Electrical 2 replacement parts for 2014 Yamaha Vino Classic

OEM Parts Yamaha 2014 Yamaha Vino Classic Electrical 2

ELECTRICAL 2 Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	YTX5LBS YUASA BATTERY - SA Part #: YTX-5LBS0-00-00 Required per assembly: 1 $87.92 - + Add to cart
2	KEY SET Part #: 5ST-WH202-40-00 Required per assembly: 1 $90.98 $72.24 - + Add to cart
3	CASE, UNIT, 1 Part #: 5ST-F831B-00-00 Required per assembly: 1 $3.39 $2.81 - + Add to cart
4	SCREW, FLAT, HEAD Part #: 98707-04012-00 Required per assembly: 3 Note: Sold in multiples of 5 only $1.85 $1.41 - + Add to cart
5	CABLE, CONTROL, 1 Part #: 5ST-F637E-00-00 Required per assembly: 1 $16.48 $13.00 - + Add to cart
6	CABLE, SEAT, LOCK Part #: 5ST-F478E-00-00 Required per assembly: 1 $16.98 $13.96 - + Add to cart
7	SCREW, PAN, HEAD, (3LA) Part #: 98517-05010-00 Required per assembly: 1 $4.59 $3.46 - + Add to cart
8	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-05800-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
9	SCREW Part #: 90149-06813-00 Required per assembly: 1 Not Available
10	SCREW Part #: 90149-06814-00 Required per assembly: 2 Not Available
11	KNOB, 1 Part #: 5SU-F836X-00-00 Required per assembly: 1 $2.39 $1.01 - + Add to cart
12	WIRE HARNESS ASSEMBLY Part #: 1TS-H2590-01-00 Required per assembly: 1 Not Available
13	FUSE (15A) Part #: 5ML-H2151-10-00 Required per assembly: 1 $0.40 $0.30 - + Add to cart
14	CLAMP Part #: 90464-12812-00 Required per assembly: 1 $0.40 $0.31 - + Add to cart
15	BAND Part #: 1UA-82591-00-00 Required per assembly: 1 $5.49 $4.05 - + Add to cart
16	CLAMP Part #: 90464-60800-00 Required per assembly: 3 $0.70 $0.59 - + Add to cart
17	PROTECTOR Part #: 1TS-F117G-00-00 Required per assembly: 1 Not Available
18	CLAMP Part #: 90464-17803-00 Required per assembly: 1 Not Available
19	CLAMP Part #: 90464-20803-00 Required per assembly: 1 $0.45 $0.37 - + Add to cart
20	CLAMP Part #: 90464-16803-00 Required per assembly: 1 $0.35 $0.28 - + Add to cart
21	CLAMP Part #: 90464-30801-00 Required per assembly: 1 $2.04 $1.71 - + Add to cart
22	FLASHER RELAY ASSY Part #: 5XN-83350-02-00 Required per assembly: 1 $44.99 $36.98 - + Add to cart
