Frame replacement parts for 2015 Yamaha V Star 1300

OEM Parts Yamaha 2015 Yamaha V Star 1300 Frame

FRAME Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME COMP. Part #: 3D8-21110-40-00 Required per assembly: 1 $3,009.32 - + Add to cart
2	DOWN TUBE COMP.2 Part #: 3D8-21150-11-00 Required per assembly: 1 $409.13 - + Add to cart
3	BOLT, HEXAGON, SOCKET, HEAD Part #: 90110-10017-00 Required per assembly: 4 $6.49 $5.16 - + Add to cart
4	STAY, ENGINE, 3 Part #: 3D8-21317-10-00 Required per assembly: 1 $178.99 $167.30 - + Add to cart
5	PROTECTOR Part #: 3MA-27491-00-00 Required per assembly: 1 $9.49 $7.88 - + Add to cart
6	BOLT, HEX, SOCKET, BUTTON Part #: 90111-10028-00 Required per assembly: 2 $7.49 $6.17 - + Add to cart
7	BOLT, HEX, SOCKET, BUTTON Part #: 90111-10030-00 Required per assembly: 2 $6.49 $5.28 - + Add to cart
8	STAY, ENGINE, 5 Part #: 3D8-21314-00-00 Required per assembly: 1 $17.48 $14.53 - + Add to cart
9	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
10	BOLT, FLANGE Part #: 90105-12043-00 Required per assembly: 1 $15.49 $12.52 - + Add to cart
11	NUT, SELF-LOCKING Part #: 90185-12002-00 Required per assembly: 1 $13.49 $9.87 - + Add to cart
12	STAY, ENGINE, 3 Part #: 3D8-21316-00-00 Required per assembly: 1 $21.98 $17.68 - + Add to cart
13	BOLT, FLANGE Part #: 95817-10020-00 Required per assembly: 2 $8.49 $5.15 - + Add to cart
14	BOLT, FLANGE Part #: 90105-12044-00 Required per assembly: 1 $23.98 $18.81 - + Add to cart
15	NUT, SELF-LOCKING Part #: 90185-12002-00 Required per assembly: 1 $13.49 $9.87 - + Add to cart
16	BOLT, FLANGE Part #: 90105-12045-00 Required per assembly: 1 $22.98 $17.93 - + Add to cart
17	NUT, SELF-LOCKING Part #: 90185-12002-00 Required per assembly: 1 $13.49 $9.87 - + Add to cart
18	BRACKET, LH. Part #: 3D8-2119W-10-00 Required per assembly: 1 $13.49 $11.02 - + Add to cart
19	BOLT, BUTTON, HEAD Part #: 92012-06012-00 Required per assembly: 1 $4.70 $2.45 - + Add to cart
20	BRACKET, COIL Part #: 3D8-21359-01-00 Required per assembly: 1 $31.98 $26.49 - + Add to cart
21	BOLT (33M) Part #: 91312-06014-00 Required per assembly: 2 $5.49 $4.66 - + Add to cart
22	COVER, SIDE, 5 Part #: 3D8-2171E-01-00 Required per assembly: 1 $47.99 $40.08 - + Add to cart
23	COVER, SIDE, 6 Part #: 3D8-2171X-01-00 Required per assembly: 1 $47.99 $40.08 - + Add to cart
24	COLLAR Part #: 90387-06071-00 Required per assembly: 2 $9.49 $6.56 - + Add to cart
25	RIVET, SPEC'L, SHAPE Part #: 90269-07076-00 Required per assembly: 2 $8.49 $5.88 - + Add to cart
26	BOLT, HEXAGON, SOCKET, BUTTON Part #: 90111-06061-00 Required per assembly: 2 $9.49 $6.15 - + Add to cart
27	PROTECTOR Part #: 3D8-2117G-00-00 Required per assembly: 1 Not Available
28	DAMPER 3 Part #: 4XY-2834E-00-00 Required per assembly: 1 $3.64 $3.02 - + Add to cart
29	DAMPER Part #: 3D8-2113B-00-00 Required per assembly: 1 Not Available
30	DAMPER Part #: 5H0-8235Y-M0-00 Required per assembly: 1 Note: Sold in multiples of 5 only $7.49 $6.35 - + Add to cart
31	PROTECTOR Part #: 3MA-27491-00-00 Required per assembly: 1 $9.49 $7.88 - + Add to cart
