Swingarm replacement parts for 2016 Honda CB1000R

OEM Parts Honda 2016 Honda CB1000R Swingarm

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	CASE, A, DRIVE, CHAIN Part #: 40510-MFN-D00 Required per assembly: 1 $6.05 $5.33 - + Add to cart
002	GUIDE, RR., BRAKE, AIR Part #: 40515-MFN-D00 Required per assembly: 1 $7.41 $6.85 - + Add to cart
003	CASE, B, DRIVE, CHAIN Part #: 40520-MFN-D00 Required per assembly: 1 $4.84 - + Add to cart
004	MASTER LINK Part #: 40535-MZ1-316 Required per assembly: 1 $11.13 $9.37 - + Add to cart
005	CHAIN, DRIVE, (DID50, VA8-120ZB)(DAIDO) Part #: 40540-MZ1-316 $333.94 $270.29 - + Add to cart
006	STOPPER, TORQUE, LINK Part #: 43433-KV3-951 Required per assembly: 1 $13.29 $10.76 - + Add to cart
007	BOLT, SWINGARM, PIVOT Part #: 52101-MCZ-000 Required per assembly: 1 $36.87 $29.84 - + Add to cart
008	COLLAR, A, PIVOT, DISTANCE Part #: 52141-MER-D00 Required per assembly: 1 $11.20 $9.43 - + Add to cart
009	COLLAR, B, PIVOT, DISTANCE Part #: 52142-MER-D00 Required per assembly: 1 $23.90 $19.34 - + Add to cart
010	COLLAR, PIVOT, DISTANCE Part #: 52143-MER-D00 Required per assembly: 1 $43.15 $34.93 - + Add to cart
011	SLIDER, CHAIN Part #: 52170-MFN-D00 Required per assembly: 1 $17.36 $13.85 - + Add to cart
012	GUIDE, CHAIN Part #: 52180-MFN-D00 Required per assembly: 1 $3.86 - + Add to cart
013	GROMMET, SWINGARM Part #: 52190-MFN-D00 Required per assembly: 2 $1.96 $1.81 - + Add to cart
015	SCREW, SPECIAL, (5X12) Part #: 90111-MFN-D00 Required per assembly: 6 $2.73 $2.54 - + Add to cart
016	SCREW (5X14) Part #: 90114-KPB-750 Required per assembly: 4 $3.27 $3.04 - + Add to cart
017	BOLT, FLANGE, (16X51) Part #: 90155-MBG-000 Required per assembly: 1 $17.37 $14.05 - + Add to cart
018	NUT, U, (18MM) Part #: 90306-MCS-G01 Required per assembly: 1 $8.18 $7.13 - + Add to cart
019	WASHER (20X31.5X2) Part #: 90401-MAS-000 Required per assembly: 1 $4.53 $4.12 - + Add to cart
020	WASHER, PLAIN, (16MM) Part #: 90559-HA8-000 Required per assembly: 1 $7.14 $6.29 - + Add to cart
021	BEARING, NEEDLE Part #: 91071-MR7-003 Required per assembly: 1 $29.77 $24.10 - + Add to cart
022	BEARING (20X37X9) Part #: 91072-MR7-003 Required per assembly: 2 $20.87 $17.40 - + Add to cart
023	DUST SEAL (28X37X4) Part #: 91202-MR7-003 Required per assembly: 3 $7.64 $6.68 - + Add to cart
024	DUST SEAL (27X34X4) Part #: 91261-KZ3-861 Required per assembly: 1 $9.36 $8.08 - + Add to cart
025	O-RING (21.8X2.4) Part #: 91355-759-003 Required per assembly: 1 $2.73 $2.54 - + Add to cart
026	CIRCLIP (37MM) Part #: 94520-37000 Required per assembly: 1 $3.15 $2.93 - + Add to cart
027	BOLT, FLANGE, (6X8) Part #: 96001-06008-07 Required per assembly: 2 $1.98 $1.83 - + Add to cart
