Windshield replacement parts for 2016 Yamaha FJ09

OEM Parts Yamaha 2016 Yamaha FJ09 Windshield

WINDSHIELD Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	WINDSHIELD Part #: 2PP-28381-00-00 Required per assembly: 1 $272.99 $251.37 - + Add to cart
2	SCREW, ROUND, HEAD Part #: 90150-05024-00 Required per assembly: 4 $3.35 $2.80 - + Add to cart
3	NUT Part #: 90179-05003-00 Required per assembly: 4 $6.49 $4.81 - + Add to cart
4	COVER 1 Part #: 2PP-84369-00-P0 Required per assembly: 1 $155.99 $131.09 - + Add to cart
5	BOLT Part #: 90111-06029-00 Required per assembly: 4 $6.49 $4.63 - + Add to cart
6	COLLAR Part #: 90387-06048-00 Required per assembly: 4 $9.49 $5.96 - + Add to cart
7	STAY, SIDE, 1 Part #: 2PP-2831U-00-00 Required per assembly: 1 $35.99 $28.46 - + Add to cart
8	STAY, SIDE, 1 Part #: 2PP-2832U-00-00 Required per assembly: 1 $35.99 $28.46 - + Add to cart
9	BUSH Part #: 90386-07MA2-00 Required per assembly: 4 $3.64 $3.46 - + Add to cart
10	WASHER, PLATE, (122-21725-00) Part #: 90202-07015-00 Required per assembly: 2 $9.49 $6.35 - + Add to cart
11	STAY, SUPPORT, 1 Part #: 2PP-2831T-00-00 Required per assembly: 1 $32.99 $24.04 - + Add to cart
12	PLUG, SPEC'L, SHAPE Part #: 90338-07157-00 Required per assembly: 2 $8.49 $5.67 - + Add to cart
13	BOLT, LEG, SHIELD Part #: 2PP-28331-00-00 Required per assembly: 2 $37.99 $30.69 - + Add to cart
14	STAY, GUIDE, 1 Part #: 2PP-2831E-00-00 Required per assembly: 2 $5.49 $4.16 - + Add to cart
15	KNOB Part #: 3P6-8432N-00-00 Required per assembly: 2 $10.99 $8.63 - + Add to cart
16	SCREW, PAN, HEAD Part #: 98507-03010-00 Required per assembly: 2 $3.85 $2.65 - + Add to cart
17	STAY 1 Part #: 2PP-28356-00-00 Required per assembly: 1 $185.99 $179.71 - + Add to cart
18	BRACKET 1 Part #: 2PP-2836A-00-00 Required per assembly: 1 $17.98 $14.95 - + Add to cart
19	BOLT, FLANGE Part #: 95022-06010-00 Required per assembly: 1 $6.49 $5.35 - + Add to cart
20	BOLT, WITH, WASHER Part #: 90119-08062-00 Required per assembly: 2 $8.49 $5.53 - + Add to cart
21	CIRCLIP (6L5) Part #: 99080-03600-00 Required per assembly: 2 $3.64 $3.46 - + Add to cart
22	BOLT, FLANGE Part #: 95817-06025-00 Required per assembly: 4 $1.75 $1.44 - + Add to cart
23	COLLAR 437216330000 Part #: 90387-07391-00 Required per assembly: 4 $10.49 $7.61 - + Add to cart
24	DAMPER Part #: 3C3-83513-00-00 Required per assembly: 4 $8.49 $6.31 - + Add to cart
25	CLAMP Part #: 90464-09026-00 Required per assembly: 1 $4.65 $3.84 - + Add to cart
26	PANEL, INNER, 3 Part #: 2PP-2836M-00-00 Required per assembly: 1 $25.98 $20.55 - + Add to cart
27	RIVET Part #: 90269-05006-00 Required per assembly: 1 $2.75 $1.84 - + Add to cart
28	RIVET Part #: 90269-07007-00 Required per assembly: 4 $4.40 $3.30 - + Add to cart
29	LABEL, NOTICE, WINDSHIELD, 1 Part #: 4B5-2815K-00-00 Required per assembly: 1 $8.49 $7.12 - + Add to cart
