Throttle Body replacement parts for 2016 Honda SXS1000M5P

OEM Parts Honda 2016 Honda SXS1000M5P Throttle Body

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	SENSOR SET Part #: 16060-HL4-003 Required per assembly: 1 ~~$97.75~~ $79.91 - + Add to cart
002	SCREW-WASHER Part #: 16080-HP5-601 Required per assembly: 1 ~~$3.10~~ $2.89 - + Add to cart
003	SCREW, TORX, (5X8.7) Part #: 16081-KPH-701 Required per assembly: 2 $4.03 - + Add to cart
004	SCREW, TORX, (5X17) Part #: 16082-KPH-701 Required per assembly: 1 ~~$5.76~~ $5.30 - + Add to cart
005	O-RING, SENSOR Part #: 16083-HL4-003 Required per assembly: 1 ~~$9.71~~ $8.45 - + Add to cart
006	O-RING, SENSOR Part #: 16084-HL4-003 Required per assembly: 1 ~~$7.96~~ $7.13 - + Add to cart
007	PLATE Part #: 16085-MGZ-D01 Required per assembly: 1 $3.15 - + Add to cart
008	COVER, BODY Part #: 16157-HN8-A61 Required per assembly: 1 $3.83 - + Add to cart
009	STAY, HARNESS, CLAMP Part #: 16196-HP6-A01 Required per assembly: 2 ~~$9.55~~ $8.82 - + Add to cart
010	BODY, ASSEMBLY, THROTTLE, (GQA4A, A), (NA, USE, ALT:, 16400-HL4-003) Part #: 16400-HL4-013 Required per assembly: 1 ~~$417.20~~ $347.70 - + Add to cart
011	BODY SET Part #: 16410-HL4-003 Required per assembly: 1 ~~$165.33~~ $135.15 - + Add to cart
012	O-RING Part #: 16428-HL4-003 Required per assembly: 1 ~~$13.69~~ $11.19 - + Add to cart
013	VALVE SET Part #: 16430-HL4-003 Required per assembly: 1 ~~$118.71~~ $98.96 - + Add to cart
014	MOTOR ASSEMBLY Part #: 16431-HL4-003 Required per assembly: 1 ~~$72.44~~ $59.22 - + Add to cart
015	PLATE Part #: 16433-MEW-921 Required per assembly: 1 ~~$11.31~~ $9.65 - + Add to cart
016	O-RING Part #: 16434-HL4-003 Required per assembly: 1 ~~$9.95~~ $8.63 - + Add to cart
017	O-RING (17.8X1.9) Part #: 16435-HN8-A61 Required per assembly: 1 ~~$10.45~~ $9.06 - + Add to cart
018	PLATE Part #: 16435-MEH-003 Required per assembly: 1 ~~$8.19~~ $7.14 - + Add to cart
019	INJECTOR, ASSEMBLY, FUEL Part #: 16450-HL4-013 Required per assembly: 2 ~~$82.55~~ $67.48 - + Add to cart
020	BODY Part #: 16451-HL4-003 Required per assembly: 1 ~~$49.45~~ $39.44 - + Add to cart
021	RING, SEAL Part #: 16472-KPC-D50 Required per assembly: 2 ~~$3.21~~ $2.99 - + Add to cart
022	DUST SEAL RING Part #: 16473-HR3-A42 Required per assembly: 2 ~~$7.35~~ $6.66 - + Add to cart
023	PIPE, FUEL Part #: 16610-HL4-003 Required per assembly: 1 ~~$17.87~~ $14.25 - + Add to cart
024	PIPE, FUEL Part #: 16620-HL4-003 Required per assembly: 1 ~~$11.79~~ $9.91 - + Add to cart
025	T-JOINT, FUEL Part #: 16630-MFJ-D00 Required per assembly: 1 ~~$25.65~~ $21.39 - + Add to cart
026	STAY, HOSE, CLAMP Part #: 17567-HL4-003 Required per assembly: 1 ~~$6.91~~ $6.30 - + Add to cart
027	BOLT, SHOULDER Part #: 90021-MGZ-D02 Required per assembly: 4 ~~$3.93~~ $3.57 - + Add to cart
028	O-RING (6.3X2.2) Part #: 91301-KZL-931 Required per assembly: 2 ~~$10.20~~ $10.10 - + Add to cart
029	O-RING (7.47X3.6) Part #: 91301-PLC-000 Required per assembly: 2 ~~$4.72~~ $4.29 - + Add to cart
030	SCREW, PAN, (4X8) Part #: 93500-04008-0H Required per assembly: 2 ~~$1.95~~ $1.80 - + Add to cart
030	SCREW, PAN, (4X8) Part #: 93500-04008-0H Required per assembly: 2 ~~$1.95~~ $1.80 - + Add to cart
031	SCREW, PAN, (5X10) Part #: 93500-05010-0H Required per assembly: 3 ~~$1.95~~ $1.80 - + Add to cart
031	SCREW, PAN, (5X10) Part #: 93500-05010-0H Required per assembly: 3 ~~$1.95~~ $1.80 - + Add to cart
031	SCREW, PAN, (5X10) Part #: 93500-05010-0H Required per assembly: 3 ~~$1.95~~ $1.80 - + Add to cart
