Frame replacement parts for 2016 Suzuki DL1000A V-Strom

OEM Parts Suzuki 2016 Suzuki DL1000A V Strom Frame

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRAME (BLACK) Part #: 41100-31J00-YAP Required per assembly: 1 Not Available
2	RAIL, SEAT, (SILVER) Part #: 41200-31J10-YD8 Required per assembly: 1 Not Available
3	BOLT Part #: 09139-10003 Required per assembly: 4 $8.81 $7.93 - + Add to cart
4	COVER, PIVOT, RH Part #: 43580-31J00 Required per assembly: 1 $25.26 $22.73 - + Add to cart
5	PROTECTOR (80X80X2.0) Part #: 33652-07D00 Required per assembly: 1 Note: CUSHION, FI (20X90X2.0); CUT AS REQUIRED ((20X40)) $6.98 $6.28 - + Add to cart
6	CUSHION, UPPER Part #: 63115-37H00 Required per assembly: 1 $4.83 $4.35 - + Add to cart
7	CUSHION, PIVOT, COVER, NO.2 Part #: 94429-21E00 Required per assembly: 1 $3.32 $2.99 - + Add to cart
8	COVER, PIVOT, LH Part #: 43590-31J00 Required per assembly: 1 $25.26 $22.73 - + Add to cart
9	PROTECTOR (80X80X2.0) Part #: 33652-07D00 Required per assembly: 1 Note: CUSHION, FI (20X90X2.0); CUT AS REQUIRED ((20X40)) $6.98 $6.28 - + Add to cart
10	CUSHION, UPPER Part #: 63115-37H00 Required per assembly: 1 $4.83 $4.35 - + Add to cart
11	CUSHION, PIVOT, COVER, NO.2 Part #: 94429-21E00 Required per assembly: 1 $3.32 $2.99 - + Add to cart
12	SCREW, LOWER Part #: 09139-05074 Required per assembly: 4 $3.02 $2.72 - + Add to cart
13	NUT, CRANK, CASE Part #: 41922-19F20 Required per assembly: 1 $20.42 $17.46 - + Add to cart
14	BOLT, CRANK, CASE, ADJUST, LWR Part #: 41921-16G01 Required per assembly: 1 $25.36 $21.67 - + Add to cart
15	NUT, CRANK, CASE Part #: 41922-33E20 Required per assembly: 1 Not Available
16	SPACER, ADJUSTER, UPPER Part #: 41941-19F01 Required per assembly: 1 Note: SPACER, CRANKCASE UPPER; $45.52 $38.92 - + Add to cart
17	BOLT, ADJUST Part #: 41921-47H00 Required per assembly: 1 $56.82 $51.14 - + Add to cart
18	SPACER, HEAD, FRONT Part #: 41942-02F00 Required per assembly: 1 $31.01 $27.91 - + Add to cart
19	BOLT, FRONT Part #: 07130-0840B Required per assembly: 1 Note: BOLT, NO.3; $5.00 $4.50 - + Add to cart
20	BOLT, FRONT Part #: 07130-0840B Required per assembly: 1 Note: BOLT, NO.3; $5.00 $4.50 - + Add to cart
