Body And Accessories replacement parts for 2016 Can Am Renegade

OEM Parts Can Am 2016 Can Am Renegade Body And Accessories

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

10	PROTECTIVE PLATE KIT. EXCEPT PACKAGE STD Part #: 715002374 Required per assembly: 1 Currently Not Available
10	CENTRAL SKID PLATE. PACKAGE HUNTER Part #: 705204031 Required per assembly: 1 Currently Not Available
14a	SQUARE NUT M6 Part #: 232862412 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
15	SKID PLATE Part #: 705007820 Required per assembly: 1 Currently Not Available
15a	SQUARE NUT M6 Part #: 232862412 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
20	HEX. FLANGED SCREW M6 X 20. EXCEPT PACKAGE STD Part #: 207662054 Currently Not Available
25	CARRIAGE BOLT M6 X 20. EXCEPT PACKAGE STD Part #: 207762044 Note: Sold in multiples of 10 only Currently Not Available
26	TORX SCREW M6 X 20 Part #: 250000712 Required per assembly: 2 Currently Not Available
27	FLAT WASHER Part #: 234062670 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
30	FLANGED ELASTIC NUT M6. EXCEPT PACKAGE STD Part #: 233261434 Note: Sold in multiples of 8 only Currently Not Available
35	HEX. FLANGED ELASTIC NUT M8. PACKAGE HUNTER Part #: 233281434 Required per assembly: 2 Currently Not Available
37	HEX. FLANGED SCREW M8 X 25. MODEL-XT Part #: 207682534 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
40	BUMPER SUPPORT Part #: 705003505 Required per assembly: 1 Currently Not Available
60	HEX. FLANGED ELASTIC NUT M8. PACKAGE HUNTER Part #: 233281434 Required per assembly: 7 Currently Not Available
65	INSERT Part #: 250100199 Required per assembly: 2 Currently Not Available
67	SCREW-PAN HD.TORX BLACK S.GRIP M8X20 Part #: 250000740 Required per assembly: 2 Currently Not Available
70	LH FOOTBOARD Part #: 705004176 Required per assembly: 1 Currently Not Available
70	RH FOOTBOARD Part #: 705004177 Required per assembly: 1 Currently Not Available
85	HEX FLANGED SCREW M8 X 25 (SCOTCH GRIP) Part #: 207582544 Required per assembly: 2 $1.40 $1.13 - + Add to cart
90	CARRIAGE BOLT M6 X 30 Part #: 207763044 Required per assembly: 8 Currently Not Available
95	BALL HEAD STUD Part #: 250300039 Required per assembly: 1 Currently Not Available
100	FLAT WASHER 6 MM Part #: 234062410 Required per assembly: 8 Currently Not Available
110	LH FOOTBOARD/FENDER Part #: 705004730 Required per assembly: 1 Currently Not Available
110	RH FOOTBOARD/FENDER Part #: 705004729 Required per assembly: 1 Currently Not Available
125	FOOTREST Part #: 705002326 Required per assembly: 2 Currently Not Available
130	HEX. FLANGED SCREW M6 X 16 Part #: 207661654 Required per assembly: 4 $1.72 $1.40 - + Add to cart
145	OVAL WASHER Part #: 705000321 Required per assembly: 9 Note: Sold in multiples of 2 only Currently Not Available
150	ENGINE COVER SUPPORT Part #: 705011461 Required per assembly: 1 Currently Not Available
160	ENGINE COVER SUPPORT Part #: 705003646 Required per assembly: 1 Currently Not Available
165	HEX. FLANGED SCREW M6 X 12. EXCEPT PACKAGE XMR Part #: 210261250 Required per assembly: 3 Currently Not Available
190	HEX. FLANGED SCREW M6 X 12, SCOTCH GRIP Part #: 207561244 Required per assembly: 1 Currently Not Available
200	LEVER INDICATOR Part #: 705003838 Required per assembly: 1 Currently Not Available
200	LEVER INDICATOR Part #: 705004416 Required per assembly: 1 Currently Not Available
220	HEX. FLANGED SCREW M6 X 30, SCOTCH GRIP Part #: 207563034 Required per assembly: 2 Note: Sold in multiples of 5 only Currently Not Available
230	FLAT WASHER Part #: 224061201 Required per assembly: 7 Currently Not Available
250	FRONT FACIA Part #: 705003948 Required per assembly: 1 Currently Not Available
260	BLACK FRONT FENDER KIT. PACKAGE XXC, MODEL RED/WHITE/BLACK, NORTH AMERICA Part #: 715002154 Required per assembly: 1 Currently Not Available
260	BLACK FRONT FENDER KIT. PACKAGE XXC, MODEL RED/WHITE/BLACK EXCEPT NORTH AMERICA Part #: 715002155 Required per assembly: 1 Currently Not Available
260	KIT FR. FENDER Part #: 715002550 Required per assembly: 1 Currently Not Available
260	KIT FENDER Part #: 715002570 Required per assembly: 1 Currently Not Available
260	RED FRONT FENDER KIT. PACKAGE STD, NORTH AMERICA Part #: 715003158 Required per assembly: 1 Currently Not Available
280	WELDED FRONT BUMPER. RED MODEL Part #: 705011635 Required per assembly: 1 Currently Not Available
285	HEX. FLANGED SCREW M6 X 25 Part #: 207662554 Required per assembly: 4 Currently Not Available
300	DASHBOARD Part #: 705003556 Required per assembly: 1 Currently Not Available
315	PAINTED BRACKET Part #: 705003599 Required per assembly: 1 Currently Not Available
320	FRONT TUBE Part #: 705003511 Required per assembly: 1 Currently Not Available
325	SUPPORT Part #: 705002282 Required per assembly: 1 Currently Not Available
330	BODY TUBE Part #: 705003510 Required per assembly: 1 Currently Not Available
370	HEX. FLANGED SCREW M6 X 35 Part #: 207663544 Required per assembly: 5 Note: Sold in multiples of 25 only Currently Not Available
390	INSERT Part #: 293450275 Required per assembly: 4 Currently Not Available
400	TORX SCREW M6 X 25 Part #: 250000758 Required per assembly: 9 Currently Not Available
410	FUSE HOLDER Part #: 710002482 Required per assembly: 1 Currently Not Available
415	POP RIVET 3/16" Part #: 390402400 Required per assembly: 2 $0.80 $0.69 - + Add to cart
420	HEX. FLANGED SCREW M8 X 25. MODEL-XT Part #: 207682534 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
430	FLANGED HEX. SCREW M6 X 45 Part #: 207664544 Required per assembly: 2 $1.05 $0.86 - + Add to cart
450	HEX. FLANGED SCREW M6 X 50 Part #: 207665044 Required per assembly: 1 $3.39 $2.75 - + Add to cart
460	SPACER Part #: 705005809 Required per assembly: 1 Currently Not Available
480	LEFT GRILL Part #: 705008137 Required per assembly: 1 Currently Not Available
485	RIGHT GRILL Part #: 705008138 Required per assembly: 1 Currently Not Available
490	KIT REAR FENDE Part #: 715002575 Required per assembly: 1 Currently Not Available
490	BLACK REAR FENDER KIT. PACKAGE XXC, MODEL RED/WHITE/BLACK, EUROPE Part #: 715002165 Required per assembly: 1 Currently Not Available
490	KIT REAR FENDE Part #: 715002572 Required per assembly: 1 Currently Not Available
490	BLACK REAR FENDER KIT. MODEL XXC (NORTH AMERICA) Part #: 715001887 Required per assembly: 1 Currently Not Available
490	REAR FENDER ASSEMBLY Part #: 715002574 Required per assembly: 1 Currently Not Available
490	BLACK REAR FENDER KIT. PACKAGE XXC, MODEL RED/WHITE/BLACK, INTERNATIONAL Part #: 715002164 Required per assembly: 1 Currently Not Available
490	RED REAR FENDER KIT. PACKAGE STD, NORTH AMERICA Part #: 715003166 Required per assembly: 1 Currently Not Available
495	REFLECTIVE SHEET Part #: 705005840 Required per assembly: 1 Currently Not Available
505	TRUSS HEAD TORX SCREW K50 X 16 Part #: 250000720 Required per assembly: 6 Currently Not Available
510	LH REAR FACIA Part #: 705004731 Required per assembly: 1 Currently Not Available
510	LH REAR FACIA. EUROPE MODEL Part #: 705004927 Required per assembly: 1 Currently Not Available
510	RH REAR FACIA Part #: 705004732 Required per assembly: 1 Currently Not Available
510	RH REAR FACIA. EUROPE MODEL Part #: 705004926 Required per assembly: 1 Currently Not Available
530	RED REFLECTOR. EXCEPT EUROPE MODEL Part #: 705011221 Required per assembly: 4 Currently Not Available
535	AMBER REFLECTOR Part #: 705011222 Required per assembly: 2 Currently Not Available
540	FLANGED ELASTIC NUT M5. EXCEPT EUROPE MODEL Part #: 233251434 Required per assembly: 6 $1.72 $1.40 - + Add to cart
575	OBLONG GROMMET Part #: 705003668 Required per assembly: 2 Currently Not Available
600	FRONT BUMPER PLATE Part #: 705004850 Required per assembly: 1 Currently Not Available
620	HEX. FLANGED SCREW M8 X 20 Part #: 207682044 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
650	SQUARE NUT M6 Part #: 232862412 Required per assembly: 2 Note: Sold in multiples of 10 only Currently Not Available
660	BLACK PAINT LATERAL PANEL LH Part #: 705002958 Required per assembly: 1 Currently Not Available
660	BLACK PAINT SIDE PANEL RH Part #: 705002959 Required per assembly: 1 Currently Not Available
660	WHITE PAINT SIDE PANEL RH. RED MODEL Part #: 705010133 Required per assembly: 1 Currently Not Available
660	DIGITAL CAMO RH SIDE PANEL Part #: 705010571 Required per assembly: 1 Currently Not Available
660	DIGITAL CAMO LH SIDE PANEL Part #: 705010570 Required per assembly: 1 Currently Not Available
660	WHITE PAINT LATERAL PANEL LH. RED MODEL Part #: 705010132 Required per assembly: 1 Currently Not Available
665	TORX SCREW M6 X 12 Part #: 250000454 Required per assembly: 2 Note: Sold in multiples of 2 only Currently Not Available
675	TORX SCREW M6 X 16 Part #: 250000755 Required per assembly: 6 Currently Not Available
680	PANEL EXTENSION Part #: 705004988 Required per assembly: 1 Currently Not Available
690	ENGINE COVER Part #: 705004966 Required per assembly: 1 Currently Not Available
700	WHITE CENTRAL PANEL KIT. ENGINE 570 EFI Part #: 715001461 Required per assembly: 1 Note: White North America, White International. Currently Not Available
700	MIDDLE PANEL Part #: 715002581 Required per assembly: 1 Currently Not Available
700	MIDDLE PANEL Part #: 715002577 Required per assembly: 1 Currently Not Available
700	RED CENTRAL PANEL KIT Part #: 715003174 Required per assembly: 1 Currently Not Available
700	WHITE CENTRAL PANEL KIT. RED MODEL Part #: 715003178 Required per assembly: 1 Currently Not Available
700	RED CENTRAL PANEL KIT Part #: 715003176 Required per assembly: 1 Currently Not Available
710	CAP Part #: 705002353 Required per assembly: 1 Currently Not Available
720	GROMMET Part #: 705003264 Required per assembly: 6 Currently Not Available
740	RH INNER FENDER Part #: 705004308 Required per assembly: 1 Currently Not Available
740	LH INNER FENDER Part #: 705004307 Required per assembly: 1 Currently Not Available
765	FLAT WASHER Part #: 234062670 Required per assembly: 1 Note: Sold in multiples of 10 only Currently Not Available
766	TORX SCREW M6 X 20 Part #: 250000722 Required per assembly: 1 Currently Not Available
770	TUFLOK PLASTIC RIVET Part #: 293150230 Required per assembly: 4 $1.45 $1.19 - + Add to cart
800	CLIP Part #: 414479100 Required per assembly: 3 Note: Sold in multiples of 10 only Currently Not Available
820	RUBBER PLUG, BLACK Part #: 293830005 Required per assembly: 1 Currently Not Available
880	LH CAP, BLACK Part #: 705001910 Required per assembly: 1 Currently Not Available
890	NECK CAP Part #: 705002420 Required per assembly: 1 Currently Not Available
910	REAR CARPET Part #: 705002343 Required per assembly: 1 Currently Not Available
920	HOOK Part #: 705002342 Required per assembly: 4 Currently Not Available
930	TORX SCREW M6 X 16 Part #: 250000755 Required per assembly: 8 Currently Not Available
