Front Fork replacement parts for 2014 Yamaha YZFR1

OEM Parts Yamaha 2014 Yamaha YZFR1 Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H) Part #: 1KB-23102-10-00 Required per assembly: 1 ~~$919.99~~ $900.18 - + Add to cart
1	FRONT FORK ASSEMBLY (L.H) Part #: 1KB-23102-00-00 Required per assembly: 1 ~~$922.99~~ $880.52 - + Add to cart
2	INNER TUBE COMP.1 Part #: 1KB-23110-01-00 Required per assembly: 1 Not Available
3	OUTER TUBE COMP (LH) Part #: 14B-23106-00-00 Required per assembly: 1 Note: FOR RYC1(REDDISH YELLOW COCKTAIL 1),BWC1(BLUISH WHITE COCKTAIL 1) ~~$347.99~~ $340.26 - + Add to cart
3	OUTER TUBE COMP (LH) Part #: 14B-23106-10-00 Required per assembly: 1 Note: FOR SMX(BLACK METALLIC X) ~~$560.99~~ $536.04 - + Add to cart
4	SEAL, DUST Part #: 4TX-23144-01-00 Required per assembly: 1 ~~$25.98~~ $21.75 - + Add to cart
5	RING, SNAP Part #: 4TX-23156-00-00 Required per assembly: 1 $11.67 - + Add to cart
6	OIL SEAL Part #: 5VX-23145-00-00 Required per assembly: 1 ~~$31.98~~ $24.61 - + Add to cart
7	GUIDE, COVER, UPPER Part #: 4TX-23115-00-00 Required per assembly: 1 $10.69 - + Add to cart
8	CYL., COMP, 2 Part #: 1KB-2315K-00-00 Required per assembly: 1 ~~$293.99~~ $288.61 - + Add to cart
9	SPRING, VALVE Part #: 14B-2319M-00-00 Required per assembly: 1 $8.69 - + Add to cart
10	VALVE Part #: 14B-23109-00-00 Required per assembly: 1 $11.73 - + Add to cart
11	PLUNGER Part #: 14B-2318Y-00-00 Required per assembly: 1 Not Available
12	BOLT, CAP Part #: 14B-23111-00-00 Required per assembly: 1 ~~$304.99~~ $274.88 - + Add to cart
13	O-RING Part #: 93210-41N50-00 Required per assembly: 1 ~~$9.49~~ $8.44 - + Add to cart
14	NUT, SPECIAL Part #: 13S-23393-00-00 Required per assembly: 1 $14.51 - + Add to cart
15	PLATE, VALVE, 2 Part #: 13S-2332N-00-00 Required per assembly: 1 $8.76 - + Add to cart
16	WASHER, PLATE Part #: 90201-25291-00 Required per assembly: 1 $11.60 - + Add to cart
17	SPRING, FRONT, FORK Part #: 14B-23141-00-00 Required per assembly: 1 Not Available
18	SEAT, SPRING, UPPER Part #: 13S-23142-00-00 Required per assembly: 1 $4.32 - + Add to cart
19	SPACER Part #: 14B-23118-00-00 Required per assembly: 1 $10.98 - + Add to cart
20	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08035-00 Required per assembly: 2 $3.61 - + Add to cart
21	FRONT FORK ASSEMBLY (R.H) Part #: 1KB-23103-10-00 Required per assembly: 1 ~~$746.99~~ $735.16 - + Add to cart
21	FRONT FORK ASSEMBLY (R.H) Part #: 1KB-23103-00-00 Required per assembly: 1 $898.10 - + Add to cart
22	INNER TUBE COMP.2 Part #: 1KB-23120-01-00 Required per assembly: 1 $311.24 - + Add to cart
23	OUTER TUBE COMP (LH) Part #: 14B-23106-00-00 Required per assembly: 1 Note: FOR RYC1(REDDISH YELLOW COCKTAIL 1),BWC1(BLUISH WHITE COCKTAIL 1) ~~$347.99~~ $340.26 - + Add to cart
23	OUTER TUBE COMP (LH) Part #: 14B-23106-10-00 Required per assembly: 1 Note: FOR SMX(BLACK METALLIC X) ~~$560.99~~ $536.04 - + Add to cart
24	SEAL, DUST Part #: 4TX-23144-01-00 Required per assembly: 1 ~~$25.98~~ $21.75 - + Add to cart
25	RING, SNAP Part #: 4TX-23156-00-00 Required per assembly: 1 $11.67 - + Add to cart
26	OIL SEAL Part #: 5VX-23145-00-00 Required per assembly: 1 ~~$31.98~~ $24.61 - + Add to cart
27	GUIDE, COVER, UPPER Part #: 4TX-23115-00-00 Required per assembly: 1 $10.69 - + Add to cart
28	CYL., COMP, 3 Part #: 1KB-2315L-00-00 Required per assembly: 1 ~~$438.99~~ $426.32 - + Add to cart
29	SPRING, VALVE Part #: 14B-2319M-00-00 Required per assembly: 1 $8.69 - + Add to cart
30	VALVE Part #: 14B-23109-00-00 Required per assembly: 1 $11.73 - + Add to cart
31	PLUNGER Part #: 14B-2318Y-00-00 Required per assembly: 1 Not Available
32	BOLT, CAP, 2 Part #: 14B-2311J-00-00 Required per assembly: 1 ~~$352.99~~ $302.64 - + Add to cart
33	O-RING Part #: 93210-41N50-00 Required per assembly: 1 ~~$9.49~~ $8.44 - + Add to cart
34	NUT, SPECIAL Part #: 13S-23393-00-00 Required per assembly: 1 $14.51 - + Add to cart
35	PLATE, VALVE, 2 Part #: 13S-2332N-00-00 Required per assembly: 1 $8.76 - + Add to cart
36	WASHER, PLATE Part #: 90201-25291-00 Required per assembly: 1 $11.60 - + Add to cart
37	SPRING, FRONT, FORK Part #: 14B-23141-00-00 Required per assembly: 1 Not Available
38	SEAT, SPRING, UPPER Part #: 13S-23142-00-00 Required per assembly: 1 $4.32 - + Add to cart
39	SPACER Part #: 14B-23118-00-00 Required per assembly: 1 $10.98 - + Add to cart
40	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08035-00 Required per assembly: 2 $3.61 - + Add to cart
41	UNDER BRACKET COMP. Part #: 14B-23340-00-00 Required per assembly: 1 $592.39 - + Add to cart
42	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08030-00 Required per assembly: 4 $3.25 - + Add to cart
43	FORK SEALS KIT Part #: 5VX-W003B-00-00 Required per assembly: 1 ~~$47.99~~ $39.39 - + Add to cart
