Generator replacement parts for 2016 Yamaha SRX120

OEM Parts Yamaha 2016 Yamaha SRX120 Generator

GENERATOR Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	ROTOR ASSEMBLY Part #: 7CN-H5650-30-00 Required per assembly: 1 $234.99 $226.38 - + Add to cart
2	T.C.I. UNIT ASSEMBLY Part #: 7CN-H5640-02-00 Required per assembly: 1 $191.99 $123.36 - + Add to cart
3	STATOR ASSEMBLY Part #: 7BN-H1410-01-00 Required per assembly: 1 $182.99 $170.72 - + Add to cart
4	BOLT, FLANGE Part #: 95817-06020-00 Required per assembly: 2 $3.50 $2.65 - + Add to cart
5	BINDER Part #: 7CN-H7188-10-00 Required per assembly: 1 $1.55 $1.00 - + Add to cart
6	NUT Part #: 90170-14800-00 Required per assembly: 1 $6.49 $4.16 - + Add to cart
7	WASHER, PLAIN Part #: 92990-14200-00 Required per assembly: 1 $2.60 $1.68 - + Add to cart
8	PLUG CAP ASSEMBLY Part #: 7CN-H2370-00-00 Required per assembly: 1 $7.99 $6.41 - + Add to cart
9	BOLT Part #: 90109-06881-00 Required per assembly: 4 $6.49 $5.38 - + Add to cart
