Headlight replacement parts for 2016 Yamaha VMAX

OEM Parts Yamaha 2016 Yamaha VMAX Headlight

HEADLIGHT Full screen diagram

Please note: If a part is displayed on the diagram but not shown in the parts list, it is no longer available.

Location	Part Description

1	HEADLIGHT ASSEMBLY Part #: 2S3-84300-00-00 Required per assembly: 1 $584.48 $544.35 - + Add to cart
2	SOCKET, PILOT, LIGHT Part #: 5JW-84346-00-00 Required per assembly: 1 $16.48 $13.34 - + Add to cart
3	BULB (12V-5W) Part #: 4SV-84347-00-00 Required per assembly: 1 $9.49 $6.31 - + Add to cart
4	COVER, SOCKET Part #: 5JW-84397-00-00 Required per assembly: 1 $32.99 $24.86 - + Add to cart
5	BULB, HEADLIGHT, (12V-60/55W) Part #: 8V0-84314-10-00 Required per assembly: 1 $75.98 $71.97 - + Add to cart
6	PLATE, GUIDE Part #: 2S3-8413G-00-00 Required per assembly: 1 $4.15 $3.43 - + Add to cart
7	CLAMP Part #: 90464-66001-00 Required per assembly: 1 $1.99 $1.83 - + Add to cart
8	SCREW, PAN, HEAD, TAPPING, (AK5) Part #: 97780-50116-00 Required per assembly: 1 $1.49 $1.44 - + Add to cart
9	DAMPER Part #: 4XV-83513-00-00 Required per assembly: 4 $8.49 $6.29 - + Add to cart
10	COVER, UPPER, 1 Part #: 2S3-23121-00-00 Required per assembly: 1 $167.99 $157.26 - + Add to cart
11	COVER, UPPER, 2 Part #: 2S3-23131-00-00 Required per assembly: 1 $167.99 $157.26 - + Add to cart
12	BOLT, HEX, SOCKET, BUTTON Part #: 90111-06106-00 Required per assembly: 2 $6.49 $5.22 - + Add to cart
13	WASHER, PLATE Part #: 90201-06049-00 Required per assembly: 2 $3.64 $3.40 - + Add to cart
14	SCREW, SPEC'L, SHAPE Part #: 90149-06302-00 Required per assembly: 4 $6.49 $4.22 - + Add to cart
15	STAY, HEADLIGHT Part #: 2S3-23174-00-00 Required per assembly: 1 $213.99 $186.07 - + Add to cart
16	GROMMET Part #: 90480-13026-00 Required per assembly: 2 $3.60 $3.02 - + Add to cart
17	COLLAR Part #: 90387-06234-00 Required per assembly: 2 $13.49 $11.26 - + Add to cart
18	NUT Part #: 90179-06061-00 Required per assembly: 4 $17.48 $14.12 - + Add to cart
19	BOLT, HEX, SOCKET, BUTTON Part #: 90111-06107-00 Required per assembly: 2 $4.04 $3.30 - + Add to cart
20	WASHER, PLATE Part #: 90201-06049-00 Required per assembly: 2 $3.64 $3.40 - + Add to cart
21	COVER, CROWN Part #: 2S3-23437-00-00 Required per assembly: 1 $191.99 $179.37 - + Add to cart
22	GROMMET Part #: 90480-13026-00 Required per assembly: 2 $3.60 $3.02 - + Add to cart
23	DAMPER Part #: 4XV-83513-00-00 Required per assembly: 1 $8.49 $6.29 - + Add to cart
24	COLLAR Part #: 90387-06233-00 Required per assembly: 2 $8.49 $5.10 - + Add to cart
25	COVER, DUST, SEAL, 1 Part #: 2S3-23383-00-00 Required per assembly: 2 $5.49 $4.34 - + Add to cart
