Oil Pump replacement parts for 2014 Yamaha Grizzly 350 4WD

OEM Parts Yamaha 2014 Yamaha Grizzly 350 4WD Oil Pump

OIL PUMP Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	OIL PUMP ASSEMBLY Part #: 5UH-13300-00-00 Required per assembly: 1 ~~$117.98~~ $97.58 - + Add to cart
2	GASKET, PUMP, COVER Part #: 5UH-13329-00-00 Required per assembly: 1 ~~$7.49~~ $6.35 - + Add to cart
3	BOLT, FLANGE Part #: 95022-06025-00 Required per assembly: 3 ~~$1.89~~ $1.44 - + Add to cart
4	COVER, PUMP, GEAR Part #: 5UH-13327-00-00 Required per assembly: 1 ~~$3.64~~ $3.02 - + Add to cart
5	BOLT, FLANGE Part #: 95022-06012-00 Required per assembly: 2 ~~$3.54~~ $2.95 - + Add to cart
6	STRAINER, OIL Part #: 5UH-13411-00-00 Required per assembly: 1 ~~$11.99~~ $7.88 - + Add to cart
7	BOLT, FLANGE Part #: 90105-05016-00 Required per assembly: 2 ~~$5.49~~ $4.31 - + Add to cart
8	BALL 5/16 Part #: 93505-16006-00 Required per assembly: 1 ~~$2.89~~ $2.16 - + Add to cart
9	SPRING, COMPRESSION Part #: 90501-101A7-00 Required per assembly: 1 ~~$9.49~~ $5.76 - + Add to cart
10	PLATE Part #: 5UH-1319K-00-00 Required per assembly: 1 ~~$1.60~~ $1.35 - + Add to cart
11	ELEMENT, ASSEMBLY, OIL, CLEANER Part #: 5GH-13440-90-00 Required per assembly: 1 $18.44 - + Add to cart
12	BOLT, UNION Part #: 90401-20008-00 Required per assembly: 1 ~~$25.98~~ $18.85 - + Add to cart
13	JOINT Part #: 1NS-13132-00-00 Required per assembly: 2 ~~$34.99~~ $27.50 - + Add to cart
14	GASKET 256131670000 Part #: 90430-14043-00 Required per assembly: 2 ~~$8.49~~ $6.35 - + Add to cart
15	BLOWER ASSY Part #: 1NS-E2405-01-00 Required per assembly: 1 ~~$251.99~~ $225.61 - + Add to cart
16	ELEMENT, OIL, COOLER Part #: 1NS-E3480-00-00 Required per assembly: 1 ~~$371.99~~ $344.11 - + Add to cart
17	CLIP Part #: 1NS-E3577-00-00 Required per assembly: 3 ~~$4.70~~ $3.90 - + Add to cart
18	BOLT 1 Part #: 1NS-E3573-00-00 Required per assembly: 3 Not Available
19	HOSE, OIL, 1 Part #: 1NS-E3464-10-00 Required per assembly: 1 ~~$36.99~~ $29.42 - + Add to cart
20	HOSE, OIL, 2 Part #: 1NS-E3465-10-00 Required per assembly: 1 $43.86 - + Add to cart
21	CLIP Part #: 90467-150A0-00 Required per assembly: 4 ~~$4.49~~ $4.08 - + Add to cart
22	GROMMET (2GH) Part #: 90480-12475-00 Required per assembly: 4 ~~$9.49~~ $6.55 - + Add to cart
23	COLLAR Part #: 90387-06113-00 Required per assembly: 4 ~~$12.49~~ $10.33 - + Add to cart
24	WASHER Part #: 90209-06012-00 Required per assembly: 4 ~~$6.49~~ $4.63 - + Add to cart
25	BOLT, FLANGE Part #: 95817-06020-00 Required per assembly: 4 ~~$3.50~~ $2.65 - + Add to cart
