Gearshift Drum replacement parts for 2016 Honda TRX250X

OEM Parts Honda 2016 Honda TRX250X Gearshift Drum

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

001	FORK, FR., GEARSHIFT Part #: 24211-HN6-000 Required per assembly: 1 $59.38 $53.98 - + Add to cart
002	FORK Part #: 24212-HN6-000 Required per assembly: 1 $59.38 $53.98 - + Add to cart
003	SWINGARM, GEARSHIFT Part #: 24213-HN6-000 Required per assembly: 1 $64.74 $52.40 - + Add to cart
004	SHAFT Part #: 24241-HF1-670 Required per assembly: 1 $22.00 $17.81 - + Add to cart
005	DRUM, GEARSHIFT Part #: 24301-HN6-A00 Required per assembly: 1 $92.24 $74.66 - + Add to cart
006	SHIFTER, DRUM Part #: 24321-HN6-A30 Required per assembly: 1 $10.65 $9.13 - + Add to cart
007	PLATE, SHIFT, GUIDE Part #: 24328-HB3-000 Required per assembly: 1 $8.64 $7.49 - + Add to cart
008	STOPPER Part #: 24430-HM8-A40 Required per assembly: 1 $13.38 $10.83 - + Add to cart
009	SPRING Part #: 24435-HM8-A40 Required per assembly: 1 $3.09 $2.87 - + Add to cart
010	SPINDLE, GEARSHIFT Part #: 24611-HM8-A40 Required per assembly: 1 $55.59 $46.34 - + Add to cart
011	ARM Part #: 24620-HN6-A30 Required per assembly: 1 $41.39 $34.51 - + Add to cart
012	PLATE, GEARSHIFT Part #: 24631-HM8-A40 Required per assembly: 1 $15.50 $12.93 - + Add to cart
013	SPRING, SHIFT, ARM Part #: 24641-HB3-004 Required per assembly: 1 $3.93 $3.57 - + Add to cart
014	SPRING Part #: 24651-HN6-A30 Required per assembly: 1 $7.11 $6.26 - + Add to cart
015	PIN, RETURN, SPRING Part #: 24652-KY4-900 Required per assembly: 1 $9.60 $8.27 - + Add to cart
016	ARM, A, GEARSHIFT Part #: 24661-HN5-670 Required per assembly: 1 $25.97 $21.65 - + Add to cart
017	SPINDLE Part #: 24680-HN6-A30 Required per assembly: 1 $73.30 $61.12 - + Add to cart
018	PLATE A Part #: 24860-HM8-A40 Required per assembly: 1 $17.33 $14.02 - + Add to cart
019	LEVER Part #: 24865-HN5-670 Required per assembly: 1 $5.41 $4.86 - + Add to cart
020	SPRING Part #: 24867-HN6-A30 Required per assembly: 1 $4.41 - + Add to cart
021	BOLT (6X15.2) Part #: 90009-HN5-670 Required per assembly: 1 $3.57 - + Add to cart
022	PIVOT Part #: 90022-HM8-A40 Required per assembly: 1 $3.51 $3.19 - + Add to cart
023	NUT, U, (6MM) Part #: 90301-473-003 Required per assembly: 1 $5.46 $4.96 - + Add to cart
024	WASHER Part #: 90407-HM8-A40 Required per assembly: 1 $4.00 $3.64 - + Add to cart
025	WASHER Part #: 90408-HM8-A40 Required per assembly: 1 $2.92 $2.71 - + Add to cart
026	WASHER (10X21.5) Part #: 90413-GE0-000 Required per assembly: 1 $5.28 $4.80 - + Add to cart
027	WASHER, DRUM, STOPPER Part #: 90417-360-000 Required per assembly: 1 $2.73 $2.54 - + Add to cart
028	WASHER (6MM) Part #: 90442-397-000 Required per assembly: 1 $3.50 $3.18 - + Add to cart
029	WASHER (12MM) Part #: 90451-GF6-000 Required per assembly: 1 $3.19 $2.97 - + Add to cart
030	WASHER (12MM) Part #: 90452-166-600 Required per assembly: 2 $3.43 $3.12 - + Add to cart
031	WASHER, CRANK, ARM Part #: 90545-044-000 Required per assembly: 1 $2.83 $2.57 - + Add to cart
032	BEARING (6807) Part #: 91008-HS0-A01 Required per assembly: 1 $46.80 $38.27 - + Add to cart
033	CIRCLIP (12MM) Part #: 94510-12000 Required per assembly: 2 $2.86 $2.65 - + Add to cart
034	BOLT, FLANGE, (6X20) Part #: 95701-06020-00 Required per assembly: 1 $2.63 $2.44 - + Add to cart
035	ROLLER (4X13.8) Part #: 96220-40138 Required per assembly: 1 $1.60 $1.46 - + Add to cart
