Front Fork replacement parts for 2015 Yamaha FJR1300A

OEM Parts Yamaha 2015 Yamaha FJR1300A Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSEMBLY (L.H (L.H) Part #: 1MC-23102-00-00 Required per assembly: 1 $735.93 $678.03 - + Add to cart
2	INNER TUBE COMP.1 Part #: 3P6-23110-11-00 Required per assembly: 1 Not Available
3	METAL, SLIDE, 2 Part #: 4SV-23135-10-00 Required per assembly: 1 $22.98 $17.27 - + Add to cart
4	TUBE, OUTER, (LEFT), (LEFT) Part #: 1MC-23126-00-00 Required per assembly: 1 $385.99 $376.82 - + Add to cart
5	METAL, SLIDE, 1 Part #: 4SV-23125-10-00 Required per assembly: 1 $22.98 $17.10 - + Add to cart
6	METAL, SLIDE, 2 Part #: 3P6-23135-00-00 Required per assembly: 1 $22.98 $17.68 - + Add to cart
7	SEAL, DUST Part #: 4SV-23144-00-00 Required per assembly: 1 $17.98 $14.47 - + Add to cart
8	OIL SEAL Part #: 4SV-23145-01-00 Required per assembly: 1 $19.98 $16.45 - + Add to cart
9	GUIDE, COVER, UPPER Part #: 4SV-23115-00-00 Required per assembly: 1 $8.49 $6.97 - + Add to cart
10	RING, SNAP Part #: 4SV-23156-00-00 Required per assembly: 1 $8.49 $6.35 - + Add to cart
11	CYL., COMP., 2 Part #: 1MC-2315K-00-00 Required per assembly: 1 $261.99 $257.33 - + Add to cart
12	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-10N52-00 Required per assembly: 1 $8.49 $5.70 - + Add to cart
13	GASKET Part #: 90430-10171-00 Required per assembly: 1 $3.18 $2.65 - + Add to cart
14	SPRING, FRONT, FORK Part #: 1MC-23141-00-00 Required per assembly: 1 $89.98 $72.20 - + Add to cart
15	WASHER, PLATE Part #: 90201-140J1-00 Required per assembly: 2 $3.35 $2.78 - + Add to cart
16	SPACER Part #: 1MC-23118-00-00 Required per assembly: 1 $11.49 $9.24 - + Add to cart
17	BOLT, CAP Part #: 1MC-23111-00-00 Required per assembly: 1 $81.98 $73.69 - + Add to cart
18	O-RING Part #: 93210-40N50-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
19	COVER Part #: 4SV-2331G-00-00 Required per assembly: 1 $19.98 $14.95 - + Add to cart
20	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08045-00 Required per assembly: 2 $9.49 $6.68 - + Add to cart
21	FRONT FORK ASSEMBLY (R.H (R.H) Part #: 1MC-23103-00-00 Required per assembly: 1 Not Available
22	INNER TUBE COMP.1 Part #: 3P6-23110-11-00 Required per assembly: 1 Not Available
23	METAL, SLIDE, 2 Part #: 4SV-23135-10-00 Required per assembly: 1 $22.98 $17.27 - + Add to cart
24	OUTER TUBE COMP (RH) Part #: 3P6-23107-01-00 Required per assembly: 1 $666.99 $652.90 - + Add to cart
25	METAL, SLIDE, 1 Part #: 4SV-23125-10-00 Required per assembly: 1 $22.98 $17.10 - + Add to cart
26	METAL, SLIDE, 2 Part #: 3P6-23135-00-00 Required per assembly: 1 $22.98 $17.68 - + Add to cart
27	SEAL, DUST Part #: 4SV-23144-00-00 Required per assembly: 1 $17.98 $14.47 - + Add to cart
28	OIL SEAL Part #: 4SV-23145-01-00 Required per assembly: 1 $19.98 $16.45 - + Add to cart
29	GUIDE, COVER, UPPER Part #: 4SV-23115-00-00 Required per assembly: 1 $8.49 $6.97 - + Add to cart
30	RING, SNAP Part #: 4SV-23156-00-00 Required per assembly: 1 $8.49 $6.35 - + Add to cart
31	CYL., COMP., 3 Part #: 1MC-2315L-00-00 Required per assembly: 1 Not Available
32	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-10N52-00 Required per assembly: 1 $8.49 $5.70 - + Add to cart
33	GASKET Part #: 90430-10171-00 Required per assembly: 1 $3.18 $2.65 - + Add to cart
34	SPRING, FRONT, FORK Part #: 1MC-23141-00-00 Required per assembly: 1 $89.98 $72.20 - + Add to cart
35	WASHER, PLATE Part #: 90201-10321-00 Required per assembly: 1 $9.49 $5.32 - + Add to cart
36	SPACER Part #: 1MC-23118-10-00 Required per assembly: 1 $3.60 $2.98 - + Add to cart
37	BOLT, CAP, 2 Part #: 1MC-2311J-00-00 Required per assembly: 1 $145.99 $132.22 - + Add to cart
38	O-RING Part #: 93210-40N50-00 Required per assembly: 1 $9.49 $6.05 - + Add to cart
39	KNOB (TEN) Part #: 5JW-2319W-00-00 Required per assembly: 1 $11.99 $9.13 - + Add to cart
40	SCREW, OVAL, HEAD Part #: 98680-03008-00 Required per assembly: 1 $0.28 $0.25 - + Add to cart
41	NUT (3BM) Part #: 95314-10600-00 Required per assembly: 1 $2.54 $1.69 - + Add to cart
42	COVER Part #: 4SV-2331G-00-00 Required per assembly: 1 $19.98 $14.95 - + Add to cart
43	BOLT, HEXAGON, SOCKET, HEAD Part #: 91314-08045-00 Required per assembly: 2 $9.49 $6.68 - + Add to cart
44	UNDER BRACKET COMP. Part #: 1MC-23340-10-00 Required per assembly: 1 $446.99 $438.87 - + Add to cart
45	BOLT, SOCKET Part #: 91317-08025-00 Required per assembly: 4 $9.49 $6.12 - + Add to cart
46	FORK SEALS KIT Part #: 4SV-W003B-00-00 Required per assembly: 1 $37.99 $30.80 - + Add to cart
