Front Fork replacement parts for 2016 Yamaha TTR125LE

OEM Parts Yamaha 2016 Yamaha TTR125LE Front Fork

FRONT FORK Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	FRONT FORK ASSY (L.H) Part #: 1B2-F3102-21-00 Required per assembly: 1 Not Available
2	INNER TUBE COMP 1 Part #: 1B2-F3110-10-00 Required per assembly: 1 ~~$199.99~~ $186.66 - + Add to cart
3	TUBE, OUTER, (LH) Part #: 1B2-F3126-11-00 Required per assembly: 1 Not Available
4	PISTON, FRONT, FORK Part #: 1B2-F3171-00-00 Required per assembly: 1 Not Available
5	SPRING Part #: 1B2-F3351-20-00 Required per assembly: 1 Not Available
6	RING, SNAP Part #: 2A6-F3156-00-00 Required per assembly: 1 $3.80 - + Add to cart
7	OIL SEAL Part #: 5B6-23145-00-00 Required per assembly: 1 ~~$26.98~~ $23.57 - + Add to cart
8	WASHER, OIL, SEAL Part #: 5B6-23146-00-00 Required per assembly: 1 ~~$12.99~~ $11.76 - + Add to cart
9	RING, PISTON Part #: 1E7-F3157-00-00 Required per assembly: 1 $3.27 - + Add to cart
10	SPRING, REBOUND Part #: 1B2-F3151-00-00 Required per assembly: 1 $6.17 - + Add to cart
11	SPACER, OIL, LOCK Part #: 1B2-F3166-00-00 Required per assembly: 1 Not Available
12	GASKET, DRAIN, PLUG Part #: 3MA-F3129-00-00 Required per assembly: 1 $4.11 - + Add to cart
13	BOLT, HEXAGON, SOCKET, HEAD Part #: 4B4-F3181-00-00 Required per assembly: 1 ~~$10.49~~ $10.25 - + Add to cart
14	BAND Part #: 1B2-23192-00-00 Required per assembly: 1 $16.77 - + Add to cart
15	BOOT Part #: 1B2-23191-00-00 Required per assembly: 1 ~~$47.99~~ $39.74 - + Add to cart
16	OIL SEAL Part #: 1L9-23145-00-00 Required per assembly: 1 ~~$28.98~~ $22.24 - + Add to cart
17	BOLT, CAP Part #: 1B2-23111-00-00 Required per assembly: 1 $14.78 - + Add to cart
18	CIRCLIP Part #: 1B2-23183-20-00 Required per assembly: 1 $4.25 - + Add to cart
19	O-RING Part #: 93210-08003-00 Required per assembly: 1 ~~$10.49~~ $9.16 - + Add to cart
20	FORK BOLT Part #: 1B2-2311H-00-00 Required per assembly: 1 ~~$72.98~~ $65.73 - + Add to cart
21	SEAT, SPRING, UPPER Part #: 1B2-23142-00-00 Required per assembly: 1 ~~$5.49~~ $4.92 - + Add to cart
22	RING, SNAP Part #: 1B2-23153-20-00 Required per assembly: 1 $3.61 - + Add to cart
23	FRONT FORK ASSY (R.H) Part #: 1B2-F3103-21-00 Required per assembly: 1 Not Available
24	INNER TUBE COMP 1 Part #: 1B2-F3110-10-00 Required per assembly: 1 ~~$199.99~~ $186.66 - + Add to cart
25	TUBE, OUTER, (RIGHT) Part #: 1B2-F3136-10-00 Required per assembly: 1 ~~$148.99~~ $134.37 - + Add to cart
26	PISTON, FRONT, FORK Part #: 1B2-F3171-00-00 Required per assembly: 1 Not Available
27	SPRING Part #: 1B2-F3351-20-00 Required per assembly: 1 Not Available
28	RING, SNAP Part #: 2A6-F3156-00-00 Required per assembly: 1 $3.80 - + Add to cart
29	OIL SEAL Part #: 5B6-23145-00-00 Required per assembly: 1 ~~$26.98~~ $23.57 - + Add to cart
30	WASHER, OIL, SEAL Part #: 5B6-23146-00-00 Required per assembly: 1 ~~$12.99~~ $11.76 - + Add to cart
31	RING, PISTON Part #: 1E7-F3157-00-00 Required per assembly: 1 $3.27 - + Add to cart
32	SPRING, REBOUND Part #: 1B2-F3151-00-00 Required per assembly: 1 $6.17 - + Add to cart
33	SPACER, OIL, LOCK Part #: 1B2-F3166-00-00 Required per assembly: 1 Not Available
34	GASKET, DRAIN, PLUG Part #: 3MA-F3129-00-00 Required per assembly: 1 $4.11 - + Add to cart
35	BOLT, HEXAGON, SOCKET, HEAD Part #: 4B4-F3181-00-00 Required per assembly: 1 ~~$10.49~~ $10.25 - + Add to cart
36	BAND Part #: 1B2-23192-00-00 Required per assembly: 1 $16.77 - + Add to cart
37	BOOT Part #: 1B2-23191-00-00 Required per assembly: 1 ~~$47.99~~ $39.74 - + Add to cart
38	OIL SEAL Part #: 1L9-23145-00-00 Required per assembly: 1 ~~$28.98~~ $22.24 - + Add to cart
39	BOLT, CAP Part #: 1B2-23111-00-00 Required per assembly: 1 $14.78 - + Add to cart
40	CIRCLIP Part #: 1B2-23183-20-00 Required per assembly: 1 $4.25 - + Add to cart
41	O-RING Part #: 93210-08003-00 Required per assembly: 1 ~~$10.49~~ $9.16 - + Add to cart
42	FORK BOLT Part #: 1B2-2311H-00-00 Required per assembly: 1 ~~$72.98~~ $65.73 - + Add to cart
43	SEAT, SPRING, UPPER Part #: 1B2-23142-00-00 Required per assembly: 1 ~~$5.49~~ $4.92 - + Add to cart
44	RING, SNAP Part #: 1B2-23153-20-00 Required per assembly: 1 $3.61 - + Add to cart
45	UNDER BRACKET COMP. Part #: 1B2-F3340-00-35 Required per assembly: 1 Note: SL(SILVER) FOR DPBSE(DEEP PURPLISH BLUE SOLID E) ~~$263.99~~ $247.15 - + Add to cart
46	BOLT, FLANGE Part #: 90105-10304-00 Required per assembly: 2 $11.05 - + Add to cart
47	BRACKET 1 Part #: 1B2-F334G-00-00 Required per assembly: 1 $5.97 - + Add to cart
48	GUIDE, CABLE Part #: 1C6-F3389-00-00 Required per assembly: 1 ~~$3.50~~ $2.69 - + Add to cart
49	BOLT, WITH, WASHER Part #: 90119-05193-00 Required per assembly: 1 ~~$2.35~~ $1.77 - + Add to cart
