-2163E-01-P7 Required per assembly: 2 ~~$28.98~~ $22.70 - + Add to cart
35	COVER, REAR, FENDER, 2 Part #: 3P6-2163E-11-P7 Required per assembly: 2 ~~$43.99~~ $33.64 - + Add to cart
36	COVER, REAR, FENDER, 3 Part #: 3P6-2163F-01-P7 Required per assembly: 2 ~~$28.98~~ $22.57 - + Add to cart
37	DAMPER Part #: 3P6-21649-00-00 Required per assembly: 2 ~~$7.49~~ $6.27 - + Add to cart
38	COVER, REAR, FENDER, 1 Part #: 1MC-2163A-00-00 Required per assembly: 1 ~~$15.49~~ $12.61 - + Add to cart
39	RIVET Part #: 90269-06081-00 Required per assembly: 2 ~~$8.49~~ $5.59 - + Add to cart
40	YBS83-525, SCREW, PANH.TAPPING Part #: 97780-50125-00 Required per assembly: 1 ~~$3.10~~ $2.00 - + Add to cart
41	PLATE, ROUTING Part #: 13S-21684-10-00 Required per assembly: 1 ~~$9.99~~ $8.12 - + Add to cart
42	PLATE, ROUTING, 2, FOR, CALIFORNIA Part #: 1MC-21686-00-00 Required per assembly: 1 ~~$10.49~~ $8.60 - + Add to cart
43	TOOL KIT Part #: 1MC-28100-00-00 Required per assembly: 1 ~~$81.98~~ $73.74 - + Add to cart
44	FJR PROTECT STICKER SET Part #: 5JW-W9390-00-00 Required per assembly: 1 Not Available
