Frame replacement parts for 2015 Yamaha Vino Classic

OEM Parts Yamaha 2015 Yamaha Vino Classic Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: 1TS-F1110-00-33 Required per assembly: 1 $586.73 - + Add to cart
2	BOLT, ENGINE, MOUNTING, 1 Part #: 5ST-F1481-00-00 Required per assembly: 1 $8.49 $6.24 - + Add to cart
3	NUT, SELF-LOCKING Part #: 9560L-10200-00 Required per assembly: 1 Not Available
4	BOLT, FLANGE Part #: 95817-10045-00 Required per assembly: 2 $6.99 $4.45 - + Add to cart
5	NUT, SELF-LOCKING Part #: 90185-10801-00 Required per assembly: 2 $1.96 $1.42 - + Add to cart
6	ENGINE BRACKET COMP. Part #: 5ST-F1410-10-00 Required per assembly: 1 Not Available
7	SPACER Part #: 5ST-F1459-00-00 Required per assembly: 1 $3.54 $2.81 - + Add to cart
8	COVER, DUST Part #: 5ST-F7235-00-00 Required per assembly: 2 $0.70 $0.59 - + Add to cart
9	DAMPER Part #: 5ST-F139X-00-00 Required per assembly: 1 $2.35 $1.01 - + Add to cart
10	PROTECTOR Part #: 5ST-F117G-00-00 Required per assembly: 1 $5.49 $4.57 - + Add to cart
11	BOLT, FLANGE Part #: 95817-06016-00 Required per assembly: 2 $1.95 $1.47 - + Add to cart
12	PROTECTOR Part #: 13P-F1652-00-00 Required per assembly: 1 $3.75 $3.08 - + Add to cart
13	BOLT, WITH, WASHER, (25K) Part #: 90119-06079-00 Required per assembly: 2 $1.25 $0.95 - + Add to cart
14	DAMPER Part #: 13P-F8371-00-00 Required per assembly: 2 $1.20 $0.98 - + Add to cart
15	HOLDER, FUEL, PIPE Part #: 13P-F1374-10-00 Required per assembly: 1 $3.04 $2.53 - + Add to cart
16	CLAMP Part #: 90464-30804-00 Required per assembly: 1 Not Available
17	NUT, CROWN Part #: 90176-06806-00 Required per assembly: 1 Not Available
18	DAMPER, LOCATING, 1 Part #: 5SW-F622F-00-00 Required per assembly: 1 Not Available
19	COVER 10 Part #: 37B-F117Y-00-00 Required per assembly: 1 Not Available
20	DAMPER 1 Part #: 5ML-F1541-00-00 Required per assembly: 2 $0.45 $0.32 - + Add to cart
21	HOLDER, CABLE Part #: 3P3-F1164-00-00 Required per assembly: 1 $5.99 $4.63 - + Add to cart
22	NUT, FLANGE, (4MV) Part #: 95707-06500-00 Required per assembly: 2 $1.00 $0.77 - + Add to cart
23	PROTECTOR Part #: 1TS-F1652-00-00 Required per assembly: 1 Not Available
24	BRACKET, CANISTOR Part #: 13P-F419F-10-00 Required per assembly: 1 $4.65 $3.87 - + Add to cart
